Page 1057 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual ADJUSTABLE PEDAL SWITCH (EXCEPT MEMORY) - BLUE 6 WAY CAV CIRCUIT FUNCTION 1 P206 18LG/LB ADJUSTABLE PEDALS MOTOR REVERSE 2 A72 18RD/OR ADJUSTABLE PEDAL RELAY OUTPUT 3- - 4 Z146 18BK GROUND 5 F504 20GY

Page 1058 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual AIRBAG CONTROL MODULE C2 - 32 WAY CAV CIRCUIT FUNCTION 1- - 2- - 3- - 4- - 5- - 6- - 7- - 8- - 9 R53 20LG/YL DRIVER SEAT BELT TENSIONER LINE 2 10 R55 20LG/DG DRIVER SEAT BELT TENSIONER LINE 1 11 R56 2

Page 1059 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual AIRBAG-PASSENGER ON/OFF SWITCH-6WAY CAV CIRCUIT FUNCTION 1 R106 20LG/LB PASSENGER AIRBAG MUX SWITCH SENSE 2 R104 20LB/LG PASSENGER AIRBAG MUX SWITCH RETURN 3 G104 20VT/GY PASSENGER AIRBAG INDICATOR DR

Page 1060 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual AMPLIFIER AUDIO C1 (PREMIUM) - GRAY 12 WAY CAV CIRCUIT FUNCTION 1 X53 20DG LEFT FRONT SPEAKER (+) 2 X55 20DG/BR LEFT FRONT SPEAKER (-) 3 X57 20DG/OR LEFT REAR SPEAKER (-) 4 Z513 18BK GROUND 5 X11 20DG

Page 1061 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual AUTOMATIC DAY/NIGHT MIRROR C1 (EXCEPT BASE)-7WAY CAV CIRCUIT FUNCTION 1 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START) 2 Z13 20BK/WT GROUND 3 L1 20WT/LG BACKUP LAMP FEED 4- - 5- - 6- - 7- - AUTO

Page 1062 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual BLEND DOOR ACTUATOR (SINGLE ZONE)-2WAY CAV CIRCUIT FUNCTION 1 C34 20DB/LB COMMON DOOR DRIVER 2 C61 20DB/LG BLEND DOOR DRIVER BLOWER MOTOR - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 C70 10DB/YL BLOWER MOTOR

Page 1063 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 K32 18DB/YL BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID CONTROL 2 Z101 18BK/VT GROUND C102 (NGC) - (AMBIENT TEMPERATURE

Page 1064 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C106 (5.7L A/T) - (INTAKE AIR FUEL MODULE SIDE) CAV CIRCUIT 1 K11 18BR/YL 2 K12 18BR/DB 3 K13 18BR/LB 4 K14 18BR/TN 5 K38 18BR/OR 6 K58 18BR/VT 7 K26 18BR/YL 8 K28 18BR/LB 9 K19 18DB/DG 10 K17 18DB/TN
