Page 1081 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C250 (HANDS FREE) - BLACK (HEADLINER SIDE) CAV CIRCUIT 1 X712 20DG/LB 2 X735 20BR 3 X792 20LB/DG 4 X835 20OR/GY 5 X730 20GY/YL 6 X793 20DG/YL 7 X722 20LB/DG 8- C301 - (BODY SIDE) CAV CIRCUIT 1 G74 20V

Page 1082 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C301 - (PASSENGER DOOR SIDE) CAV CIRCUIT 1 G74 20VT/WT 2 P195 18LG/YL (POWER WINDOWS/ LOCKS) 3 P72 18TN/GY (POWER WINDOWS/ LOCKS) 4 X154 18GY/YL 5 X156 18GY/LB 6 P74 18TN/OR (POWER WINDOWS/ LOCKS) 7 Q

Page 1083 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C302 - BLACK (PASSENGER DOOR SIDE) CAV CIRCUIT 1 F21 20PK/DG 2- 3- 4 G778 18VT/LB 5- 6 G160 20VT/LG 7 Q16 14OR/TN 8 Q26 14OR/GY 9- 10 P392 18LG/DB 11 Z216 20BK/DB 12 - 13 C16 18DB/GY 14 - 15 - 16 - C3

Page 1084 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C305 (SLT) - (BODY SIDE) CAV CIRCUIT 1 C16 18DB/GY 2 Q16 14OR/TN 3 Q26 14OR/GY 4 P393 18LG 5- 6 P1 18TN/LG 7 Z461 14BK/DG 8 Q612 14OR/DB 9- 10 G161 20VT/DG 11 G163 20VT/LB 12 Q412 14OR/LB 13 Q611 14OR

Page 1085 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C306 - (REAR DOOR SIDE) CAV CIRCUIT 1 Z79 20LG/BK 2 G77 20VT/GY 3 P393 18LG (POWER WINDOW/LOCKS) 4 P5 18TN/OR (POWER WINDOW/LOCKS) 5 Q15 14OR/LB (POWER WINDOW/ LOCKS) 6 Q411 14OR/WT (POWER WINDOW/ LOC

Page 1086 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C308 - (I/P SIDE) CAV CIRCUIT 1 G74 20VT/WT 2- 3- 4 X154 18GY/YL 5 G160 20VT/LG (SLT) 6 G76 20VT/YL 7- 8 P392 18LG/DB (SLT) 9 G778 18VT/LB (SLT) 10 F21 20PK/DG 11 - 12 - 13 - 14 X206 18DG/LG 15 X296 1

Page 1087 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C311 - (BODY SIDE) CAV CIRCUIT 1 Z918 14BK (BASE) 1 Z939 14BK (EXCEPT BASE) 2 A210 12OR/RD (EXCEPT BASE) 3 G10 20VT/LG 3 G10 20LG/RD 4 A405 18RD/DB 5 Z951 20BK 6 C311 - (DRIVER SEAT SIDE) CAV CIRCUIT

Page 1088 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C313 - (DRIVER SEAT SWITCH SIDE) CAV CIRCUIT 1 P105 12LG 2 P13 12LG/OR 3 P21 12LG/TN 4 P15 12LG/BR 5 P107 12LG/WT 6 P11 12LG/YL 7 A210 12OR/RD 8 Z939 14BK 9 P17 12LG/DG 10 P19 12LG/LB 11 - 12 - C315 -
