Multi information display6-20 Instruments and controls
6
1. Press and hold the multi information dis-play switch for about 2 seconds or more toswitch from the setting mode screen to themenu screen.Refer to “Changing the function settings”on page 6-15.2. Lightly press the multi information dis-play switch to select “ALARM” (rest timesetting).3. Press and hold the multi information dis-play switch for about 2 seconds or more todisplay “ALARM”.4. Lightly press the multi information dis-play switch to select the time until the dis-play.5. Press and hold the multi information dis-play switch for about 2 seconds or more,the setting is changed to the selected time.
E00529100396
It is possible to change the turn-signal sound.
1. Press and hold the multi information dis-play switch for about 2 seconds or more toswitch from the setting mode screen to themenu screen.Refer to “Changing the function settings”on page 6-15.2. Lightly press the multi information dis-play switch to select (changing theturn-signal sound).3. Press and hold the multi information dis-play switch for about 2 seconds or more toswitch from 1 (turn-signal sound 1) to 2(turn-signal sound 2), or from 2 to 1.The setting changes to the selected turn-signal sound.
E00523601875
All of the function settings can be returned totheir factory settings.1. Press and hold the multi information dis-play switch for about 2 seconds or more toswitch from the setting mode screen to themenu screen.Refer to “Changing the function settings”on page 6-15.2. Lightly press the multi information dis-play switch to select “RESET” (returningto the factory settings).
3. When you press and hold the multi infor-mation display switch for about 5 secondsor more, the buzzer sounds and all of thefunction settings are returned to the fac-tory settings.
NOTE
zThe drive time is reset when the operationmode of the power switch is put in OFF.
Changing the turn-signal sound
Returning to the factory settings
NOTE
zThe factory settings
are as follows.
•Average fuel consum
ption reset mode: A
(Auto reset)•Fuel consumption display unit: L/100 km•Temperature unit: °C (Celsius)•Display language: ENGLISH or RUSSIAN•Cooperative language
setting: A (language
cooperation enabled)•Operation sounds: ON
(Operation sounds
on)•“REST REMINDER” display: OFF•Turn-signal sound: Turn-signal sound 1
BK0203201EN.book 20 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Indicator lamp, warning lamp, and information screen display list
Instruments and controls 6-21
6
E00523701182E00523802034
Indicator lamp, warning lamp, and information screen display list Indicator and warning lamp list 1- Position lamp indicator lamp
m P. 6-37
2- Front fog lamp indicator lamp
m P. 6-37
3- Turn-signal indicator lamps/Hazard
warning indicator lamps
m P. 6-36
4- Rear fog lamp indicator lamp
*
m P. 6-37
5- High-beam indicator lamp
m P. 6-37
6- Plug-in Hybrid EV System warning
lamp
m P. 6-39
7- Auxiliary battery charge warning lamp
m P. 6-39
8- Charging indicator
m P. 6-37
9- Regenerative brake warning lamp
m P. 6-39
10- Ready indicator
m P. 6-37
11- Acoustic Vehicle Alerting System
(AVAS) OFF indicator lamp
m P. 7-24
12- Active Stability Control (ASC) indica-
tor lamp
m P. 7-34
13- Active Stability Control (ASC) OFF
indicator lamp
m P. 7-34
14- Anti-lock brake system (ABS) warning
lamp
m P. 7-30
15- Supplemental restraint system (SRS)
warning lampm P. 5-30
16- Check engine warning lamp
m P. 6-38
17- Seat belt warning lamp
m P. 5-11
18- Brake warning lamp
m P. 6-37
BK0203201EN.book 21 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Indicator lamp, warning lamp, and information screen display list6-22 Instruments and controls
6
E00523901344
When there is information to be announced, such as lamp reminder, the buzzer sounds and the screen switches to the displays sho
wn below. Refer
to the appropriate page and take the necessary measures.When the cause of the warning display is eliminated, the warning display goes out automatically.Refer to “Warning display list” on page 6-22.Refer to “Navigation information display” on page 6-32.Refer to “Other interrupt displays” on page 6-33.
E00524001993
19- Information screen display list
m P. 6-22
Information screen display list
NOTE
zA warning may be displayed on the in
formation screen and the buzzer ma
y sound in the following rare cases.
This is caused by the system picking up inte
rference such as noise or strong electromagnetic waves, and is not a functional pro
blem.
•An extremely strong electromagnetic wave is received from a source such as an illegal radio set, a spark from a wire, or a rad
ar station.
•Abnormal voltage or a static electricity
discharge is generated by th
e operation of installed elect
rical equipment (including
after-market parts).
If the warning display appears many times,
we recommend you to consult a MITSUBISHI MOTORS Authorised Service Point.
Warning display li st
Screen
Cause
Solution (Reference)
zOne or more minor failure is occurring in the Plug-in Hybrid EV System.
zHave your vehicle inspected by a MIT-SUBISHI MOTORS Authorised Service Point.
