Page 1145 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual SPEAKER-LEFT INSTRUMENT PANEL - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 X209 18GY/OR LEFT INSTRUMENT PANEL SPEAKER (+) 2 X299 18GY/YL LEFT INSTRUMENT PANEL SPEAKER (-) SPEAKER-LEFT REAR - WHITE 3 WAY CAV C

Page 1146 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual SPEED CONTROL SERVO (DIESEL A/T/NGC)-4WAY CAV CIRCUIT FUNCTION 1 V36 20VT/YL S/C VACUUM CONTROL 2 V35 20VT/OR S/C VENT CONTROL 3 V30 20VT/WT S/C BRAKE SWITCH OUTPUT 4 Z913 20BK GROUND SPEED CONTROL SW

Page 1147 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual TAIL/STOP/TURN SIGNAL LAMP-LEFT-6WAY CAV CIRCUIT FUNCTION 1 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT 2- - 3 Z928 18BK GROUND 4 L53 18DG/WT LEFT STOP LAMP FEED 5 L63 18WT/DG LEFT REAR TURN LAMP DRIVER 6

Page 1148 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual THROTTLE POSITION SENSOR (4.7L)-3WAY CAV CIRCUIT FUNCTION 1 F855 18PK/YL 5 VOLT SUPPLY 2 K22 18BR/OR TP NO. 1 SIGNAL 3 K900 18DB/DG SENSOR GROUND TOW/HAUL OVERDRIVE SWITCH - WHITE 2 WAY CAV CIRCUIT FU

Page 1149 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual TRANSFER CASE CONTROL MODULE C1 (ELECTRIC 4x4) - 16 WAY CAV CIRCUIT FUNCTION A1 D25 20VT/DB PCI BUS A2 - - A3 - - A4 G92 20VT/OR 4WD LOW INDICATOR A5 G91 20VT/WT 4WD HIGH INDICATOR A6 K977 20BR/WT MOD

Page 1150 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual TRANSFER CASE CONTROL MODULE C3 (ELECTRIC 4x4)-4WAY CAV CIRCUIT FUNCTION A Z905 16BK GROUND B A34 16RD/WT FUSED B(+) C T315 16YL/BR SHIFT MOTOR CONTROL A D T316 16YL/GY SHIFT MOTOR CONTROL B TRANSFER

Page 1151 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual TRANSMISSION RANGE SENSOR-6WAY CAV CIRCUIT FUNCTION 1 L10 18WT/GY FUSED IGNITION SWITCH OUTPUT (RUN) 2 T117 20DG/YL TRANS RANGE SENSOR ELECTRONIC CLUSTER 5 VOLT SUPPLY 3- - 4 L1 18WT/LG BACKUP LAMP FE

Page 1152 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual VACUUM PUMP (DIESEL)-4WAY CAV CIRCUIT FUNCTION 1- - 2 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START) 3- - 4 Z936 18BK GROUND VISTRONIC FAN DRIVE (DIESEL)-6WAY CAV CIRCUIT FUNCTION 1 K160 18BR/O
