Indicator lamps6-36 Instruments and controls
6
The setting for rest interval can be changed.
E00501600100E00501701427
These indicator lamps blink inthe following situations.zWhen the turn-signal leveris moved to activate a turn-signal lamp.
Refer to “Turn-signal lever” on page 6-45.
zWhen the hazard warning flasher switchis pressed to activate the hazard warninglamps.Refer to “Hazard warning flasher switch”on page 6-45.
Screen
Solution
We r e c o m m e n d y o u t o h a v e i t c h e c k e d . R e f e r t o “ S e r v i c e r e m i n d e r ” f o r f u r t h e r d e t a i l s o n p a g e 6-11.
Screen
Solution
Stop the vehicle in a safe place, stop the Plug-in Hybrid EV system, and take a rest.Use this display as rough guide for taking rests during a long drive.The interval from the start of your trip until this message is displayed can be set.Refer to “Changing the time until “REST REMINDER” is displayed” on page 6-19.The display and buzzer alert the driver when the set time is reached. If you continue to drive without having a rest, the buzzer sounds about every 5 minutes to encourage you to take a rest.zIn the following cases, the time driven is reset and the display returns to the previous dis-play screen. After this, when the set time is reached again, the buzzer and display encourage you to take a rest.•The buzzer sounds 3 times.•Put the operation mode in OFF.• The multi information display switch is held for about 2 seconds or more.
Indicator lamps Tu r n - s i g n a l i n d i c a t o r lamps/Hazard warning indica-tor lamps BK0203201EN.book 36 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Warning lamps
Instruments and controls 6-37
6
zWhen the hazard warning lamps automat-ically activate due to sudden brakingwhile driving. (Vehicle equipped withemergency stop signal system)Refer to “Emergency stop signal system”on page 7-29.
E00501800173E00501901520
E00502000071E00508900173E00530101045
The ready indicator keepsflashing until Plug-in HybridEV System is activated. Whenthe Plug-in Hybrid EV Systemhas activated normally and the
vehicle becomes ready to run, the lamp stopsflashing and stays lit. Refer to “Starting thePlug-in Hybrid EV System” on page 7-12.If the indicator keeps flashing, the vehiclescan not drive.
E00530201020
This indicator flashes whenthe normal charging cable isconnected.After that, the lamp switchesto being illuminated when
charging starts and goes out when charging iscompleted.
E00502400147E00502503673
This lamp illuminates whenthe operation mode of thepower switch is put in ON,and goes off after a few sec-onds.
Always make sure that the lamp goes offbefore driving.With the operation mode in ON, the brakewarning lamp illuminates under the followingconditions:zWhen the parking brake has been applied.zWhen the brake fluid level in the reservoirfalls to a low level.zWhen the braking system is an abnormal-ity.
High-beam indicator lamp
This indicator lamp illumi-nates when the high beam isused.
Front fog lamp indicator lamp
This lamp illuminates whilethe front fog lamps are on.
Rear fog lamp indicator lamp
*
This lamp illuminates whilethe rear fog lamp is on.
Position lamp indicator lamp
This indicator lamp illumi-nates while the position lampsare on.
Ready indicator
Charging indicator Wa r n i n g l a m p s Brake warning lamp
BK0203201EN.book 37 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Warning lamps6-38 Instruments and controls
6
With the operation mode in ON, a buzzersounds under the following condition:zThe vehicle speed exceeds 8 km/h withthe parking brake applied.
E00502602938
This lamp is a part of anonboard diagnostic systemwhich monitors the emissions,engine control system.If a problem is detected in one
of these systems, this lamp illuminates orflashes.Although your vehicle will usually be driva-ble and not need towing, we recommend youto have the system checked as soon as possi-ble.This lamp will also illuminate when the oper-ation mode of the power switch is put in ON,and goes off after the Plug-in Hybrid EV Sys-tem has started. If it does not go off after thePlug-in Hybrid EV System has started, werecommend you to have the vehicle checked.