BK0203201EN.book 22 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Indicator lamp, warning lamp, and information screen display list
Instruments and controls 6-23
6
zOne or more failure is occurring in the Plug-in Hybrid EV System.
zImmediately park the vehicle in a safe place and contact a MITSUBISHI MOTORS Authorised Service Point.
zThe parking lock unit is in failure. The Plug-in Hybrid EV system cannot be kept in standstill condition without applying the parking brake.
zPark the vehicle at a safe, flat place and apply the parking brake. Contact a MIT-SUBISHI MOTORS Authorised Service Point.Refer to “Electrical parking switch” on page 7-16.
zYo u a r e a t t e m p t i n g t o s e t t h e o p e r a t i o n mode to “ON” when the charge connector is connected to the charge port.
zDisconnect the charge connector from the charge port before operating the power switch.
zCharging was interrupted due to system failure (electric leak detected).
zThere is an electric leak or the normal charge cable is faulty. Immediately stop using the cable and contact a MITSUBI-SHI MOTORS Authorised Service Point.
zCharging was interrupted due to poor con-nection of the charge cable or power fail-ure.
zConnect the charge cable correctly.Refer to “Normal charging” on page 3-8.zIf charging is interrupted due to a power failure, charging will be automatically resumed when the power is restored.
Screen
Cause
Solution (Reference)
BK0203201EN.book 23 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Indicator lamp, warning lamp, and information screen display list6-24 Instruments and controls
6
zThe drive battery temperature is too cold.
zWhen the vehicle is under running, stop the vehicle at a safe place and contact a MIT-SUBISHI MOTORS Authorized Service Point.zWhen the vehicle is in parking, in the day-time, wait for the outside temperature to rise and re-start the Plug-in hybrid system if the outside temperature has been risen.Refer to “Cautions and actions to deal with intense cold” on page 2-9.
zYo u h a v e f o r g o t t e n t o t u r n o f f t h e l a m p s . R e f e r t o “ L a m p s ( h e a d l a m p s , f o g l a m p , e t c . )
auto-cutout function” on page 6-40.
zThere is a fault in the keyless operation system.
Refer to “Keyless operation system” on page 4-6.
Screen
Cause
Solution (Reference)
BK0203201EN.book 24 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Indicator lamp, warning lamp, and information screen display list
Instruments and controls 6-25
6
zThe keyless operation key is not detected.
zInsert the keyless operation key into the key slot.Refer to “If the keyless operation key is not operating properly” on page 7-13.
zYo u h a v e f o r g o t t e n t o r e m o v e t h e k e y l e s s operation key from the key slot.
zRemove the keyless operation key from the key slot.Refer to “Keyless operation key reminder” on page 7-13.
zThere is a fault in the EPS.
zHave the vehicle inspected by a MITSUBISHI MOTORS Authorised Ser-vice Point as soon as possible.Refer to “Electric power steering system (EPS)” on page 7-32.
zThe brake fluid level in the reservoir has fallen to a low level.zThere is a fault in the brake system.
zImmediately stop the vehicle in a safe place.We r e c o m m e n d y o u t o c o n s u l t a MITSUBISHI MOTORS Authorised Ser-vice Point.Refer to “Brake warning display” on page 6-39.
zWhen the brake pedal has been repeatedly depressed over a short period of time, the brake warning lamp may come on and the brake warning buzzer may sound, and this warning may be displayed.
zIf the this warning display is disappeared and brake warning lamp goes out and the buzzer stops a few seconds after stopping brake operation, there is no abnormality.
Screen
Cause
Solution (Reference)
BK0203201EN.book 25 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Indicator lamp, warning lamp, and information screen display list6-26 Instruments and controls
6
zThe RBS (regenerative brake system) can-not be used.
zWe recommend you to consult a MITSUB-ISHI MOTORS Authorised Service Point.
zThere is a fault in the ABS.
zAv o i d s u d d e n b r a k i n g a n d h i g h - s p e e d d r i v -ing, stop the vehicle in a safe place, and take corrective measures. Refer to “ABS warning” on page 7-30.
zOne of the doors or the tailgate is not com-pletely closed.The open door is displayed.
zClose the door or tailgate.Refer to “Door ajar warning display screen” on page 6-9.
zThe bonnet is open.
zClose the bonnet.Refer to “Bonnet” on page 11-3.
zThere is a fault in the electronic immobi-lizer (Anti-theft starting system).
zPut the operation mode in OFF, and then start the Plug-in Hybrid EV System again.If the warning is not cancelled, please con-tact a MITSUBISHI MOTORS Authorised Service Point.
Screen
Cause
Solution (Reference)
BK0203201EN.book 26 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Indicator lamp, warning lamp, and information screen display list
Instruments and controls 6-27
6
zAn attempt was made to open the driver’s door with the operation mode in any mode other than OFF.
