2014 MITSUBISHI OUTLANDER SPORT Owners Manual

Automatic climate control air conditioner8-4 For pleasant driving
8
E00702401436
Cooling or heating can only be performed when ready indicator is illuminating. When the operation mode is ON, only the blower i
s available.
E00702502476
Automatic climate control air conditioner
NOTE
zIf the drive battery level display indicates 0, the cooling performance cannot be obtained even the air conditioner is turned o
n.
Refer to “Drive battery leve
l display screen” on page 6-9.
zIf the engine cannot be started
due to fuel shortage, etc., the heating perform
ance cannot be obtained even the air conditioner
is turned on.
Control panel Dual-zone automatic climate control air conditioner1- Passenger’s side temperature control
switch
2- Air conditioning switch
3- Blower speed selection switch4- MODE switch
5- Driver’s side temperature control
switch
6- Air selection switch
BK0203201EN.book 4 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Automatic climate control air conditioner
For pleasant driving 8-5
8
E00702801371
Press of the blower speed selectionswitch to increase the blower speed.Press of the blower speed selectionswitch to decrease the blower speed.The selected blower speed will be shown inthe display (A).
E00703001673
Press or of the temperature controlswitch to the desired temperature.The selected temperature will be shown in thedisplay (A).
7- Demister switch8- AUTO switch9- Rear window demister switch
m P.6-53
10- OFF switch11 - P assen ge r ’s side tem pera tu re disp la y
m P.8-5
12- DUAL indicator13- Mode selection display14- Driver’s side temperature display
m P.8-5
15- Air conditioning indicator16- Blower speed display
NOTE
zThere is an interior air temperature sensor(A) in the illustrated position.Never place anything on
top of the sensor,
since doing so will prevent it from function-ing properly.zSince the air conditioning operation is con-trolled while the ECO mode is operating,you may feel that effectiveness of the airconditioner is weak.m ECO mode switch P.6-46
zEven if the ECO mode is operating, you canselect normal operation of the air condi-tioner.On vehicles equipped
with Mitsubishi Multi-
Communication System (MMCS), screenoperations can be used to change the setting.Refer to the separate
owner’s manual for
details.zIn extreme cold, the air conditioning controlpanel screen may operate sluggishly. Thisdoes not indicate a problem.It will disappear when the vehicle interiortemperature rises to
a normal temperature.
zA sound will be made every time you pushall the switches.
Blower speed selection switch
NOTE
1- Increase2- DecreaseTe m p e r a t u r e c o n t r o l s w i t c h
BK0203201EN.book 5 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Automatic climate control air conditioner8-6 For pleasant driving
8
The settings described above are the factorysettings.The air selection and air conditioningswitches can be customised (function settingchanged), and the automatic switching of out-side air and the air conditioner according tooperating conditions can be changed asdesired.For further information, we recommend youto consult a MITSUBISHI MOTORS Author-ised Service Point.Refer to “Customising the air conditioningswitch” on page 8-8.Refer to “Customising the air selection” onpage 8-7.The driver’s side and the passenger’s sidetemperature can be controlled independently.At this time, the “DUAL” indicator will beshown in the display (A).
zSynchronized modeIf the driver’s side temperature controlswitch is pressed, the passenger’s sidetemperature will also be controlled to thesame setting temperature as the driver’sside.zDual modeIf the passenger’s side temperature con-trol switch is pressed under synchronizedmode, the system will switch to dualmode. In dual mode, the driver’s side andthe passenger’s side temperature can beset separately by using each temperaturecontrol switch.Press the AUTO switch to return to syn-chronized mode.
E00703401808
To change the air selection, simply press theair selection switch.
NOTE
zThe temperature value of air conditioner isswitched in conjunction
with outside temper-
ature display unit of the multi informationdisplay.Refer to “Changing the temperature unit” onpage 6-17.zWhile the engine coolant temperature is low,the temperature of th
e air from the heater
will not change instantly, even if you haveselected warm air with the switch.To p r e v e n t t h e w i n d s c r e e n a n d w i n d o w sfrom fogging up, the ventilator mode will bechanged to “ ” and the blower speed willbe reduced while the system is operating inthe AUTO mode.zWhen you feel that it is hot or cold to the set-ting temperature, it is possible to adjust sothat you can feel more comfortable.For further information, we recommend youto consult a MITSUBISHI MOTORSAuthorised Service Point.zWhen the temperature is set to the highest orthe lowest, the air selection and the air condi-tioner will be automatically changed as fol-lows.Also, if the air selec
tion is operated manually
after an automatic changeover, manual oper-ation will be selected.•Quick Heating (When the temperature is setto the highest setting)Outside air will be introduced and the airconditioner will stop.
•Quick Cooling (When the temperature is setto the lowest setting)Inside air will be r
ecirculated and the air
conditioner will operate.
zWhen the air conditioner is set to quick heat-ing, the engine starts
running (except vehi-
cles with electric heater).

