2014 MITSUBISHI OUTLANDER SPORT Owners Manual

Keyless operation system4-12 Locking and unlocking
4
Key not detected
Inner buzzer sounds once
When the engine switch is turned to the ACC or ON from OFF or when the engine is started, the warning is activated, if any of the following conditions is occurred.•••Carrying another keyless operation key with a different code, or the keyless operation key could be outside the operating range.The battery of the keyless operation key is dead.Communication is blocked by electric wave environment.
Keyless operation key reminder
Inner buzzer sounds about 1 minuteOuter buzzer sounds about 3 seconds inter-mittently
If the operation mode is in OFF and the driver’s door is opened with the keyless operation key in the key slot, a warning is issued and the outer buzzer sounds for about 3 seconds and the inner buzzer sounds for about 1 minute to remind you to remove the key. If the key removed from key slot, the buzzer is stopped.
Keyless operation key take-out monitoring system
Inner buzzer sounds onceOuter buzzer sounds intermittently
••••When the vehicle is parked with the operation mode in any mode other than OFF, if you close the door after opening any of the doors and taking the keyless operation key out of the vehicle, a warning is issued until the key is detected in the vehicle.If you take the keyless operation key out of the vehicle through a window without opening a door, the keyless operation key take-out monitoring system does not operate.It is possible to change the setting to make the keyless operation key take-out monitoring system operate if you take the keyless operation key out from the vehicle through a window without opening a door. For further information, please contact a MITSUBISHI MOTORS Authorised Service Point.Even if you have the keyless operation key within the engine start operating range, if the keyless operation key and vehicle ID codes cannot be matched, for example due to the ambient environment or electromagnetic conditions, the warning may be activated.
Item
Display
Buzzer
Note (Solution)
BK0203201EN.book 12 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Keyless operation system
Locking and unlocking 4-13
4
E00306000019E00307201464
The emergency key is built into the keylessoperation key. If the keyless operation func-tion cannot be used, for example because the
keyless operation key battery has worn out orthe vehicle battery is flat, you can lock andunlock the driver’s door and start the enginewith the emergency key.To u s e t h e e m e r g e n c y k e y ( A ) , u n l o c k t h elock knob (B) and remove it from the keylessoperation key (C).Refer to “Doors” on page 4-14, or “If the key-less operation key is not operating properly”on page 7-13.
Key lock-in preven-tion system
Inner buzzer sounds onceOuter buzzer sounds about 3 seconds inter-mittently
••When the operation mode is in OFF, if you close all the doors and the tailgate with the keyless operation key left in the vehicle and you try to lock the doors and tailgate by pressing the driver’s or front passenger’s door lock/unlock switch, or the tailgate LOCK switch, a warning is issued and you cannot lock the doors and tailgate.Make sure you have the keyless operation key with you before lock-ing the doors. Even if you leave the keyless operation key inside the vehicle, it is possible that the doors will lock depending on the sur-rounding environment and wireless signal conditions.
Door ajar prevention system
Inner buzzer sounds onceOuter buzzer sounds about 3 seconds inter-mittently
When the operation mode in OFF, if you try to lock the doors and tail-gate by pressing the driver’s or front passenger’s door lock/unlock switch, or the tailgate LOCK switch with one of the doors or the tail-gate not completely closed, a warning is issued and you cannot lock the doors and tailgate.
Operation mode OFF reminder system
Inner buzzer sounds onceOuter buzzer sounds about 3 seconds inter-mittently
When the operation mode is in any mode other than OFF, if you close all the doors and the tailgate then try to lock the doors and tailgate by pressing the driver’s or front passenger’s door lock/unlock switch, or the tailgate LOCK switch, a warning is issued and you cannot lock the doors and tailgate.
Item
Display
Buzzer
Note (Solution)
To o p e r a t e w i t h
out using the
keyless operation function Emergency key
BK0203201EN.book 13 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Doors4-14 Locking and unlocking
4
E00300402291
Pull the inside door handle towards you toopen the door.
NOTE
zOnly use the emergency key for emergen-cies. If the keyless operation key batterywears out, replace it as
quickly as possible so
that you can use the keyless operation key.zAfter using the emergency key, always returnit into the keyless operation key.
Doors
CAUTIONzMake sure the doors ar
e closed: dr
iving with
doors not completely closed is dangerous.zNever leave children in the vehicle unat-tended.zBe careful not to lock the doors while thekey is inside the vehicle.NOTE
zTo p r e v e n t t h e k e y f r o m b e i n g l o c k e d i n s i d ethe vehicle, neither the lock knob on thedriver’s door nor the key can be used to lockthe driver’s door when it is open.
