SHIFT LEVER AND FRONT OUTPUT SHAFT SEAL
(1) Shift transfer case into NEUTRAL.
(2) Remove nut that retains the shift lever to sec-
tor shaft. Then remove shift lever from shaft (Fig. 3).
(3) Remove the front propeller shaft seal boot
retaining clamp (Fig. 4).
(4) Remove the front propeller shaft seal boot (Fig.
5).
(5) Remove the front output shaft seal slinger by
bending (Fig. 6) the slinger ears away from the
transfer case.
(6) Using a suitable pry tool (Fig. 7), remove the
slinger from the output shaft using care not to dam-
age the shaft.
(7) Using a screw and a slide hammer, remove the
front output shaft seal.
Fig. 3 Remove Range Lever Nut
1 - RANGE LEVER
Fig. 4 Remove Boot Clamp
1 - SEAL BOOT
2 - BOOT CLAMP
Fig. 5 Remove Seal Boot
1 - SEAL BOOT
2 - SEAL SLINGER
Fig. 6 Bend Slinger Ears
1 - SLINGER
2 - BEND UPWARD
Fig. 7 Remove Slinger From Shaft
1 - SLINGER
2-PRYTOOL
21 - 418 TRANSFER CASE - NV241 GENIIDR
TRANSFER CASE - NV241 GENII (Continued)
Page 2122 of 2627
REAR EXTENSION
(1) Remove rear extension bolts (Fig. 8).
(2) Remove rear extension housing (Fig. 9). Tap
extension once or twice with a plastic mallet to break
sealer bead and loosen it.(3) Remove output bearing retaining ring with
heavy duty snap-ring pliers (Fig. 10).
OIL PUMP AND REAR CASE
(1) Remove rear case-to-front case bolts (Fig. 11).
Fig. 8 Remove Rear Extension Bolts
1 - EXTENSION HOUSING
2 - TRANSFER CASE
Fig. 9 Remove Rear Extension
1 - EXTENSION HOUSING
2 - TRANSFER CASE
3 - PRY SLOT
Fig. 10 Remove Output Shaft Retaining Ring
1 - REAR OUTPUT SHAFT
2 - OUTPUT SHAFT BEARING
3 - RETAINING RING
4 - TRANSFER CASE
Fig. 11 Remove Case Bolts
1 - REAR CASE
2 - FRONT CASE
3 - BOLT
DRTRANSFER CASE - NV241 GENII 21 - 419
TRANSFER CASE - NV241 GENII (Continued)
Page 2123 of 2627

(2) Loosen rear case with pry tool to break sealer
bead. Insert tool in slot at each end of case (Fig. 12).
(3) Unseat rear case from alignment dowels.
(4) Remove rear case and oil pump assembly from
front case (Fig. 13).
CAUTION: Do not remove the bolts holding the oil
pump cover to the rear case half. The oil pump
cover is aligned to the rear output shaft bearing
inner race and will become mis-aligned if the bolts
are loosened. If the transfer case failure has gener-
ated any debris which may have become trapped in
the oil pump, the rear case and oil pump assembly
MUST be replaced.FRONT OUTPUT SHAFT AND DRIVE CHAIN
(1) Remove shift rail cup and spring (Fig. 14).
(2) Remove front sprocket retaining ring (Fig. 15).
Fig. 12 Loosen Case Halves
1 - REAR CASE
2 - FRONT CASE
3 - PRY SLOTS
Fig. 13 Remove Rear Case
1 - REAR CASE
2 - FRONT CASE
Fig. 14 Shift Rail Cup And Spring Removal
1 - SHIFT RAIL
2 - SPRING
3 - CUP
Fig. 15 Removing Front Sprocket Retaining Ring
1 - FRONT SPROCKET
2 - RETAINING RING
3 - FRONT OUTPUT SHAFT
21 - 420 TRANSFER CASE - NV241 GENIIDR
TRANSFER CASE - NV241 GENII (Continued)
Page 2124 of 2627
(3) Pull mainshaft, front sprocket and chain out-
ward about 25.4 mm (1-inch) simultaneously (Fig.
16).
(4) Remove chain from mainshaft drive sprocket
and remove front sprocket and chain as assembly.
SHIFT FORKS AND MAINSHAFT
(1) Remove the transfer case position sensor (Fig.
17).(2) Loosen detent plug.
(3) Remove detent plug, spring, and plunger (Fig.
18). Note that the plug has an O-ring seal. Remove
and discard this seal.
(4) Remove the front output shaft snap-ring (Fig.
19).