This data will be erased if a auxiliary batterycable is disconnected which will make a rapiddiagnosis difficult. Do not disconnect a auxil-iary battery cable when the check enginewarning lamp is ON.
CAUTIONzIn the situations listed below, brake perfor-mance may be compromised or the vehiclemay become unstable if brakes are appliedsuddenly; consequen
tly, avoid driving at
high speeds or applyi
ng the brakes suddenly.
Furthermore, immediately the vehicle shouldbe brought to a stop in
a safe location and we
recommend you to have it checked.•The brake warning lamp does not illumi-nate when the parking brake is applied ordoes not turn off when the parking brake isreleased.•The brake warning lamp and the ABSwarning lamp illuminate at the same time.For details, refer to “ABS warning lamp”on page 7-30.•The brake warning lamp remains illumi-nated while driving.
zThe vehicle should be brought to a halt in thefollowing manner when brake performancehas deteriorated.• Depress the brake pedal harder than usual.Even if the brake pedal moves down to thevery end of its possible stroke, keep itpressed down hard.
• Should the brakes fail, use regenerativebraking to reduce your speed and carefullypull the parking brake lever.Depress the brake pedal to operate the stoplamp to alert the vehicles behind you.
Check engine warning lamp
CAUTION
CAUTIONzProlonged driving with this lamp on maycause further damage to the emission controlsystem. It could also
affect fuel economy and
drivability.zIf the lamp does not illuminate when theoperation mode is put in ON, we recommendyou to have the system checked.zIf the lamp illuminates while the Plug-inHybrid EV System is
operating, avoid driv-
ing at high speeds and have the systeminspected by a MITSUBISHI MOTORSAuthorised Service Poin
t as soon as possible.
NOTE
zThe engine electronic control moduleaccommodating the onboard diagnostic sys-tem has various fault data (especially aboutthe exhaust emission) stored.
BK0203201EN.book 38 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Information screen display
Instruments and controls 6-39
6
E00502702287
This warning lamp will illu-minate when there is a prob-lem with the charging systemfor the auxiliary battery.Normally, when the operation
mode of the power switch is put in ON, thiswarning lamp will illuminate. Then, when thePlug-in Hybrid EV System is started and theready indicator illuminates, the warning lampwill go out.
E00537300023
This warning lamp will illu-minate when there is a fault atthe Plug-in Hybrid EV Sys-tem.Refer to “Service precautions”
on page 11-2.Normally, this warning lamp illuminateswhen the operation mode of the power switchis put in ON, and goes off after a few seconds.
E00537200022
This warning lamp will illu-minate when there can notused at the regenerative brakewhile the Plug-in Hybrid EVSystem is operating.
The warning is also displayed on the multiinformation display.
Normally, this warning lamp illuminateswhen the operation mode of the power switchis put in ON, and goes off after the Plug-inHybrid EV System is activated.
E00524601117E00524701381
This warning is displayed if you drive withthe parking brake still applied. The warninglamp in the instrument cluster only illumi-nates when the parking brake is applied.
Auxiliary battery charge warn-ing lamp
CAUTIONzIf the warning lamp stays on after the readyindicator illuminates, there may be a prob-lem with the charging system for the auxil-iary battery.•Immediately park your vehicle in a safeplace and we recommend you to have itchecked.•Do not charge the auxiliary battery.
Plug-in Hybrid EV System warning lamp
CAUTIONzIf the lamp illuminates while the Plug-inHybrid EV System is
operating, immediately
park your vehicle in a safe place and we rec-ommend you to consult a MITSUBISHIMOTORS Authorised Service Point.
Regenerative brake warning lamp
CAUTIONzIf the lamp illuminates while the Plug-inHybrid EV System is
operating, we recom-
mend you to have the vehicle inspected by aMITSUBISHI MOTORS Authorised ServicePoint.
Information screen display Brake warning display
BK0203201EN.book 39 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Combination headlamps and dipper switch6-40 Instruments and controls
6
When the operation mode of the powerswitch is put in ON, if the brake fluid is low,this warning is displayed.The warning lamp in the instrument clusteralso illuminates.