Automatic climate control air conditioner
For pleasant driving 8-7
8
zOutside air: Indicator lamp (A) is OFFOutside air is introduced into the passen-ger compartment.zRecirculated air: Indicator lamp (A) is ONAir is recirculated inside the passengercompartment.
E00739600022
Functions can be changed as desired, asstated below.
zEnable automatic air controlWhen the AUTO switch is pressed, the airselection switch is also controlled auto-matically.zDisable automatic air controlEven when the AUTO switch is pressed,the air selection switch is not controlledautomatically.zSetting change methodHold down the air selection switch forabout 10 seconds or more.•When the setting is changed from enableto disable3 sounds are emitted and the indicatorlamp flashes 3 times.•When the setting is changed from disa-ble to enable2 sounds are emitted and the indicatorlamp flashes 3 times.On vehicles equipped with MitsubishiMulti-Communication System (MMCS),screen operations can also be used tochange the setting. Refer to the separateowner’s manual for details.
CAUTIONzUse of the recirculation position for anextended time may cause the windows to fogup.
NOTE
zNormally, use the outside position to keepthe windscreen and side windows clear andquickly remove fog or frost from the wind-screen.If high cooling performance is desired, or ifthe outside air is dusty
or otherwise contami-
nated use the recirculation position. Switchto the outside position periodically toincrease ventilation so that the windows donot become fogged up.zWhen the engine coolant temperature rises toa certain level, the air selection is automati-cally switched to the recirculation positionand the indicator lamp (A) comes on. At thistime, the system will not switch to the out-side position even if the air selection switchis pushed.zWhen the outside air temperature is high, thesystem will not switch to the outside positioneven the air selection switch is pressed if theair conditioner is operating. This is to protectthe air conditioner compressor and is not afailure.

Automatic climate control air conditioner8-8 For pleasant driving
8
E00702600037
When the AUTO switch is pressed, the indi-cator lamp (A) comes on and the mode selec-tion (except for “ ”), blower speedadjustment, recirculated/outside air selection,temperature adjustment, and air conditionerON/OFF status are all controlled automati-cally.
E00703502327
Push the switch to turn the air conditioner on,the “ ” indicator will be shown in the dis-play (A).Push the switch again to switch it off.
E00739700023
Functions can be changed as desired, asstated below.zEnable automatic air conditioning controlWhen the AUTO switch is pressed, or thetemperature control switch is set to theminimum temperature, the air condition-ing switch is controlled automatically.zDisable automatic air conditioning controlThe air conditioning switch is not con-trolled automatically as long as the airconditioning switch is not operated.zSetting change methodHold down the air conditioning switch forabout 10 seconds or more.•When the setting is changed from enableto disable3 sounds are emitted and the “ ” indi-cator flashes 3 times.•When the setting is changed from disa-ble to enable2 sounds are emitted and the “ ” indi-cator flashes 3 times.
zWhen the demister switch is pressed, inorder to prevent misting of the windows theventilator automatically switches to outsideair even if “Disable automatic air control” isset.
AUTO switch
NOTE
Air conditioning switch
NOTE
zIf a problem is detected in the air condition-ing system, the “ ” indicator blinks. Pressthe air conditioning switch once to turn it off,then once more to turn it back on. If the “ ”indicator does not blink for a while, there isnothing wrong. If it starts to blink again, werecommend you to have it checked.