To lock or unlock with the key 1- Lock2- Unlock
NOTE
zWhen locking or unlocking with the key,only the driver’s door will be locked orunlocked.To l o c k o r u nl o c k a l l d o o r s a n d t h e t a i l g a t e ,use the central door lock switch, the keylessentry system or the keyless operation func-tion.Refer to “Central door locks” on page 4-15,“Keyless entry system” on pages 4-3, and“To operate using the
keyless operation func-
tion” on page 4-9.zIf the vehicle is equipped with the keylessoperation system, the driver’s door can belocked or unlocked with the emergency key.Refer to “Emergency key” on page 4-13.
To l o c k o r u n l o c k f r o m i n s i d e the vehicle 1- Lock2- Unlock
NOTE
zThe driver’s door can be opened withoutusing the lock knob by pulling the insidedoor handle.
BK0203201EN.book 14 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Central door locks
Locking and unlocking 4-15
4
Set the inside lock knob (1) to the lockedposition and close the door (2).
E00300801937
Using the central door lock switch on thedriver’s door locks or unlocks all doors andthe tailgate.
E00311301310
Yo u c a n s e l e c t t h e f u n c t i o n t o u n l o c k t h edoors and tailgate using the engine switch.This functions is not activated when the vehi-cle is shipped from the factory. To activate or
deactivate this function, please contact aMITSUBISHI MOTORS Authorised ServicePoint.All doors and the tailgate will unlock when-ever the operation mode is put in OFF.
E00300901042
Child protection helps prevent the rear doorsfrom being opened accidentally from theinside.
To l o c k w i t h o u t u s i n g t h e k e y Front passenger’s door, Rear door Central door locks
NOTE
zRepeated continuous
operation between lock
and unlock could activate the central doorlocking systems built-in protection circuitand prevent the system from operating. Ifthis occurs, wait about
1 minute before oper-
ating the central door lock switch.zWhen the driver’s door is open, the centraldoor lock switch cannot be used to lock it.
To l o c k a n d u n l o c k t h e d o o r s and tailgate Using the central door lock switch 1- Lock
2- Unlock
To unlock the doors and tail-gate LHD
RHD
Using the power switch “Child-protection” rear doors 1- Lock2- Unlock
BK0203201EN.book 15 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Tailgate*4-16 Locking and unlocking
4
If the lever is set to the locked position, therear door cannot be opened using the insidehandle, but only with the outside handle.If the lever is set to the “Unlock” position, thechild protection mechanism does not func-tion.
E00301401220
The tailgate can be locked or unlocked byusing the central door lock switch (driverside).
After unlocking the tailgate, push the tailgateopen switch (A) and pull up the tailgate.Pull the tailgate grip (B) downward as illus-trated. Gently slam the tailgate from the out-side so that it is completely closed. Alwaysensure the tailgate is securely closed.
CAUTIONzWhen driving with a child in the rear seat,please use the child
protection to prevent
accidental door opening which may cause anaccident.
Ta i l g a t e
*
WA R N I N GzIt is dangerous to drive with the tailgateopen, since carbon mo
noxide (CO) gas can
enter the cabin.Yo u c a n n o t s e e o r s m e l l C O . I t c a n c a u s eunconsciousness and even death.zWhen opening and cl
osing the tailgate,
make sure that there are no people nearbyand be careful not to hit your head orpinch your hands, neck, etc.
To l o c k / u n l o c k

1- Lock2- Unlock
NOTE
zRepeated continuous
operating between lock
and unlock could cause the central doorlocks’ built-in protection circuit to preventthe system from operating. If this occurs,wait about 1 minute
before operating the
central door lock switch.LHD
RHD
To o p e n

NOTE
zThe tailgate cannot be opened when the bat-tery is flat or disconnected.If you want to open the tailgate, it can beopened by using the insi
de tailgate release.
Refer to “Inside tailgate release” on page4-24.
To c l o s e

BK0203201EN.book 16 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Electric tailgate*
Locking and unlocking 4-17
4
E00312801022
Before operating the electric tailgate, unlockthe tailgate by using the keyless entry system,keyless operation function, or the central doorlocks.Refer to “Keyless entry system” on page 4-3,“Keyless operation system” on page 4-6, or“Central door locks” on page 4-15.
E00312900013
CAUTIONzWhen closing the tailgate, always ensureyour or other person’s fingers cannot becaught by the tailgate.NOTE
zGas struts (C) are installed to support thetailgate.To p r e v e n t d a m a g e o r f a u l t y o p e r a t i o n .•Do not hold the gas struts when closing thetailgate.•Also, do not push or
pull the gas struts.
•Do not attach any plastic material, tape,etc., to the gas struts.•Do not tie string, etc., around the gas struts.•Do not hang any object
on the gas struts.