Fig. 16 Remove Front Sprocket and Drive Chain
1 - FRONT DRIVE SPROCKET
2 - DRIVE CHAIN
3 - MAINSHAFT
Fig. 17 Remove Position Sensor
1 - FRONT CASE
2 - POSITION SENSOR
Fig. 18 Remove Detent Plug, Spring, and Plunger
1 - FRONT CASE
2 - DETENT PLUG
3 - DETENT SPRING
4 - DETENT PLUNGER
Fig. 19 Remove Front Output Shaft Snap-ring
1 - FRONT OUTPUT SHAFT
2 - SNAP-RING
DRTRANSFER CASE - NV241 GENII 21 - 421
TRANSFER CASE - NV241 GENII (Continued)
Page 2125 of 2627
(5) Remove front output shaft from bearing in case
(Fig. 20).
(6) Pull mainshaft assembly out of input gear,
mode sleeve, and case (Fig. 21).(7) Remove mode fork, mode sleeve, and shift rail
as assembly (Fig. 22). Note which way the sleeve fits
in the fork (long side of sleeve goes to front).
(8) Remove range fork retaining ring.
(9) Remove range fork and hub as an assembly
(Fig. 23). Note fork position for installation reference.
Fig. 23 Range Fork And Hub Removal
1 - RANGE HUB
2 - RANGE FORK
Fig. 20 Remove Front Output Shaft
1 - FRONT CASE
2 - FRONT OUTPUT SHAFT
Fig. 21 Remove Mainshaft
1 - FRONT CASE
2 - MAINSHAFT
Fig. 22 Remove Mode Fork and Shift Rail
1 - MODE FORK
2 - SHIFT RAIL
3 - MODE SLEEVE
21 - 422 TRANSFER CASE - NV241 GENIIDR
TRANSFER CASE - NV241 GENII (Continued)
Page 2126 of 2627
(10) Remove the shift sector support (Fig. 24).
(11) Remove shift sector (Fig. 25).MAINSHAFT
(1) Remove the drive sprocket retaining ring (Fig.
26) from the output shaft.
(2) Remove the drive sprocket thrust washer (Fig.
27) from the output shaft.
Fig. 24 Remove Sector Support
1 - SECTOR SUPPORT
2 - FRONT CASE
3 - SECTOR SHAFT
Fig. 25 Remove Shift Sector
1 - SHIFT SECTOR
Fig. 26 Remove The Drive Sprocket Retaining Ring
1 - OUTPUT SHAFT
2 - RETAINING RING
3 - DRIVE SPROCKET
Fig. 27 Remove Drive Sprocket Thrust Washer
1 - OUTPUT SHAFT
2 - THRUST WASHER
3 - DRIVE SPROCKET
DRTRANSFER CASE - NV241 GENII 21 - 423
TRANSFER CASE - NV241 GENII (Continued)
Page 2127 of 2627
(3) Remove drive sprocket (Fig. 28) from the out-
put shaft.
(4) Remove the clutch gear (Fig. 29) and hub (Fig.
30) from the output shaft.
(5) Remove the mode hub retaining ring (Fig. 31)
from the output shaft.
Fig. 31 Remove Retaining Ring
1 - OUTPUT SHAFT
2 - RETAINING RING
3 - MODE HUB
Fig. 28 Remove Drive Sprocket
1 - OUTPUT SHAFT
2 - DRIVE SPROCKET
Fig. 29 Remove Clutch Gear
1 - OUTPUT SHAFT
2 - CLUTCH GEAR
3 - MODE HUB
Fig. 30 Remove Sprocket Hub
1 - OUTPUT SHAFT
2 - SPROCKET HUB
21 - 424 TRANSFER CASE - NV241 GENIIDR
TRANSFER CASE - NV241 GENII (Continued)
Page 2128 of 2627
(6) Remove the mode hub (Fig. 32) from the output
shaft.
INPUT AND PLANETARY GEAR
(1) Remove input gear seal with suitable screw
and slide hammer.
(2) Remove input gear retaining ring (Fig. 33) with
heavy duty snap-ring pliers.(3) Place front case in horizontal position. Then
remove input gear and low range gear as an assem-
bly (Fig. 34). Tap gear out of bearing with plastic
mallet, if necessary.
INPUT AND PLANETARY GEAR
(1) Remove snap-ring that retains input gear in
low range gear (Fig. 35).
Fig. 35 Input Gear Snap-Ring Removal
1 - INPUT GEAR SNAP-RING
Fig. 32 Remove Mode Hub
1 - OUTPUT SHAFT
2 - MODE HUB
Fig. 33 Remove Input Gear Retaining Ring
1 - INPUT GEAR
2 - RETAINING RING
Fig. 34 Remove Input Planetary Assembly
1 - FRONT CASE
2 - INPUT PLANETARY ASSEMBLY
DRTRANSFER CASE - NV241 GENII 21 - 425
TRANSFER CASE - NV241 GENII (Continued)
