Page 2265 of 2627

(5) Install the clutch gear (Fig. 65) onto the output
shaft. Verify that the pointed ends of the clutch gear
teeth are pointing to the front of the mainshaft.
(6) Lubricate sector shaft with transmission fluid
and install shift sector in case (Fig. 66). Position slot
in sector so it will be aligned with shift fork pin
when shift forks are installed.
(7) Apply LoctiteŸ 242, or equivalent, to the
threads of the sector support to replentish the factory
applied patch. Install the shift sector support.
Tighten the sector support with Socket 9033 to 27-34
N´m (20-25 ft.lbs.).(8) Assemble and install range fork and hub (Fig.
67). Be sure hub is properly seated in low range gear
and engaged to the input gear.
(9) Align and insert range fork pin in shift sector
slot.
(10) Install mode fork and shift rail onto the mode
sleeve.
(11) Install the mode fork, sleeve, and shift rail
into the transfer case (Fig. 68).
Fig. 65 Install Clutch Gear
1 - OUTPUT SHAFT
2 - CLUTCH GEAR
3 - MODE HUB
Fig. 66 Install Shift Sector
1 - SHIFT SECTOR
Fig. 67 Install Range Fork And Hub Assembly
1 - RANGE HUB
2 - RANGE FORK
Fig. 68 Mode Fork And Sleeve Installation
1 - MODE SLEEVE
2 - MODE FORK AND RAIL
21 - 562 TRANSFER CASE - NV273DR
TRANSFER CASE - NV273 (Continued)
Page 2266 of 2627
(12) Install new o-ring on detent plug (Fig. 69).
(13) Install detent plunger, spring, and plug (Fig.
70). Tighten the plug to 16-25 N´m (12-18 ft. lbs.).(1) Position the shift motor and mode sensor
assembly (Fig. 71) onto the transfer case.
(2) Install the bolts (Fig. 72) to hold the shift
motor and mode sensor assembly to the transfer
case. Tighten the bolts to 16-25 N´m (12-18 ft. lbs.).
Fig. 69 O-Ring Installation On Detent Plug
1 - O-RING
2 - DETENT PLUG
Fig. 70 Install Detent plug, Spring, and Plunger
1 - FRONT CASE HALF
2 - DETENT PLUG
3 - SPRING
4 - PLUNGER
Fig. 71 Install Shift Motor Assembly Onto Transfer
Case
1 - TRANSFER CASE
2 - SHIFT MOTOR ASSEMBLY
Fig. 72 Install Shift Motor Assembly Bolts
1 - TRANSFER CASE
2 - SHIFT MOTOR ASSEMBLY
3 - BOLTS
DRTRANSFER CASE - NV273 21 - 563
TRANSFER CASE - NV273 (Continued)
Page 2267 of 2627

(3) Install mainshaft into the transfer case (Fig.
73). Guide mainshaft through the mode and range
sleeves and into the input gear.
FRONT OUTPUT SHAFT AND DRIVE CHAIN
(1) Install the front output shaft (Fig. 74) into the
front output shaft front bearing.
(2) Install the front output shaft bearing inner
snap-ring (Fig. 75) onto the output shaft.
(3) Install the new front output shaft seal with
Installer MB991168A
(4) Insert front drive sprocket in drive chain.
(5) Install drive chain around rear drive sprocket.(6) Position rear drive sprocket (Fig. 76) over the
output shaft and lower the sprocket and chain
assembly until the front sprocket is positioned over
the front output shaft.
(7) Align the splines in the sprockets to the splines
on the output shafts and install the sprockets onto
the output shafts.
Fig. 73 Install Mainshaft Assembly
1 - FRONT CASE HALF
2 - MAINSHAFT ASSEMBLY
Fig. 74 Install Front Output Shaft
1 - FRONT CASE
2 - FRONT OUTPUT SHAFT
Fig. 75 Install Front Output Shaft Bearing Inner
Snap-Ring
1 - FRONT CASE HALF
2 - SNAP-RING
Fig. 76 Install Drive Chain and Sprockets
1 - FRONT CASE HALF
2 - CHAIN
3 - DRIVE SPROCKETS
21 - 564 TRANSFER CASE - NV273DR
TRANSFER CASE - NV273 (Continued)
Page 2268 of 2627

(8) Install front sprocket retaining ring (Fig. 77).
(9) Install rear sprocket retaining ring (Fig. 78).(10) Insert magnet in front case pocket (Fig. 79).
REAR CASE
(1) Install the oil pick-up tube and screen into the
rear case half.
(2) Apply bead of MopartGasket Maker, or equiv-
alent, to mating surface of front case. Keep sealer
bead width to maximum of 3/16 inch. Do not use
excessive amount of sealer as excess will be displaced
into case interior.
(3) Align mainshaft with the rear output shaft
bearing and align shift rail with bore in rear case.
Then install rear case (Fig. 80). Verify that the case
alignment dowels correctly seat into their mating
recesses.
Fig. 77 Install Front Output Shaft Sprocket
Retaining Ring
1 - FRONT OUTPUT SHAFT
2 - DRIVE SPROCKET
3 - RETAINING RING
Fig. 78 Install Rear Output Shaft Sprocket Retaining
Ring
1 - REAR OUTPUT SHAFT
2 - DRIVE SPROCKET
3 - RETAINING RING
Fig. 79 Case Magnet Installation
1 - MAGNET
2 - CASE POCKET
Fig. 80 Install Rear Case Half
1 - FRONT CASE HALF
2 - REAR CASE HALF
DRTRANSFER CASE - NV273 21 - 565
TRANSFER CASE - NV273 (Continued)
Page 2269 of 2627

