Supplemental restrain
t system (SRS)-airbag
5-26 Seat and seat belts
5
Because the front airbags and driver’s kneeairbag may deploy in certain types of unex-pected impacts as shown in the illustrationthat can easily move you out of position, it isimportant to always properly wear your seatbelts. Your seat belts will help keep you a safedistance from the steering wheel and instru-ment panel during the initial stages of airbagdeployment. The initial stage of airbag infla-tion is the most forceful and can possiblycause serious or fatal injuries if you contact itat this stage.
WA R N I N GzDo not attach anything to the steeringwheel’s padded cover, such as badges oraccessories. It might strike and injure anoccupant if the airbag inflates.zDo not set anything on, or attach anythingto, the instrument
panel above the glove
box. It might strike and injure an occu-pant if the airbag inflates.
WA R N I N GzDo not attach accessories to, or put themin front of, the windscreen. These objectscould restrict the airbag inflation, orstrike and injure an occupant if the air-bags inflate.zDo not attach accessories to the lower por-tion of the driver’s side instrument panel.Such objects could prevent the driver’sknee airbag from infl
ating normally or
could be propelled to cause serious injuryif the airb
ag inflates.
WA R N I N GzDo not put packages, pets or other objectsbetween the airbags
and the driver or
front passenger. It could affect airbag per-formance, or could cause injury when theairbag inflates.zRight after the airbag inflation, severalairbag system components will be hot. Donot touch these components. There is adanger of being burnt.zThe airbag system is designed to workonly once. Once
the airbags have
deployed, they will not work again. Theymust promptly be replaced and we recom-mend you to have the entire airbag systeminspected by a MITSUBISHI MOTORSAuthorised Service Point.
BK0203201EN.book 26 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Supplemental restraint system (SRS)-airbag
Seat and seat belts 5-27
5
E00407600619
The side airbags (A) are contained in thedriver and front passenger seatbacks.The side airbag is designed to inflate only onthe side of the vehicle that is impacted, evenwith no passenger in the front seat.The label shown here is attached to the seat-backs with a side airbag.
E00409101686
The curtain airbags are contained in the frontpillars and roof side rail. The curtain airbag isdesigned to inflate only on the side of thevehicle that is impacted, even with no passen-ger in the front seat or rear seat.
E00407702513
The side airbags and curtain airbags aredesigned to deploy when the vehicle suffers a
moderate to severe side impact to the middleof the passenger compartment.The typical condition is shown in the illustra-tion.The seat belts in your vehicle are your pri-mary means of protection in a collision. TheSRS side airbags and curtain airbags aredesigned to provide additional protection.Therefore, for your safety and the safety of alloccupants, be sure to always properly wearyour seat belts.With certain types of side collisions, the vehi-cle’s body structure is designed to absorb theshock to help protect the occupants fromharm. (The vehicle body’s side area maydeform significantly as it absorbs the impact.)
Side airbag system
Curtain airbag system Deployment of side airbags and curtain airbags The side airbags and curtain air-bags ARE DESIGNED TO DEPLOY when...
The side airbags and curtain air-bags MAY NOT DEPLOY when...
BK0203201EN.book 27 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Supplemental restrain
t system (SRS)-airbag
5-28 Seat and seat belts
5
Under such circumstances, the side airbagsand curtain airbags may not deploy irrespec-tive of the deformation and damage to thevehicle body. Examples of some typical con-ditions are shown in the illustration.
Because the side airbags and curtain airbagsdo not protect the occupant in all types of sidecollisions, be sure to always properly wearyour seat belts.The side airbags and curtain airbags are notdesigned to deploy in conditions where theycannot usually provide protection to the occu-pant. Typical conditions are shown in theillustration.
Because the side airbags and curtain airbagsdo not protect the occupant in all types of col-lisions, be sure to always properly wear yourseat belts.
1- Side impacts in an area away from the
passenger compartment
2- Motorcycle or other similar small vehi-
cle collides with the side of vehicle
3- Collision with a utility pole, tree or
other narrow object
4- Oblique side impacts5- Vehicle rolls onto its side or roofThe side airbags and curtain air-bags ARE NOT DESIGNED TO DEPLOY when...
