Bluetooth® 2.0 interface8-52 For pleasant driving
8
1. Press the SPEECH button.2. Say “Dial.”3. After the voice guide says “Numberplease,” say the telephone number.4. The voice guide will say “Dialing .”The Bluetooth
® 2.0 interface will then
make the call. When the confirmation function is on, thesystem will confirm the telephone numberagain. To continue with that number,answer “Yes.” To c h a n g e t h e t e l e p h o n e n u m b e r, a n s w e r“No.” The system will say “Numberplease” then say the telephone numberagain.
Yo u c a n m a k e c a l l s u s i n g t h e v e h i c l e p h o n e -book or mobile phonebook of the Bluetooth
®
2.0 interface.For details on the phonebooks, refer to“Phonebook function” on page 8-54.1. Press the SPEECH button.2. Say “Call.”3. After the voice guide says “Name please,”say the name you want to call, from thoseregistered in the phonebook.
4. If there is only 1 match, the system willproceed to Step 5.If there are 2 or more matches, the voiceguide will say “More than one match wasfound, would you like to call .” If that person is the one you wantto call, answer “Yes.”Answer “No,” the name of the nextmatching person will be uttered by thevoice guide.
NOTE
zIn the case of English, the system will recog-nise both “zero” and “oh”
(Letter “o”) for the
number “0.”zThe Bluetooth
® 2.0 interface supports num-
bers (0 to 9) and characters (+, # and
*).
zThe maximum supported telephone numberlength is as follows:•International telephone number: + and tele-phone numbers (to 18 digits).•Except for international telephone number:telephone numbers (to 19 digits).
Making a call using a phonebook
NOTE
zIf you say “Call” when the vehicle phone-book and the mobile phonebook are empty,the voice guide will say “The vehicle phone-book is empty. Would you like to add a newentry now?”Answer “Yes,” and the voice guide will say“Entering the phonebook - new entry menu.”Yo u c a n n o w c r e a t e d a t a i n t h e v e h i c l ephonebook.Answer “No,” the system will return to themain menu.
NOTE
zIf you say “No” to all names read by the sys-tem, the voice guide will say “Name notfound, returning to main menu” and the sys-tem will return to the main menu.
BK0203201EN.book 52 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Bluetooth® 2.0 interface
For pleasant driving 8-53
8
5. If only 1 telephone number is registeredunder the name you just said, the voiceguide will proceed to Step 6.If 2 or more telephone numbers are regis-tered that match the name you just said,the voice guide will say “Would you liketo call at [home], [work],[mobile], or [other]?” Select the locationto call.
6. The voice guide will say “Calling ” and then the system will dialthe telephone number.
Yo u c a n r e d i a l t h e l a s t n u m b e r c a l l e d , b a s e don the history of dialed calls in the paired cel-lular phone.Use the following procedure to redial. 1. Press the SPEECH button.2. Say “Redial.”
E00761300035
During a call, press the SPEECH button toenter voice recognition mode, then say“ SEND” to generate DTMFtones.For example, if during a call you need to sim-ulate the pressing of a phone button as aresponse to an automated system, press the
SPEECH button and speak “1 2 3 4 poundsend” and the 1234# will be sent via your cel-lular phone.
E00761601064
If an incoming phone call is received whilethe operation mode is in ON or ACC, theaudio system will be automatically turned onand switched to the incoming call, even whenthe audio system was originally off.The voice guide announcement for theincoming call will be output from the frontpassenger’s seat speaker.If the CD player or radio was playing whenthe incoming call was received, the audio sys-tem will mute the sound from the CD playeror radio and output only the incoming call. To r e c e i v e t h e c a l l , p r e s s t h e P I C K - U P b u t t o non the steering wheel control switch.When the call is over, the audio system willreturn to its previous state.
E00760300041
At any time during a call, you can mute thevehicle microphone. Pressing the SPEECH button and then saying“Mute” during a call will turn ON the mutefunction and mute the microphone.
