Page 1089 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C316 - (PASSENGER SEAT SIDE) CAV CIRCUIT 1 P89 20LG/OR 2 P54 20OR/LG 3 A210 12OR/RD 4 Z939 14BK 5 P188 18LG/VT 6- C319 - (CENTER CONSOLE SIDE) CAV CIRCUIT 1 Z939 18BK 2 A405 18RD/DB C319 - (SEAT JUMPE

Page 1090 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C320 - NATURAL (BODY SIDE) CAV CIRCUIT 1 Z72 20LG/BK 2 G76 20TN/YL 3 P392 18LG/DB (EXCEPT BASE) 4 G778 18VT/LB (EXCEPT BASE) 5 Q15 14OR/LB (EXCEPT BASE) 6 Q412 14OR/LB (EXCEPT BASE) 7 Q612 14OR/DB (EX

Page 1091 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C323 (EXCEPT HEATED SEATS) - (PASSENGER SEAT SIDE) CAV CIRCUIT 1 P18 12LG/DG 2 P14 12LG/OR 3 P10 12LG/TN 4 P12 12LG/YL 5 P16 12LG/BR 6 P20 12LG/LB 7 P104 12LG 8 P106 12LG/WT 9 A210 12OR/RD 10 Z939 14B

Page 1092 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C323 (HEATED SEATS) - (SEAT JUMPER SIDE) CAV CIRCUIT 1 P104 12LG 2 P106 12LG/WT 3 A210 12OR/RD 4 Z939 14BK 5- 6- C327 (DUAL REAR WHEELS) - (CHASSIS SIDE) CAV CIRCUIT 1 L7 18WT/YL 2 Z948 20BK C327 (DUA

Page 1093 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C328 (DUAL REAR WHEELS) - (DRW LAMP SIDE) CAV CIRCUIT 1 L70 18WT/YL 2 Z948 18BK CAMSHAFT POSITION SENSOR (DIESEL)-3WAY CAV CIRCUIT FUNCTION 1 F855 18PK/YL 5 VOLT SUPPLY 2 K916 18BR/OR SENSOR GROUND 3

Page 1094 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual CENTER HIGH MOUNTED STOP LAMP/CARGO LAMP-4WAY CAV CIRCUIT FUNCTION 1 L14 20WT/TN CARGO LAMP DRIVER 2 Z964 20BK GROUND 3 Z350 20BK/TN GROUND 4 L50 20WT/TN BRAKE LAMP SWITCH OUTPUT CIGAR LIGHTER OUTLET

Page 1095 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual CLEARANCE LAMP NO. 3 (HEAVY DUTY)-2WAY CAV CIRCUIT FUNCTION 1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT 2 Z946 20BK GROUND CLEARANCE LAMP NO. 4 (HEAVY DUTY)-2WAY CAV CIRCUIT FUNCTION 1 L70 20WT/GY FUSE

Page 1096 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual CLOCKSPRING C2 - YELLOW 4 WAY CAV CIRCUIT FUNCTION 1 R61 20LG/VT DRIVER SQUIB 2 LINE 1 2 R63 20LG/WT DRIVER SQUIB 2 LINE 2 3 R43 20LG/BR DRIVER SQUIB 1 LINE 1 4 R45 20LG/OR DRIVER SQUIB 1 LINE 2 CLOCK