1- Head-on collisions2- Rear end collisionsWA R N I N GzThe side airbags and curtain airbags aredesigned to supplement the driver andpassenger seat belts in certain sideimpacts. Seat belts should always be wornproperly, and the driver and passengershould sit well back and upright withoutleaning against the window or door.
BK0203201EN.book 28 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Supplemental restraint system (SRS)-airbag
Seat and seat belts 5-29
5
zThe side airbag and cu
rtain airbag inflate
with great force. The driver and passengershould not put their arms out the window,and should not lean against the door, inorder to reduce risk of serious or possiblefatal injury from the
deploying side airbag
and curtain airbag.WA R N I N GzDo not allow any rear seat occupant tohold onto the seatback
of either front seat,
in order to reduce risk of injury from thedeploying side airbag. Special care shouldbe taken with children.zDo not place any objects near or in frontof the seatback of either front seat. Theycould interfere with proper side airbaginflation, and also could cause injury ifthrown free by side airbag deployment.WA R N I N G
zDo not place stickers, labels or additionaltrim on the seatback of either front seat.They could interfere with proper side air-bag inflation.zDo not install seat covers on seats withside airbags.Do not re-cover seats
that have side air-
bags. This could interfere with proper sideairbag inflation.zDo not attach a microphone (A) or anyother device or object around the partwhere the curtain airbags (B) activatesuch as on the windsc
reen, side door glass,
front and rear pillars and roof side orassist grips. When
the curtain airbags
inflate, the microphone or other device orobject will be hurled with great force orthe curtain airbags may not activate cor-rectly, resulting in death or serious injury.WA R N I N G
WA R N I N GzDo not put a hanger or any heavy orpointed object on the
coat hook. If the cur-
tain airbag was activated, any such itemcould be propelled away with great forceand could prevent the curtain airbag frominflating correctly. Hang clothes directlyon the coat hook (without using a hanger).Make sure there are no heavy or sharpobjects in the pockets of clothes that youhang on the coat hook.zDo not allow the child
to lean against or
close to the front door even if the child isseated in a child restraint system.The child’s head should
also not be leaned
against or be close to the area where theside airbag and curtai
n airbag are located.
It is dangerous if the side airbag and cur-tain airbag inflate.Failure to follow all of these instructionscould lead to serious or fatal injury to thechild.zWe rec ommend wor k around and on theside airbags and curtain airbags system tobe done by a MITSUBISHI MOTORSAuthorised Service Point.
BK0203201EN.book 29 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Supplemental restrain
t system (SRS)-airbag
5-30 Seat and seat belts
5
E00407802673
There is a supplemental restraint system(“SRS”) warning lamp on the instrumentpanel. The system checks itself every time theoperation mode of the power switch is put inON. The SRS warning lamp will come on forseveral seconds and then go out. This is nor-mal and means the system is working prop-erly.If there is a problem involving one or more ofthe SRS components, the warning lamp willcome on and stay on. At the same time, thewarning display will appear on the informa-tion screen in the mu
lti information display.
The SRS warning lamp/display is shared bythe SRS airbag and the seat belt pre-tensionersystem.
E00407901619
SRS warning lamp/display
WA R N I N GzIf any of the following conditions occur,there may be a problem with the SRS air-bags and/or seat belt
pre-tensioners, and
they may not function
properly in a colli-
sion or may suddenly
activate without a
collision:•Even when the operation mode is in ON,the SRS warning lamp does not come onor it remains on.• The SRS warning lamp and/or the warn-ing display comes on while driving.The SRS airbags and seat belt pre-ten-sioners are designed to help reduce therisk of serious injury
or death in certain
collisions. If either of the above conditionsoccurs, immediately
have your vehicle
checked by a MITSUBISHI MOTORSAuthorised Service Point.
