Page 1097 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual COIL ON PLUG NO. 1 (5.7L)-2WAY CAV CIRCUIT FUNCTION 1 K342 16BR/WT ASD RELAY OUTPUT 2 K19 18DB/DG COIL CONTROL NO. 1 COIL ON PLUG NO. 2 (3.7L/4.7L) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K17 18DB/TN COI

Page 1098 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual COIL ON PLUG NO. 3 (5.7L)-2WAY CAV CIRCUIT FUNCTION 1 K342 16BR/WT ASD RELAY OUTPUT 2 K18 18DB/OR COIL CONTROL NO. 3 COIL ON PLUG NO. 4 (3.7L/4.7L) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K15 18DB/GY COI

Page 1099 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual COIL ON PLUG NO. 5 (5.7L)-2WAY CAV CIRCUIT FUNCTION 1 K342 16BR/WT ASD RELAY OUTPUT 2 K16 18DB/YL COIL CONTROL NO. 5 COIL ON PLUG NO. 6 (3.7L/4.7L) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K10 18DB/OR COI

Page 1100 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual COIL ON PLUG NO. 7 (5.7L)-2WAY CAV CIRCUIT FUNCTION 1 K342 16BR/WT ASD RELAY OUTPUT 2 K97 18BR COIL CONTROL NO. 7 COIL ON PLUG NO. 8 (4.7L) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K98 18DB/YL COIL CONTRO

Page 1101 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual CONDENSER FAN (NGC) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 Z823 16BK/DG GROUND 2 C123 16LB/WT CONDENSER FAN RELAY OUTPUT CONTROLLER ANITLOCK BRAKE C1 - BLACK 14 WAY CAV CIRCUIT FUNCTION 1 B4 20DG/GY REA

Page 1102 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual CRANKSHAFT POSITION SENSOR (4.7L)-3WAY CAV CIRCUIT FUNCTION 1 K24 20BR/LB CKP SIGNAL 2 K900 20DB/DG SENSOR GROUND 3 F855 20PK/YL 5 VOLT SUPPLY CRANKSHAFT POSITION SENSOR (5.7L)-3WAY CAV CIRCUIT FUNCTI

Page 1103 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual DATA LINK CONNECTOR - BLACK 16 WAY CAV CIRCUIT FUNCTION 12 D20 20WT/LG SCI RECEIVE (PCM) 13 - - 14 - - 15 D15 18WT/DG SCI TRANSMIT (TCM) 16 A114 18GY/RD FUSED B(+) DATA LINK CONNECTOR-ENGINE (DIESEL)-

Page 1104 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual DOOR AJAR SWITCH-PASSENGER - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 G74 20VT/WT PASSENGER DOOR AJAR SWITCH SENSE 2 Z74 20BK/WT GROUND DOOR AJAR SWITCH-RIGHT REAR - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 G76 2