Electric tailgate* Operating the electric tailgate
WA R N I N GzThe luggage area was not designed forpeople to ride in it. Do not let your chil-dren ride in or play in the luggage area.Riding or pl
aying in the luggage area
could result in a serious accident.
zBefore driving, make sure the electric tail-gate is securely closed.If you drive with the
tailgate open, there is
a danger of exhaust gas entering the vehi-cle and causing carbon monoxide poison-ing.zFor safety’s sake, the electric tailgateshould be operated by adults and not chil-dren.zWhen opening and closing the tailgate,make sure that there are no people nearbyand be careful not to hit your head orpinch your hands, neck, etc.Make sure the electric tailgate is com-pletely open before loading and unloadingluggage.CAUTIONzDo not stand behind th
e exhaust pipe when
loading and unl
oading luggage.
The heat from the exhaust could cause burns.zBefore driving, make sure the electric tail-gate is closed properly. If the tailgate openswhen driving, luggage could fall onto theroad and cause an accident.zDo not install accessories other thanMITSUBISHI MOTORS GENUINE partson the electric tailgate. Some accessoriescould be too heavy, causing the drop preven-tion mechanism to operate.WA R N I N G
BK0203201EN.book 17 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Electric tailgate*4-18 Locking and unlocking
4
E00313001034
The electric tailgate can be operated using theremote control switch on the keyless opera-tion key, or the close switch on the tailgatewhen the electric tailgate power switch (A) ison.
CAUTIONzWhen closing the electric tailgate, make surethere is no foreign matter around the striker(A).If foreign matter gets into the striker it couldprevent the electric tailgate from closing nor-mally.NOTE
zWhen opening and closing the electric tail-gate, do not place your hands near the arm(B).zGas struts (C) are installed in the locationsshown below in order to support the electrictailgate.zMake sure not to bump your head in the areanear the arm of the
electric tailgate when
loading and unloading luggage.
NOTE
zPlease observe the following in order to pre-vent damage or faulty operation.•Do not pull on the gas struts when closingthe electric tailgate or otherwise push orpull them.•Do not attach any plastic material, tape,etc., to the gas struts.•Do not tie string, etc., around the gas struts.•Do not hang anything fr
om the gas struts.
Automatic operation
WA R N I N GzTu r n o f f t h e e l e c t r i c t a i l g a t e p o w e r s w i t c hwhen not operating the electric tailgate.If the switch is left on, someone’s hand orhead could get caught if the electric tail-gate switch or close switch is accidentallyoperated, or childre
n play with the con-
trols.zIf the electric tailgate power switch isturned off while the
tailgate is operating,
it will stop moving and switch to manualoperation.At this time, the electric tailgate couldopen or close sudden
ly, depending on its
position.CAUTIONzDo not apply excessive force on the electrictailgate when opening or closing it. Doing socould cause a breakdown.
BK0203201EN.book 18 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Electric tailgate*
Locking and unlocking 4-19
4
E00313101048
The electric tailgate can be opened automati-cally when all of the following conditions aremet.zThe operation mode is in OFF.zThe key is not inserted into the ignitionswitch.zThe electric tailgate is completely closed.zThe electric tailgate is unlocked.
zThe operation mode is in ON with theelectrical parking switch is pressed.zThe electric tailgate is completely closed.zThe electric tailgate is unlocked.
zThe electric tailgate is unlocked.zThe keyless operation key is within theoperating range (70 cm from the electrictailgate switch) and the tailgate is locked.The factory setting is “Inactive”.To m o d i f y t h e s e t t i n g t o “ A c t i v e ” , p l e a s econtact an authorised MITSUBISHIMOTORS dealer.
The electric tailgate can be closed automati-cally when all of the following conditions aremet.zThe operation mode is in OFF.zThe electric tailgate is completely open.zPeople, luggage, etc., are not touching thesensors.
zThe operation mode is in ON with theelectrical parking switch is pressed.zThe electric tailgate is completely open.zPeople, luggage, etc., are not touching thesensors.
zDo not start the engine while the tailgate isoperating. The sudden operation preventionmechanism could operate, making the elec-tric tailgate stop intermittently while itmoves.NOTE
zThe electric tailgate cannot be opened whenthe battery is flat or disconnected.If you want to open the electric tailgate, itcan be opened by using the inside tailgaterelease.Refer to “Inside tailgate release” on page4-24.zIf the keyless entry system or close switch isoperated when the electric tailgate powerswitch is off, the warning buzzer sounds 4times to notify the driver that the electrictailgate cannot be operated.zThe electric tailgate does not operate nor-mally under the following conditions:•When parked on an incline•In strong winds•When the electric tailgate is covered withsnow
zRepeated continuous operation betweenopening and closing the electric tailgate willactivate the built-in protection circuit andswitch the tailgate to manual operation.CAUTION
zIf the electric tailgate handle is operatedwhile the tailgate is operating or immedi-ately after it is closed, the tailgate will movein the direction opposite to the one in whichit was operating.zIf the battery or fuse is replaced while theelectric tailgate is open, it cannot be closedautomatically.In this case close the electric tailgate manu-ally.
Operating conditions
NOTE
