2014 MITSUBISHI OUTLANDER SPORT Owners Manual

Security alarm system*4-28 Locking and unlocking
4
E00301801859
The following methods can be used to cancelthe system when it is in the system prepara-tion mode or the system armed mode.zPressing the UNLOCK switch on theremote control switch.zPutting the operation mode in ON.zOpening any one of the doors or the tail-gate, when the system is in the systempreparation mode.
zHolding the keyless operation key andpressing the driver’s or front passenger’sdoor lock/unlock switch, or the tailgateopen switch to unlock the doors and thetailgate.
E00301902118
When the system is in the system armedmode, the alarm will be activated as followsif the vehicle is unlocked or if any of thedoors, tailgate or bonnet is opened using amethod other than the keyless entry system orthe keyless operation function.
NOTE
The function will be activated again if the fol-lowing operation is performed.zIf the doors and the tailgate are unlockedusing the keyless entry
system or the keyless
operation function.zIf the operation mode is put in on or ACC.
Cancelling the system

NOTE
zIf the bonnet is opened during the systempreparation mode, the system preparationmode is suspended.The system returns to the system preparationmode when the bonnet is closed.zIf the battery terminals are disconnectedwhile the system is in
the system preparation
mode, the memory will be erased.zIt is possible to regist
er up to 4 remote con-
trol switches.As long as they are registered, any of theremote control switches, other than the oneused to activate the system, can be used tocancel the system.If you want to register additional remotecontrol switches, please contact aMITSUBISHI MOTORS Authorised ServicePoint.zThe activation distance for keyless entry sys-tem is approximately 4 m.If it is not possible to lock or unlock thevehicle by pressing the switch at the correctdistance or the security alarm system cannotbe set or cancelled using the switch, the bat-tery may need to be replaced.Replace the battery at a MITSUBISHIMOTORS Authorised Service Point.
zIf the UNLOCK switch on the remote con-trol switch, or the driver’s or front passen-ger’s door lock/unlock switch is pressed andno door or the tailgate is opened within 30seconds, the doors and the tailgate will auto-matically relock. In this
case as well, the sys-
tem preparation mode will go into effect.zThe time between pressing of the UNLOCKswitch on the remote control switch, or thedriver’s or front passenger’s doorlock/unlock switch and automatic lockingcan be adjusted. Please consult aMITSUBISHI MOTORS Authorised ServicePoint.On vehicles equipped with Mitsubishi Multi-Communication System (MMCS), screenoperations can be used to make the adjust-ment. Refer to the separate owner’s manualfor details.
Alarm activation

NOTE
BK0203201EN.book 28 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Electric window control
Locking and unlocking 4-29
4
1. The inside alarm will be activated forapproximately 10 seconds. (except forvehicles equipped with the interior alarmsensor)2. The alarm will be activated for approxi-mately 30 seconds.The turn-signal lamps will flash, and thehorn (the siren for vehicles equipped withthe interior alarm sensor) will sound inter-mittently.3. The alarm will resume if unlawful actionsare taken again, even if the alarm hasstopped.
E00302001698
It is possible to halt the activation of an alarmusing the following methods:zPressing the LOCK or UNLOCK switchon the remote control switch.(After pressing of the LOCK switch, thevehicle will lock if all the doors and thetailgate are closed, after which the systempreparation mode will once again go intoeffect.)zPutting the operation mode in ON.zHolding the keyless operation key andlocking or unlocking the doors and thetailgate using the keyless operation func-tion.
E00302201632
The electric windows can only be operatedwith the operation mode in ON.
E00302301822
Each door window opens or closes while thecorresponding switch is operated.
NOTE
zIf the bonnet is opened during the systemarmed mode, the vehicl
e outside alarm oper-
ates immediately.
Cancelling the alarm

