Page 1761 of 2627
(10) Remove second gear clutch cone snap ring
from mainshaft synchro hub groove (Fig. 50).
(11) Remove second gear clutch cone, synchro
clutch ring and synchro stop ring (Fig. 51).(12) Remove 1-2 synchro hub snap ring (Fig. 52).
(13) Remove 1-2 synchro sleeve, hub, struts and
springs as an assembly (Fig. 53).
NOTE: Tapered side of sleeve also goes toward
front. Do not disassemble synchro components
unless worn or damaged.
Fig. 50 SECOND GEAR CLUTCH CONE SNAP RING
1 - 1-2 SLEEVE
2 - SNAP RING
3 - SECOND GEAR CLUTCH CONE
Fig. 51 SECOND GEAR CLUTCH CONE AND RING
1 - 1-2 SLEEVE AND HUB
2 - SYNCHRO STOP RING
3 - CLUTCH RING
4 - SECOND GEAR CLUTCH CONE
Fig. 52 1-2 SLEEVE AND HUB SNAP RING
1 - 1-2 HUB SNAP RING
2 - 1-2 SLEEVE AND HUB
Fig. 53 1-2 SYNCHRO SLEEVE AND HUB
1 - 1-2 SLEEVE AND HUB
21 - 58 MANUAL TRANSMISSION - NV4500DR
MANUAL TRANSMISSION - NV4500 (Continued)
Page 1762 of 2627
(14) Remove first gear synchro stop ring and
clutch ring (Fig. 54).
(15) Remove first gear clutch cone front snap ring
from mainshaft hub (Fig. 55).(16) Remove first gear clutch cone (Fig. 56).
(17) Remove first gear clutch gear rear snap ring
from mainshaft hub (Fig. 56).
NOTE: Do not remove this snap ring unless main-
shaft is being replaced.
Fig. 54 FIRST GEAR STOP AND CLUTCH RING
1 - FIRST GEAR CLUTCH RING
2 - FIRST GEAR STOP RING
Fig. 55 FIRST GEAR CLUTCH GEAR FRONT SNAP
RING
1 - FIRST SPEED CLUTCH GEAR
2 - CLUTCH GEAR SNAP RING (FRONT)
Fig. 56 FIRST GEAR CLUTCH GEAR
1 - CLUTCH GEAR SNAP RING (REAR)
2 - FIRST SPEED CLUTCH GEAR
DRMANUAL TRANSMISSION - NV4500 21 - 59
MANUAL TRANSMISSION - NV4500 (Continued)
Page 1763 of 2627
(18) Remove mainshaft rear bearing, with Puller
Flange 6444-1 and Puller Rods 6444-3 for 4X2 or
6444-4 for 4X4.
(19) Position the first Jaw 6445 on the bearing
cone and seat Puller Flange 6444-1 in notch of jaw
(Fig. 57).
(20) Install second Jaw 6445 on the bearing cone
and puller flange. Slide Collar 6444-8 over jaws to
hold them in place.
(21) Install Puller 6444 on the puller rods and
secure with nuts (Fig. 58). Tighten puller bolt to the
remove bearing.
Fig. 57 MAINSHAFT REAR BEARING PULLER
1 - REAR BEARING
2 - FLANGE
3-JAW
4 - COLLAR5 - MAINSHAFT
6 - PULLER
7 - RODS
8-JAW
21 - 60 MANUAL TRANSMISSION - NV4500DR
MANUAL TRANSMISSION - NV4500 (Continued)
Page 1764 of 2627

(22) Remove bearing puller tools and rear main-
shaft bearing from output shaft.
(23) Remove reverse gear thrust washer (Fig. 59).
(24) Remove reverse gear and synchro components
as assembly (Fig. 60).CAUTION: Do not disassemble synchro compo-
nents unless they are damaged. If synchro sleeve
or struts require service, mark position of sleeve on
hub before removal. Correct sleeve position is
important as sleeve can be installed backwards
causing shift problems.
(25) Remove reverse gear bearing assembly from
mainshaft (Fig. 60).
(26) Remove reverse gear bearing spacer from
mainshaft (Fig. 61).
(27) Remove reverse clutch gear snap ring (Fig.
61). Heavy duty snap ring pliers will be required to
spread the ring far enough to remove it.