(4) Install 4-5 rear case-to front case bolts (Fig. 81)
to hold rear case in position. Tighten bolts snug but
not to specified torque at this time.
CAUTION: Verify that shift rail, and case alignment
dowels are seated before installing any bolts. Case
could be cracked if shaft rail or dowels are mis-
aligned.
(5) Tighten bolts to 27-34 N´m (20-25 ft. lbs.),
(6) Install rear output bearing inner snap-ring
(Fig. 82) to output shaft.OIL PUMP AND REAR EXTENSION
(1) Install the oil pump (Fig. 83) onto the output
shaft.
(2) Engage the oil pump pick-up tube (Fig. 84) into
the oil pump. Verify that the pick-up tube o-ring is
on the tube and is correctly installed to the oil pump.
Fig. 81 Install Case Half Bolts
1 - FRONT CASE HALF
2 - REAR CASE HALF
3 - BOLTS
Fig. 82 Install Rear Bearing Inner Snap-Ring
1 - OUTPUT SHAFT
2 - REAR CASE HALF
3 - SNAP-RING
Fig. 83 Install Oil Pump
1 - REAR CASE HALF
2 - REAR OUTPUT SHAFT
3 - OIL PUMP
Fig. 84 Engage The Oil Pick-up To Oil Pump
1 - OIL PUMP
2 - OIL PICK-UP TUBE
21 - 566 TRANSFER CASE - NV273DR
TRANSFER CASE - NV273 (Continued)
Page 2270 of 2627
(3) Apply bead of MopartGasket Maker, or equiv-
alent, to mating surface of rear extension housing.
Keep sealer bead width to maximum of 3/16 inch. Do
not use excessive amount of sealer as excess could be
displaced into output bearing.
(4) Install extension housing (Fig. 85) onto the
rear case half.
(5) Install rear extension bolts (Fig. 86). Tighten
the bolts to 27-34 N´m (20-25 ft.lbs.).(6) Install the extension housing dust boot and
seal assembly with Installer 9037 and Handle C-4171
(Fig. 87).
Fig. 85 Install Extension Housing
1 - REAR CASE HALF
2 - EXTENSION HOUSING
Fig. 86 Install Extension Housing Bolts
1 - EXTENSION HOUSING
2 - BOLTS
Fig. 87 Install Extension Housing Seal
1 - EXTENSION HOUSING
2 - HANDLE C-4171
3 - INSTALLER 9037
DRTRANSFER CASE - NV273 21 - 567
TRANSFER CASE - NV273 (Continued)
Page 2271 of 2627

(7) Install the front companion flange onto the
front output shaft.
(8) Install two bolts 180É apart into the front out-
put shaft companion flange.
(9) Place holder over the bolts and against the
companion flange (Fig. 88).
(10) Install a new front companion flange nut.
Tighten the companion flange nut to 176-271 N´m
(130-200 ft.lbs.).
INSTALLATION
(1) Mount transfer case on a transmission jack.
(2) Secure transfer case to jack with chains.
(3) Position transfer case under vehicle.
(4) Align transfer case and transmission shafts
and install transfer case onto the transmission.
(5) Install and tighten transfer case attaching nuts
to 27-34 N´m (20-25 ft. lbs.) torque.
(6) Connect the vent hose.
(7) Connect the shift motor and mode sensor wir-
ing connectors. Secure wire harness to clips on trans-
fer case.
(8) Align and connect the propeller shafts.
(9) Fill transfer case with correct fluid. (Refer to
21 - TRANSMISSION/TRANSFER CASE/FLUID -
STANDARD PROCEDURE)
(10) Install skid plate, if equipped.(11) Remove transmission jack and support stand.
(12) Lower vehicle and verify transfer case shift
operation.
SPECIFICATIONS
TRANSFER CASE - NV273
TORQUE SPECIFICATIONS
DESCRIPTION N-m Ft. Lbs. In. Lbs.
Plug, Detent 16-24 12-18 -
Plug, Drain/Fill 20-34 15-25 -
Bolt, Extension Housing 27-34 20-25 -
Bolt, Case Half 27-34 20-25 -
Support, Sector 27-34 20-25 -
Nuts, Mounting 30-41 20-30 -
Bolts, Shift Motor and
Mode Sensor Assembly16-25 12-18 -
Nut, Companion Flange 176-271 130-200 -
Fig. 88 Install Companion Flange Nut
1 - HOLDER 6719
2 - BOLTS
21 - 568 TRANSFER CASE - NV273DR
TRANSFER CASE - NV273 (Continued)
Page 2272 of 2627
SPECIAL TOOLS
TRANSFER CASE NV271/NV273
Handle, Universal - C-4171
Remover - L-4454
Installer, Bearing - 6953
Installer, Pump Housing Seal - 7888
Installer, Bearing - 8128
Cup - 8148
Installer - 8151
Installer - 8152
DRTRANSFER CASE - NV273 21 - 569
TRANSFER CASE - NV273 (Continued)