NOTE
zIf the name you selected has matching datain the vehicle phonebook but no telephonenumber is registered under the selected loca-tion, the voice guide will say“{home/work/mobile/other} not found for. Would you like to add location ortry again?”Say “Try again,” and the system will returnto Step 3.Say “Add location” and you can register anadditional telephone number under theselected location.zIf the name you selected has matching datain the mobile phonebook but no telephonenumber is registered under the selected loca-tion, the voice guide will say“{home/work/mobile/other} not found for. Would you like to try again?” Answer “Yes,” and the system will return toStep 3.Answer “No,” and the call will be cancelled.Start over again from Step 1.
NOTE
zWhen the confirmation function is on, thesystem will check if the name and location ofthe receiver are correct
. If the name is cor-
rect, answer “Yes.”To c h a n g e t he n a m e o r l o c a t i o n t o c a l l ,answer “No.” The system will return to Step3.
RedialingSend function
Receiving calls Mute function
BK0203201EN.book 53 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Bluetooth® 2.0 interface8-54 For pleasant driving
8
Saying “Mute off” in the same way will turnoff the mute function and cancel the mute onthe microphone.
E00761400036
The Bluetooth
® 2.0 interface can switch
between hands-free mode (hands-free calls)and private mode (calls using cellular phone). If you press the SPEECH button and say“Transfer call” during a hands-free call, youcan stop the hands-free mode and talk in pri-vate mode. To r e t u r n t o h a n d s - f r e e m o d e , p r e s s t h eSPEECH button again and say “Transfercall.”
E00763700017
The Bluetooth
® 2.0 interface has 2 types of
unique phonebooks that are different from thephonebook stored in the cellular phone. Theyare the vehicle phonebook and the mobilephonebook.These phonebooks are used to register tele-phone numbers and make calls to desirednumbers via voice recognition function.
E00763801262
This phonebook is used when making callswith the voice recognition function.Up to 32 names can be registered in the vehi-cle phonebook per language.Also, each entry has 4 locations associatedwith: home, work, mobile and other. You canregister one telephone number for each loca-tion.Yo u c a n r e g i s t e r a d e s i r e d n a m e a s a n a m e f o rany phonebook entry registered in the vehiclephonebook.Names and telephone numbers can bechanged later on.The vehicle phonebook can be used with allpaired cellular phones.You can register a telephone number in thevehicle phonebook in the following 2 ways:Reading out a telephone number, and select-
ing and transferring 1 phonebook entry fromthe phonebook of the cellular phone.1. Press the SPEECH button.2. Say “Phonebook.”3. The voice guide will say “Select one ofthe following: new entry, edit number,edit name, list names, delete, erase all, orimport contact.” Say “New entry.”4. The voice guide will say “Name please.”Say your preferred name to register it.
Switching between hands-free mode and private mode Phonebook function
NOTE
zDisconnecting the battery cable will notdelete information registered in the phone-book.
Ve h i c l e p h o n e b o o k

Bluetooth® 2.0 interface
For pleasant driving 8-55
8
5. When the name has been registered, thevoice guide will say “home, work,mobile, or other?” Say the location forwhich you want to register a telephonenumber.6. The voice guide will say “Numberplease.” Say the telephone number to reg-ister it.
7. The voice guide will repeat the telephonenumber you have just read, and then reg-ister the number.When the telephone number has been reg-istered, the voice guide will say “Numbersaved. Would you like to add anothernumber for this entry?”To a d d a n o t h e r t e l e p h o n e n u m b e r f o r anew location for the current entry, answer“Yes.” The system will return to locationselection in Step 5.Answer “No” to end the registration pro-cess and return to the main menu.
Yo u c a n s e l e c t 1 p h o n e b o o k e n t r y f r o m t h ephonebook of the cellular phone and registerit in the vehicle phonebook.
1. Press the SPEECH button.2. Say “Phonebook.”3. The voice guide will say “Select one ofthe following: new entry, edit number,edit name, list names, delete, erase all, orimport contact.” Say “Import contact.”
