Page 1065 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C107 (5.7L) - BLACK (INTAKE AIR FUEL MOD- ULE SIDE) CAV CIRCUIT 1 K900 18DB/DG 2 K1 18VT/BR 3 K21 18DB/LG 4 K922 18BR/DB 5 F856 18YL/PK 6 K447 18TN/YL 7 K342 16BR/WT 8 F855 18PK/YL 9 K2 18VT/OR 10 K12

Page 1066 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C109 (DIESEL) - LT GRAY (ENGINE SIDE) CAV CIRCUIT 1 V35 18VT/OR 2 V32 18VT/YL 3 T41 18YL/DB 4 T6 18DG 5 T118 18DG 6 T9 18DG/TN 7- 8 T38 18YL/BR 9 T75 18YL/LB 10 T54 18DG/OR 11 T515 18YL/DB 12 V36 18VT

Page 1067 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C110 (DIESEL) - BLACK (TRANSMISSION SIDE) CAV CIRCUIT 1 C3 20DB/YL 2 B29 20DG/WT 3- 4 K900 20DB/DG 5 V37 20VT 6 K160 18BR/OR 7 K161 18BR/LB 8 F856 18YL/PK 9 D20 20WT/LG 10 D21 20WT/BR 11 F202 20PK/GY

Page 1068 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C112 (DIESEL M/T) - (TRANSMISSION SIDE) CAV CIRCUIT 1 C3 18DB/YL 2 A961 14RD 3 K615 18BR/WT 4 K616 18BR/YL 5 K167 18BR/YL 6 K23 18BR/WT 7 K852 18BR/VT 8 K29 18WT/BR C130 (DIESEL) - (TRANSMISSION SIDE)

Page 1069 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C131 (3.7L/4.7L EXCEPT ELECTRONIC TRANS- FER CASE) - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 D20 20WT/LG 2 D21 20WT/BR 3- 4- C131 (3.7L/4.7L EXCEPT ELECTRONIC TRANS- FER CASE) - DK GRAY (ENGINE SIDE) C

Page 1070 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C131 (4.7L ELECTRONIC TRANSFER CASE) - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 T316 16YL/GY 2 D200 20WT/LG 3 T313 20YL/LG 4 D202 20WT/VT 5 T885 20YL/GY 6 D201 20WT/DG 7 D203 20WT/BR 8 T315 16YL/BR 9 D2

Page 1071 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C131 (5.7L/DIESEL) - GRAY (HEADLAMP AND DASH SIDE) CAV CIRCUIT A1 T316 16YL/GY (ELECTRONIC TRANS- FER CASE) A2 D200 20WT/LG (ELECTRONIC TRANS- FER CASE) A3 T313 20YL/LG (ELECTRONIC TRANS- FER CASE) A4

Page 1072 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual C200 - (I/P SIDE) CAV CIRCUIT 1 C70 10DB/YL 2 C34 20DB/LB 3 C71 16DB/BR 4 C32 20DB/TN 5 C73 14DB/VT 6 C72 16DB/OR 7 C7 10DB 8 C29 20DB 9 C21 20DB/LG 10 C121 20DB/DG 11 C61 20DB/LG 12 C33 20LB/BR (SLT)