SRS servicing
WA R N I N GzWe re commend any main tenanc e per-formed on or near the components of theSRS to be performed by a MITSUBISHIMOTORS Authorised Service Point.Improper work on the SRS components orwiring could result in inadvertent deploy-ment of the airbags,
or could render the
SRS inoperative; either situation couldresult in serious injury.
zDo not modify your steering wheel, seatbelt retractor or any other SRS compo-nents. For example, replacement of thesteering wheel, or modifications to thefront bumper or body structure (forexample fitment of a frontal protectionbar, including roo bars and bull barsexcept approved MITSUBISHI MOTORSGENUINE accessory parts) can adverselyaffect SRS performance and lead to possi-ble injury.zIf your vehicle has received any damage,we recommend you to have the SRSinspected to ensure it is in proper workingorder.zDo not modify your front seats, centre pil-lar and centre console.It can adversely affect SRS performanceand lead to possible injury.zIf you found any tear, scratch, crack ordamage to the portion where the airbag isstored, you should h
ave the SRS inspected
by a MITSUBISHI MOTORS AuthorisedService Point.NOTE
zIf your vehicle has to be scrapped, do this inline with local legislation and contact a MIT-SUBISHI MOTORS Authorised ServicePoint to safely dismantle the airbag system.WA R N I N G
BK0203201EN.book 30 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

6
Instruments and controlsInstruments .......................................................................................6-2Multi information display ................................................................. 6-3Indicator lamp, warning lamp, and information screen display list.....................................................................................................6-21Indicator lamps ...............................................................................6-36Wa r n i n g l a m p s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3 7Information screen display .............................................................6-39Combination headlamps and dipper switch ....................................6-40Headlamp levelling .........................................................................6-44Turn-signal lever ............................................................................. 6-45Hazard warning flasher switch .......................................................6-45ECO mode switch ..........................................................................6-46Fog lamp switch .............................................................................6-46Wi p er and w ashe r sw it ch .. . . .. . .. . . .. . . .. . .. . . .. . . .. . .. . . .. . .. . . .. . . .. . .. . . .. . . .. . .. . . . 6- 4 7Wi p er dei ce r sw it ch * .. . .. . . .. . . .. . .. . . .. . . .. . .. . . .. . . .. . .. . . .. . .. . . .. . . .. . .. . . .. . . .. . .. . . . 6- 5 3Rear window demister switch.........................................................6-53Horn switch.....................................................................................6-54
BK0203201EN.book 1 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Instruments6-2 Instruments and controls
6
E00500102447E00537800028
Indicates the total power of the motors andengine during driving.
Indicates the charging power generated by theregenerative brake.The more the needle reflects, the more elec-tric energy is charged.The needle of the energy usage indicator maynot enter the charge zone when the drive bat-tery is close to full charge.
E00531301044
Each time you press the rheostat illuminationbutton, there is a sound and the brightness ofthe instruments changes.
Instruments 1- Energy usage indicator
m P.6-2
2- Multi information display
m P.6-3
Information screen display list m P.6-22
3- Speedometer (km/h or mph + km/h)4- Rheostat illumination button
m P.6-2
Energy usage indicator Eco/Power zone
Charge zone Meter illumination control Eco/Power zoneCharge zone
1- Brightness level2- Rheostat illumination button
NOTE
zYo u c a n a d j u s t t o 8 d i f f e r e n t l e v e l s r e s p e c -tively for when the position lamps are illumi-nated and when they are not.zIf the vehicle is equipped with the automaticlamp control, when the lamp switch is in aposition other than the “OFF” position, themeter illumination switches automatically tothe adjusted brightness, depending on thebrightness outside the vehicle.zThe brightness level of the instruments isstored when the operation mode of the powerswitch is put in OFF.
BK0203201EN.book 2 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display
Instruments and controls 6-3
6
E00519902119
Always stop the vehicle in a safe place beforeoperating.The following information is included on themulti information display: warnings, odome-ter, tripmeter, average fuel consumption, EVcruising range, total cruising range, EVHVdriving rate, energy flow, etc.[When the operation mode of the powerswitch is OFF]zIf you press and hold the button for about 2seconds or more when the position lamps areilluminated, the brightness level changes tothe maximum level. Pr