E00524901309
If the engine oil pressure drops while thePlug-in Hybrid EV System is operating, the
warning display is displayed on the informa-tion screen in the multi information display.
E00506003416
CAUTIONzIf a vehicle is driven without releasing theparking brake, the brake will be overheated,resulting in ineffectiv
e braking and possible
brake failure.If this warning is displayed, release the park-ing brake.CAUTIONzIf this warning stays illuminated and doesnot go out while driving, there is a danger ofineffective braking. If this happens, immedi-ately park your vehicle in a safe place andwe recommend you to have it checked.
zIf the brake warning disp
lay is displayed and
the brake warning lamp and the ABS warn-ing lamp are illuminated at the same time,the braking force dist
ribution function will
not operate, so the vehicle may be destabi-lised during sudden braking. Avoid suddenbraking and high-speed driving, stop thevehicle in a safe place, and we recommendyou to have it checked.zThe vehicle should be brought to a halt in thefollowing manner when brake performancehas deteriorated.•Depress the brake pedal harder than usual.Even if the brake pe
dal moves down to the
very end of its possible stroke, keep itpressed down hard.• Should the brakes fail, use regenerativebrake to reduce your speed and carefullypull the parking brake lever.Depress the brake pedal to operate the stoplamp to alert the vehicles behind you.
Oil pressure warning display
CAUTION
CAUTIONzIf the vehicle is driven while the engine oil islow, or the oil level is normal but the warn-ing is displayed, the engine may burn out andbe damaged.zIf the warning is displayed while the Plug-inHybrid EV System is operating, immediatelypark your vehicle in a safe place and checkthe engine oil level.zIf the warning is disp
layed while the engine
oil level is normal, have it inspected.
Combination headlamps and dipper switch Headlamps
NOTE
zDo not leave the lights on for a long timewhile the Plug-in Hybrid EV System is sta-tionary (not operating). A run-down auxil-iary battery could result.
BK0203201EN.book 40 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Combination headlamps and dipper switch
Instruments and controls 6-41
6
Rotate the switch to turn on the lamps.
Rotate the switch to turn on the lamps.
zWhen it rains, or when the vehicle has beenwashed, the inside of the lens sometimesbecomes foggy, but this does not indicate afunctional problem.When the lamp is swit
ched on, the heat will
remove the fog. However, if water gathersinside the lamp, we recommend you to havechecked.
Ty p e 1 OFF All lamps off
Position, tail, licence plate, instru-ment panel lamps and downlight onHeadlamps and other lamps go onNOTE
Ty p e 2 OFF All lamps offAUTO
With the operation mode of the power switch is in ON, head-lamps, position, tail, licence plate, instrument panel lamps and down-light turn on and off automatically in accordance with outside light level. All lamps turn off automati-cally when the operation mode is put in OFF.

Position, tail, licence plate, instru-ment panel lamps and downlight onHeadlamps and other lamps go on
NOTE
zThe sensitivity of the automatic on/off con-trol can be adjusted. For further information,contact a MITSUBISHI MOTORS Author-ised Service Point.On vehicles equipped
with Mitsubishi Multi-
Communication System (MMCS), screenoperations can be used to make the adjust-ment.Refer to the separate owner’s manual fordetails.zIf the front fog lamps turn on when they aresupposed to with the
switch in the “AUTO”
position, the lamps turn off automaticallywith operation mode off.zDo not cover the sensor (A) for the automaticon/off control by affixing a sticker or label tothe windscreen.zIf the lamps do not turn on or off with theswitch in the “AUTO”
position, manually
operate the switch and we recommend you tohave your vehicle checked.
BK0203201EN.book 41 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Combination headlamps and dipper switch6-42 Instruments and controls
6
zIf the operation mode of the power switchis put in OFF or ACC while the lampswitch is in the “ ” or “ ” position,the lamps will turn off automaticallywhen the driver"s door is opened.zIf the operation mode of the power switchis put in OFF or ACC while the lampswitch is in the “ ” or “ ” position,the lamps will remain on for about 3 min-utes while the driver’s door is shut andwill then automatically turn off.