NOTE
zWhen the confirmation function is on, thevoice guide will say “. Is this cor-rect?” Answer “Yes.”If a telephone number has
been registered for
the selected location, the voice guide will say“The current number is ,number please.”If you do not want to change the telephonenumber, say “cancel” or the original numberto keep it registered.NOTE
zIn the case of English, the system will recog-nise both “zero” and “oh” (Letter “o”) for thenumber “0.”
NOTE
zWhen the confirmation function is on, afterrepeating the tele
phone number you have
read, the voice guide will ask “Is this cor-rect?” Answer “Yes.”Answer “No” to return to telephone numberregistration in step 6.

Bluetooth® 2.0 interface8-56 For pleasant driving
8
4. The voice guide will say “Would you liketo import a single entry or all contacts?”Say “Single entry.”The Bluetooth
® 2.0 interface will become
ready to receive transferred phonebookdata.5. After the voice guide says “Ready toreceive a contact from the phone. Only ahome, a work, and a mobile number canbe imported,” the Bluetooth
® 2.0 inter-
face will receive the phonebook data fromthe Bluetooth
® compatible cellular phone.
6. Operate the Bluetooth
® compatible cellu-
lar phone to set it up so that the phone-book entry you want to register in thevehicle phonebook can be transferred tothe Bluetooth
® 2.0 interface.
7. When the reception is complete, the voiceguide will say “ numbers have beenimported. What name would you like touse for these numbers?”Say the name you want to register for thisphonebook entry.
8. The voice guide will say “Adding.”When the confirmation function is on, thesystem will ask if the name is correct.Answer “Yes.”Answer “No,” the voice guide will say“Name please.” Register a different name.9. The voice guide will say “Numberssaved.”
10. The voice guide will say “Would you like
to import another contact?”Answer “Yes” if you want to continuewith the registration. You can continue toregister a new phonebook entry from Step5.Answer “No,” the system will return tothe main menu.
E00739800024
Yo u c a n c h a n g e o r d e l e t e a n a m e o r t e l e p h o n enumber registered in the vehicle phonebook.Yo u c a n a l s o l i s t e n t o t h e l i s t o f n a m e s r e g i s -tered in the vehicle phonebook.
NOTE
zIf the maximum number of entries arealready registered, the voice guide will say“The phonebook is full. Would you like todelete a name?” Say “Yes” if you want todelete a registered name.If you say “No,” the system will return to themain menu.
NOTE
zIf the Bluetooth
® 2.0 interface cannot recog-
nise the Bluetooth
® compatible cellular
phone or the connection takes too muchtime, the voice guide will say “Import con-tact has timed out” and then the system willcancel the registration. In such case, startover again from Step 1.zPressing the HANG-UP button or pressingand holding the SPEECH button will cancelthe registration.NOTE
zIf the entered name is already used for otherphonebook entry or similar to a name usedfor other phonebook entry, that name cannotbe registered.

Bluetooth® 2.0 interface
For pleasant driving 8-57
8
1. Press the SPEECH button.2. Say “Phonebook.”3. The voice guide will say “Select one ofthe following: new entry, edit number,edit name, list names, delete, erase all, orimport contact”. Say “Edit number.”4. The voice guide will say “Please say thename of the entry you would like to edit,or say list names.” Say the name of thephonebook entry you want to edit.5. The voice guide will say “Home, work,mobile or other?” Select and say the loca-tion where the telephone number youwant to change or add is registered.When the confirmation function is on, thesystem will check the target name andlocation again. Answer “Yes” if you wantto continue with the editing.Answer “No,” the system will return toStep 3.
6. The voice guide will say “Number,please.” Say the telephone number youwant to register.7. The voice guide will repeat the telephonenumber.When the confirmation function is on, thesystem will ask if the number is correct.Answer “Yes.”Answer “No,” the system will return tothe Step 3.8. Once the telephone number is registered,the voice guide will say “Number saved”and then the system will return to themain menu.