Fig. 58 MAINSHAFT REAR BEARING
1-JAWS
2 - COLLAR
3 - FLANGE
4 - MAINSHAFT
5 - PULLER
6 - TIGHTENING WRENCH
7 - HOLDING WRENCH
8 - RODS
Fig. 59 REVERSE GEAR THRUST WASHER
1 - REVERSE GEAR
2 - THRUST WASHER
Fig. 60 REVERSE GEAR, BEARING, AND STOP
RING
1 - FIRST GEAR
2 - REVERSE GEAR ASSEMBLY
3 - BEARING ASSEMBLY
4 - STOP RING
Fig. 61 REVERSE GEAR BEARING SPACER AND
FIRST GEAR SNAP RING
1 - CLUTCH GEAR SNAP RING
2 - REVERSE GEAR BEARING SPACER
DRMANUAL TRANSMISSION - NV4500 21 - 61
MANUAL TRANSMISSION - NV4500 (Continued)
Page 1765 of 2627

(28) Remove reverse clutch gear (Fig. 62).
(29) Remove first gear from bearing and mainshaft
(Fig. 63).
(30) Remove first gear bearing from mainshaft
(Fig. 64).
CLEANING
Clean the gears, shafts, shift components and
transmission housings with a standard parts clean-
ing solvent. Do not use acid or corrosive base sol-
vents. Dry all parts except bearings with compressed
air.
Clean the shaft bearings with a mild solvent such
as Mopar degreasing solvent, Gunk or similar sol-
vents. Do not dry the bearings with compressed air.
Allow the bearings to either air dry or wipe them dry
with clean shop towels.
INSPECTION
NOTE: Minor corrosion, nicks, or pitting can be
smoothed with 400 grit emery and polished out with
crocus cloth.
Inspect the reverse idler gear, bearings, shaft and
thrust washers. Replace the bearings if the rollers
are worn, chipped, cracked, flat-spotted or brinnelled.
Replace the gear if the teeth are chipped, cracked or
worn thin.
Inspect the front bearing retainer and bearing cup.
Replace the bearing cup if scored, cracked, brinnelled
or rough. Check the release bearing slide surface of
the retainer carefully. Replace the retainer if worn or
damaged in any way.
Inspect mainshaft bearing surfaces, splines, snap
ring grooves and threads. Replace the shaft if any
surfaces exhibit considerable wear or damage.
Inspect the countershaft and bearings. Replace the
shaft if any surfaces exhibit considerable wear or
damage.
Inspect shift forks for wear and distortion. Check
fit of the sleeve in the fork to be sure the two parts
fit and work smoothly. Replace the fork if the roll pin
holes are worn oversize or damaged. Do not attempt
to salvage a worn fork. Replace shift fork roll pins if
necessary or if doubt exists about their condition.
The all bearings for wear, roughness, flat spots,
pitting or other damage. Replace the bearings if nec-
essary.
Inspect the blocker rings and fiction cones. replace
either part if worn or damaged in any way. Replace if
the friction material is burned, flaking off or worn.
Inspect synchro components wear or damage.
Replace parts if worn, cracked or distorted.
Inspect all of the thrust washers and locating pins.
Replace the pins if bent or worn. Replace the wash-
ers if worn or the locating pin notches are distorted.
Inspect the case and housing/adapter sealing and
mating surfaces are free of burrs and nicks. InspcetFig. 62 Reverse Clutch Gear
1 - REVERSE CLUTCH GEAR
Fig. 63 FIRST GEAR
1 - FIRST GEAR
Fig. 64 FIRST GEAR BEARING
1 - MAINSHAFT
2 - FIRST GEAR BEARING
21 - 62 MANUAL TRANSMISSION - NV4500DR
MANUAL TRANSMISSION - NV4500 (Continued)
Page 1766 of 2627

the alignment dowels in the case top surface and in
the housing/adapter are tight and in good condition.
Replace the gear case or housing/adapter if cracked
or broken.
ASSEMBLY
NOTE: Gaskets are not used in the transmission.
Use Mopar Silicone Sealer or equivalent on all gear
case and extension housing sealing surfaces.
COUNTERSHAFT AND REVERSE IDLER GEAR
(1) Install countershaft front bearing cup in case
with Handle C-4171 and Installer 6061-1.
(2) Install front bearing on countershaft with
Installer C-4340 (Fig. 65).