1. Turn the lamp switch in the “OFF” posi-tion while the operation mode of thepower switch is in OFF or ACC.2. Turn on the lamps with the switch in the“ ” or “ ” position again, then thelamps will remain on.3. When 1 minute has passed, the lamps willautomatically be turned off.
E00506101631
If the driver’s door is opened when the opera-tion mode of the power switch is put in ACCor OFF with the lamps illuminated, a buzzerwill sound to remind the driver to turn off thelamps.The buzzer will automatically stop if theauto-cutoff function is activated, the lampswitch is turned off, or the door is closed.
E00506201544
When the lamp switch is in the “ ” posi-tion, the beam changes from high to low (orlow to high) each time the lever is pulledfully (1). While the high beam is on, the highbeam indicator lamp in the instrument clusterwill also illuminate.
E00506300199
The high beams flash when the lever is pulledslightly (2), and will go off when it isreleased.When the high beam is on, the high beamindicator lamp in the instrument cluster willilluminate.
Lamps (headlamps, fog lamp, etc.) auto-cutout function
NOTE
zThe lamp auto-cutout function can also bedisabled.For further information, we recommend youto consult a MITSUBISHI MOTORSAuthorised Service Point.On vehicles equipped
with Mitsubishi Multi-
Communication System (MMCS), screenoperations can be used to make the adjust-ment. Refer to the separate owner’s manualfor details.
When you want to keep the lamps on:
NOTE
zIf you place the light switch in the “ ”position, the lamps will not be automaticallyturned off.
Lamp monitor buzzer
Dipper (High/Low beam change) Headlamp flasher
BK0203201EN.book 42 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Combination headlamps and dipper switch
Instruments and controls 6-43
6
E00528901600
This function turns on the position and taillamps for about 30 seconds after theUNLOCK switch on the remote control trans-mitter is pressed when the combination head-lamps and dipper switch is in the “OFF” or“AUTO” position (for vehicles equipped withthe automatic lamp control). On vehiclesequipped with the automatic lamp control(except for vehicles equipped with LDW), thewelcome light function will operate onlywhen it is dark outside the vehicle.
E00529001549
This function turns on the headlamps in thelow beam setting for about 30 seconds afterthe operation mode is put in OFF.1. Turn the combination headlamps and dip-per switch to the “OFF” or “AUTO” posi-tion (for vehicles equipped with theautomatic lamp control).2. Put the operation mode of the powerswitch in OFF.
3. Within 60 seconds of putting the opera-tion mode in OFF, pull the turn signallever towards you.4. The headlamps will come on in the lowbeam setting for about 30 seconds. Afterthe headlamps go off, the headlamps canbe turned on again in the low beam settingfor about 30 seconds by pulling the turnsignal lever towards you within 60 sec-onds of putting the operation mode inOFF.To t u r n o n t h e h e a d l a m p s a g a i n a f t e r 6 0seconds of putting the operation mode inOFF, repeat the process from step 1.
NOTE
zThe high beams can also flash when the lampswitch is OFF.zIf you turn the lamps off with the headlampsset to highbeam, the headlamps are automati-cally returned to their low-beam settingwhen the lamp switch is next turned to the“” position.
We l c o m e l i g h t
NOTE
zWhile the welcome light function is operat-ing, perform one of the following operationsto cancel the function.•Push the LOCK switch on the remote con-trol transmitter.
•Turn the combination headlamps and dip-per switch to the “ ” or “ ” position.•Put the operation mode of the power switchin ON.
zIt is possible to modify
functions as follows:
•The headlamps can be set to come on in thelow beam setting.•The welcome light function can be deacti-vated.For further information, please contact yourMITSUBISHI MOTORS Authorised ServicePoint.On vehicles equipped
with Mitsubishi Multi-
Communication System (MMCS), screenoperations can be used to make the adjust-ment. Refer to the separate owner’s manualfor details.
Coming home light
NOTE
NOTE
zWhile the coming home light function isoperating, perform one of the followingoperations to cancel the function.•Pull the turn signal lever towards you.