1. Press the SPEECH button.2. Say “Phonebook.”3. The voice guide will say “Select one ofthe following: new entry, edit number,edit name, list names, delete, erase all, orimport contact.” Say “Edit name.”4. The voice guide will say “Please say thename of the entry you would like to edit,or say list names.” Say the name you wantto edit.5. The voice guide will say “Changing.”When the confirmation function is on, thesystem will check if the name is correct.Answer “Yes” if you want to continuewith the editing based on this information.Answer “No,” the syst
em will return to
Step 4.6. The voice guide will say “Name please.”Say the new name you want to register.7. The registered name will be changed.When the change is complete, the systemwill return to the main menu.

Bluetooth® 2.0 interface8-58 For pleasant driving
8
E00739900025
1. Press the SPEECH button.2. Say “Phonebook.”3. The voice guide will say “Select one ofthe following: new entry, edit number,edit name, list names, delete, erase all, orimport contact.” Say “List names.”4. Bluetooth
® 2.0 interface will read out the
entries in the phonebook in order.5. When the voice guide is done reading thelist, it will say “End of list, would you liketo start from the beginning?” When youwant to check the list again from thebeginning, answer “Yes.”When you are done, answer “No” toreturn to the previous or main menu.
E00740000026
1. Press the SPEECH button.2. Say “Phonebook.”3. The voice guide will say “Select one ofthe following: new entry, edit number,edit name, list names, delete, erase all, orimport contact.” Say “Delete.”4. The voice guide will say “Please say thename of the entry you would like todelete, or say list names.” Say the name ofthe phonebook entry in which the tele-phone number you want to delete is regis-tered.
5. If only one telephone number is registeredin the selected phonebook entry, the voiceguide will say “Deleting .”If multiple telephone numbers are regis-tered in the selected phonebook entry, thevoice guide will say “Would you like todelete [home], [work], [mobile], [other],or all?”Select the location to delete, and the voiceguide will say “Deleting .”6. The system will ask if you really want todelete the selected telephone number(s) togo ahead with the deletion, answer “Yes.”Answer “No,” the system will canceldeleting the telephone number(s) and thenreturn to Step 4.

Bluetooth® 2.0 interface
For pleasant driving 8-59
8
7. When the telephone number deletion iscomplete, the voice guide will say“ deleted” and thenthe system will return to the main menu.If all locations are deleted, the system willsay “ and all locations deleted”and the name will be removed from thephonebook. If numbers still remain underthe entry, the name will retain the otherassociated numbers.
E00740100027
Yo u c a n d e l e t e a l l r e g i s t e r e d i n f o r m a t i o nfrom the vehicle phonebook.1. Press the SPEECH button.2. Say “Phonebook.”3. The voice guide will say “Select one ofthe following: new entry, edit number,edit name, list names, delete, erase all, orimport contact.” Say “Erase all.”4. For confirmation purposes, the voiceguide will ask “Are you sure you want toerase everything from your hands-freesystem phonebook?” Answer “Yes.”Answer “No” to cancel the deletion of allregistered information in the phonebookand return to the main menu.
5. The voice guide will say “You are aboutto delete everything from your hands-freesystem phonebook. Do you want to con-tinue?” Answer “Yes” to continue.Answer “No” to cancel the deletion of allregistered information in the phonebookand return to the main menu.6. The voice guide will say “Please wait,erasing the hands-free system phone-book” and then the system will delete alldata in the phonebook.When the deletion is complete, the voiceguide will say “Hands-free system phone-book erased” and then the system willreturn to the main menu.
E00763900080
All entries in the phonebook stored in the cel-lular phone can be transferred in a batch andregistered in the mobile phonebook.Up to 7 mobile phonebooks, each containingup to 1,000 names, can be registered.The Bluetooth
® 2.0 interface automatically
converts from text to voice the names regis-tered in the transferred phonebook entries,and creates names.
Follow the steps below to transfer to themobile phonebook the phonebook stored inthe cellular phone.