(3) Lubricate countershaft front bearing cup and
cone with petroleum jelly.
(4) Position gear case on end with rear of case fac-
ing up (Fig. 66).
(5) Install countershaft in gear case (Fig. 66).
NOTE: Do not install rear countershaft bearing on
countershaft at this time.(6) Lubricate reverse idler gear bearings with
petroleum jelly and install first bearing and second
bearing (Fig. 67).
(7) Install idler gear front thrust washer on boss
in gear case (Fig. 67). Coat thrust washer with lib-
eral quantity of petroleum jelly to hold it in place.
Fig. 65 COUNTERSHAFT FRONT BEARING
1 - FRONT BEARING
2 - INSTALLER
3 - COUNTERSHAFT
Fig. 66 COUNTERSHAFT IN GEAR CASE
1 - GEAR CASE
2 - COUNTERSHAFT
Fig. 67 IDLER GEAR FRONT THRUST WASHER
1 - IDLER GEAR FRONT THRUST WASHER ON BOSS
DRMANUAL TRANSMISSION - NV4500 21 - 63
MANUAL TRANSMISSION - NV4500 (Continued)
Page 1767 of 2627
(8) Install reverse idler gear in case (Fig. 68).
(9) Install idler gear rear thrust washer between
idler gear and case boss (Fig. 68).
(10) Align idler gear bearings and thrust washers
with a drift.
(11) Install reverse idler shaft with notched end of
shaft facing countershaft (Fig. 69).(12) Lift countershaft upward and position wood
block between front of shaft and case (Fig. 70).
(13) Install rear bearing cone on countershaft with
Installer C-4040 (Fig. 71).
Fig. 68 IDLER GEAR
1 - REAR THRUST WASHER
2 - REVERSE IDLER GEAR
3 - FRONT THRUST WASHER
Fig. 69 REVERSE IDLER SHAFT
1 - COUNTERSHAFT
2 - SHAFT NOTCH
3 - REVERSE IDLER SHAFT
Fig. 70 SUPPORTING COUNTERSHAFT
1 - COUNTERSHAFT
2 - WOOD BLOCK
Fig. 71 COUNTERSHAFT REAR BEARING
1 - INSTALLER
2 - REAR BEARING
3 - COUNTERSHAFT
21 - 64 MANUAL TRANSMISSION - NV4500DR
MANUAL TRANSMISSION - NV4500 (Continued)
Page 1768 of 2627

(14) Remove wood block from under countershaft
and lower countershaft front bearing into front bear-
ing cup.
(15) Lubricate countershaft rear bearing cup and
cone with petroleum jelly.
(16) Install countershaft rear bearing cup in gear
case and over rear bearing (Fig. 72). Tap cup into
place with plastic mallet if necessary.
(17) Install countershaft rear bearing plate (Fig.
73).
NOTE: Verify plate is seated in notch in reverse
idler shaft before tightening bearing plate bolts.(18) Apply Mopar silicone adhesive/sealer or equiv-
alent to flange and lip of new cap. Installnewfront
bearing cap in gear case (Fig. 74) with Handle
C-4171 and Installer C-3972-A.
COUNTERSHAFT END PLAY
(1) Rotate countershaft 4-5 times to seat bearings.
(2) Mount dial indicator on case. Then position
indicator plunger on end of countershaft and zero
dial indicator (Fig. 75).
(3) Raise countershaft with screwdriver and note
end play reading on dial indicator. End play should
be 0.051 - 0.15 mm (0.002 - 0.006 in.).
Fig. 72 COUNTERSHAFT REAR BEARING CUP
1 - COUNTERSHAFT REAR BEARING CUP
Fig. 73 COUNTERSHAFT REAR BEARING PLATE
1 - COUNTERSHAFT
2 - REAR BEARING PLATE
3 - IDLER SHAFT
Fig. 74 COUNTERSHAFT FRONT BEARING CAP
1 - FRONT BEARING CAP
Fig. 75 MEASURING COUNTERSHAFT END PLAY
1 - DIAL INDICATOR
2 - COUNTER SHAFT
3 - INDICATOR MOUNTING ARM AND BASE
DRMANUAL TRANSMISSION - NV4500 21 - 65
MANUAL TRANSMISSION - NV4500 (Continued)
