Page 1753 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (3) Remove front retainer seal by (Fig. 21) collaps- ing one side of seal then prying it out. (4) Remove front retainer bearing cup with Puller 6444. Assemble Puller Flange 6444-1 and Puller Rods 6444

Page 1754 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual DRIVE GEAR (1) Remove drive gear (Fig. 25). (2) Remove pilot bearing from drive gear (Fig. 26).(3) Remove tapered bearing from drive gear with Puller Flange 6444-1 and Puller Rods 6444-6 (Fig. 27). (4

Page 1755 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual MAINSHAFT AND GEARTRAIN (1) Move 1-2 and 3-4 synchro sleeves into neutral. (2) Remove drive gear thrust bearing from forward end of mainshaft (Fig. 28). (3) Remove fourth gear clutch gear and synchro

Page 1756 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (3) Remove reverse idler shaft (Fig. 33). (4) Rotate countershaft outward and push reverse idler gear away from countershaft and toward front of case (Fig. 34).(5) Remove idler gear (Fig. 35). (6) Kee

Page 1757 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (8) Remove countershaft rear bearing with Puller Flange 6444-1 and Puller Rods 6444-4 (Fig. 37). NOTE: Shaft cannot be removed from case until rear bearing has been removed. (9) Position first Jaw 644

Page 1758 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual GEAR CASE (1) Remove countershaft front bearing cap with hammer (Fig. 40). (2) Remove countershaft front bearing cup with Remover 6454 and Handle C-4171 (Fig. 41).(3) Remove roll pin that secures shif

Page 1759 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual MAINSHAFT NOTE: Gear and synchro components can be installed backwards. Paint or scribe gear and syn- chro components for installation reference. Then stack geartrain parts in order of removal. (1) Re

Page 1760 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (6) Remove second gear thrust washer (Fig. 46). Note washer notch for locating pin. (7) Remove thrust washer locating pin (Fig. 47) with needle nose pliers.(8) Remove second gear (Fig. 48). (9) Remove
