Page 2129 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (2) Remove retainer (Fig. 36). (3) Remove front tabbed thrust washer (Fig. 37). (4) Remove input gear (Fig. 38). (5) Remove rear tabbed thrust washer from low range gear (Fig. 39). CLEANING Clean the

Page 2130 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual INPUT GEAR AND PLANETARY CARRIER Check the teeth on the gear (Fig. 40). Minor nicks can be dressed off with an oilstone but replace the gear if any teeth are broken, cracked, or chipped. The bearing s

Page 2131 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual DRIVE CHAIN Examine the drive chain and shaft bearings. replace the chain if stretched, distorted, or if any of the links bind. Replace the bearings if rough, or noisy. LOW RANGE ANNULUS GEAR Inspect

Page 2132 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (3) Using Installer 6436 and Handle C-4171 (Fig. 45), remove front output shaft bearing. (4) Start front output shaft bearing in case. Then seat bearing with Handle C-4171 and Installer 6953. (5) Inst

Page 2133 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (9) Install new bearing with Tool Handle C-4171 and Installer 5066 (Fig. 48). The bearing bore is chamfered at the top. Install the bearing so it is flush with the lower edge of this chamfer (Fig. 49)

Page 2134 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual INPUT AND PLANETARY GEAR (1) Lubricate gears and thrust washers (Fig. 52) with recommended transmission fluid. (2) Install first thrust washer in low range gear (Fig. 52). Be sure washer tabs are prop

Page 2135 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual SHIFT FORKS AND MAINSHAFT (1) Lubricate mainshaft splines with recommended transmission fluid. (2) Install the mode hub (Fig. 55) onto the output shaft. (3) Install the mode hub retaining ring (Fig. 5

Page 2136 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (7) Install the drive sprocket thrust washer (Fig. 60) onto the output shaft. (8) Install the drive sprocket retaining ring (Fig. 61) onto the output shaft.(9) Lubricate sector shaft with transmission