Automatic climate control air conditioner
For pleasant driving 8-9
8
On vehicles equipped with MitsubishiMulti-Communication System (MMCS),screen operations can also be used tochange the setting. Refer to the separateowner’s manual for details.
E00702700038
Push the switch to turn off the air condition-ing system.
E00703300031
Each time the MODE switch is pressed, themode changes to the next one in the follow-ing sequence: “ ”
m “ ”
m “ ”
m
“”
m “ ”. The selected mode is shown
in the display (A). (Refer to “Mode selection”on page 8-2.)
E00703901063
When this switch is pressed, the modechanges to the “ ” mode. The indicatorlamp (A) will come on. The selected mode isshown in the display (B). (Refer to “Modeselection” on page 8-2.)
NOTE
zThe factory setting is “Enable automatic airconditioning control”.zWhen the demister switch is pressed, inorder to prevent misting of the windows theair conditioner operates automatically even if“Disable automatic air conditioning control”is set.
OFF switch
MODE switch Demister switch
NOTE
zWhen the demister switch is pressed, the airconditioning system automatically operatesand outside air (as oppos
ed to recirculated
air) is selected. This automatic switchingcontrol is carried out to prevent misting ofthe windows even if “D
isable automatic air
conditioning control” or
“Disable
automatic
air control” is set. (Refer to “Customising theair conditioning switch” on page 8-8, “Cus-tomising the air selec
tion” on page 8-7.)
zWhen the demister switch is pressed, theengine may start running (except vehicleswith electric heater).
BK0203201EN.book 9 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Automatic climate control air conditioner8-10 For pleasant driving
8
E00704102131
In normal conditions, use the system in theAUTO mode and follow these procedures:1. Push the AUTO switch.2. Set the temperature control switch to thedesired temperature.The mode selection (except for “ ”),blower speed adjustment, recircu-lated/outside air selection, temperatureadjustment, and air conditioner ON/OFFstatus are all controlled automatically.
E00704200239
Blower speed and ventilator mode may becontrolled manually by setting the blowerspeed selection switch and the MODE switchto the desired positions.To r e t u r n t o a u t o m a t i c o p e r a t i o n , p r e s s t h eAUTO switch.
E00704301947
1. Set the air selection switch to the outsideposition.2. Set the MODE switch to the “ ” posi-tion.3. Select your desired blower speed bypressing the blower speed selectionswitch.4. Select your desired temperature by press-ing the temperature control switch.5. Push the air conditioning switch.
Operating the system in auto-matic mode
NOTE
zIf the blower speed selection switch, air con-ditioning switch, Mode switch, or air selec-tion switch is operated while the system isoperating in the AUTO mode, the activatedfunction overrides th
e corresponding func-
tion of automatic control. All other functionsremain under automatic control.
Operating the system in manual mode Demisting of the windscreen and door windows
CAUTIONzFor safety, make sure you have a clear viewthrough all the windows.

Important operation tips for the air conditioner
For pleasant driving 8-11
8
1. Push the demister switch to change to the“” position.2. Set the blower to the maximum speed.3. Set the temperature to the highest posi-tion.
E00704400127
When driving on a dirt road, adjust the venti-lation controls as follows:
1. Set the air selection switch to the outsideposition.2. Select the MODE switch to the desiredposition.3. Select the temperature control switch tothe desired position.4. Select the desired blower speed (thehigher the better).5. Ensure all windows are closed (to pressur-ise the cabin).
If you are driving behind another vehicle on adirt road and/or the outside air is dusty orcontaminated, set the air selection switch tothe recirculation position. During periods ofextended driving, ventilate the vehicle’s inte-rior by occasionally setting the switch fromthe recirculation to the outside position.
E00708302102
zPark the vehicle in the shade.Parking in the hot sun will make the vehi-cle inside extremely hot, and it willrequire more time to cool the interior.If it is necessary to park in the sun, openthe windows for the first few minutes ofair conditioning operation to expel the hotair.
zClose the windows when the air condi-tioner is in use. The entry of outside airthrough open windows will reduce thecooling efficiency.zTo o m u c h c o o l i n g i s n o t g o o d f o r t h ehealth. The inside air temperature shouldonly be 5 to 6 °C below the outside airtemperature.zWhen operating the system, make sure theair intake, which is located in front of thewindscreen, is free of obstructions such asleaves and snow. Leaves collected in theair-intake plenum may reduce air flowand plug the plenum water drains.zTo o m u c h c o o l i n g / h e a t i n g c a n a f f e c t t h eEV cruising range, so maintain an appro-priate temperature to extend the EV cruis-ing range.
If the air conditioner seems less effective thanusual, the cause might be a refrigerant leak.We r e c o m m e n d y o u t o h a v e t h e s y s t e minspected.The air conditioning system in your vehiclemust be charged with the refrigerant HFC-134a and the lubricant POE MA68EV.