NOTE
zWhen the ignition switch is turned to the“ON” position or the operation mode is putin ON, the buzzer sounds 4 times. This oper-ation indicates that the alarm was activatedwhile the vehicle was parked.Please check the inside of the vehicle to con-firm that nothi
ng was stolen.
zEven if the battery is disconnected, the alarmactivation memory will not be erased.
Electric window control Electric window control switch 1- Driver’s door window2- Front passenger’s door window3- Rear left door window4- Rear right door window5- Lock switchDriver’s switchLHD
Driver’s switchRHD
BK0203201EN.book 29 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Electric window control4-30 Locking and unlocking
4
The driver’s switches can be used to operateall door windows. A window can be openedor closed by operating the correspondingswitch.Press the switch down to open the window,and pull up the switch to close it.If the switch for the driver’s window is fullypressed down/pulled up, the door windowautomatically opens/closes completely.If you want to stop the window movement,operate the switch lightly in the reverse direc-tion.
The passenger’s switches can be used to oper-ate the corresponding passenger’s door win-dows.Press the switch down for opening the win-dow, and pull up the switch for closing.
E00303101263
When this switch is operated, the passenger’sswitches cannot be used to open or close the
door windows and the driver’s switch cannotopen or close any door windows other thanthe driver’s door window.To u n l o c k , p r e s s i t o n c e a g a i n .
E00302401012
The door windows can be opened or closedfor 30 seconds after the engine is stopped.
WA R N I N GzBefore operating the electric window con-trol, make sure that nothing is capable ofbeing trapped (head, hand, finger, etc.).zNever leave the vehicle without removingthe key.zNever leave a child (or other person whomight not be capable of safe operation ofthe electric window control) in the vehiclealone.
Driver’s switches
Passenger’s switches
NOTE
zRepeated operation with the engine stoppedwill run down the battery. Operate the win-dow switches only while
the engine is run-
ning.zThe rear door windows only open halfway.
Lock switch
1- Lock2- UnlockWA R N I N GzA child may tamper with the switch at therisk of its hands or head being trapped inthe window. When driving with a child inthe vehicle, please press the window lockswitch to disable the passenger’s switches.
Timer function
BK0203201EN.book 30 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Sunroof*
Locking and unlocking 4-31
4
However, once the driver’s door or the frontpassenger’s door is opened, the windows can-not be operated.
E00302500830
If a hand or head is trapped in the closingwindow, it will lower automatically.Nonetheless, make sure that nobody putstheir head or hand out of the window whenclosing the driver’s door window.The lowered window will become operationalafter a few seconds.
E00302701275
The sunroof can only be operated with theignition switch in the “ON” position.
The sunroof automatically opens if the switch(1) is pressed.To s t o p t h e m o v i n g s u n r o o f , p r e s s t h e s w i t c h(2) or (3).The sunroof closes while the switch (3) ispressed.
Safety mechanism (driver’s window only)
WA R N I N GzIf the battery terminals are disconnectedor the fuse for electric window is replaced,the safety mechanism will be cancelled.If a hand or head got trapped, a seriousinjury could result.CAUTIONzThe safety mechanism is cancelled justbefore the window is
fully closed. This
allows the window to close completely.Therefore be especially
careful that no fin-
gers are trapped in the window.
zThe safety mechanism is deactivated whilethe switch is pulled up. Therefore be espe-cially careful that fingers are not trapped inthe door window opening.NOTE
zThe safety mechanism can be activated if thedriving conditions or
other circumstances
cause the driver’s door window to be sub-jected to a physical shock similar to thatcaused by a trapped hand or head.zIf the battery terminals are disconnected orthe fuse for electric window is replaced, thesafety mechanism will be cancelled and thedoor window will not automaticallyopen/close completely.If the window is open, repeatedly raise thedriver’s door window switch until the win-dow has been fully closed. Following this,release the switch, raise the switch onceagain and hold it in this condition for at least1 second, then releas
e it. You should now be
able to operate the driver’s door window inthe normal fashion.
Sunroof
*
CAUTION
To o p e n

NOTE
zThe sunroof automatica
lly stops just before
reaching the fully open position. Press the switch again to make it open fully.
To c l o s e

BK0203201EN.book 31 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Sunroof*4-32 Locking and unlocking
4
When the switch (2) is pressed, the rear edgeof the sunroof rises for ventilation.The sunroof tilts down while the switch (3) ispressed.
E00303900349
The sunroof can be opened or closed for 30seconds after the ignition switch is turnedfrom the “ON” position to the “ACC” or“LOCK” position.However, once the driver’s door or the frontpassenger’s door is opened, the sunroof can-not be operated.
E00304100029
Slide the sunshade manually to open andclose it.
To t i l t u p

To t i l t d o w n

Timer function

WA R N I N GzBefore operating the sunroof, make surethat nothing is capa
ble of being trapped
(head, hand, finger, etc.).zDo not put head, hands or anything elseout of the sunroof opening while drivingthe vehicle.zNever leave the vehicle without removingthe key.
zNever leave a child (o
r other person who
might not be capable of safe operation ofthe sunroof switch) in the vehicle alone.NOTE
zThe sunroof stops just before reaching thefully open position.If the vehicle is driven with the sunroof inthis position, wind buffeting is lower thanwith the sunroof fully open.zWhen leaving the vehicle unattended, makesure you close the sunroof and remove theignition key.zDo not try to operate the sunroof if it is fro-zen closed (after snow fall or during extremecold).zDo not sit or place heavy luggage on the sun-roof or roof opening edge.zRelease the switch as
soon as the sunroof
reaches the fully open or fully closed posi-tion.zIf the sunroof does not operate when the sun-roof switch is operated, release the switchand check whether something is trapped bythe sunroof. If nothing is trapped, have thesunroof checked at an authorized MITSUBI-SHI MOTORS dealer.zDepending on the models of ski carriers orroof carriers, the sunroof may contact thecarrier when the sunroof is tilted up. Be care-ful when tilting up the sunroof if such a skicarrier or a roof carrier is installed.WA R N I N G
zBe sure to close the sunroof completelywhen washing the vehicle or when leavingthe vehicle.zBe careful not to put any wax on the weath-erstrip (black rubber) around the sunroofopening. If stained with wax, the weather-strip cannot maintain a weatherproof sealwith the sunroof.zAfter washing the vehicle or after it hasrained, wipe off any water that is on the sun-roof before operating it.zOperating the sunroof
repeatedly with the
engine stationary will run down the battery.Operate the sunroof while the engine is run-ning.
Sunshade

NOTE
BK0203201EN.book 32 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Sunroof*
Locking and unlocking 4-33
4
CAUTIONzBe careful that hands are not trapped whenclosing the sunshade.NOTE
zThe sunshade cannot be
closed with the sun-
roof opened. Do not attempt to close the sun-shade when the sunroof is opened.
BK0203201EN.book 33 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

BK0203201EN.book 34 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

5
Seat and seat beltsSeat arrangement ............................................................................. 5-2Seat adjustment ................................................................................. 5-2Front seats .........................................................................................5-3Rear seats ..........................................................................................5-5Head restraints ..................................................................................5-5Making a luggage area ...................................................................... 5-7Making a flat seat..............................................................................5-8Seat belts ........................................................................................... 5-9Pregnant women restraint ...............................................................5-14Seat belt pre-tensioner system and force limiter system ................5-14Child restraint .................................................................................5-15Seat belt inspection .........................................................................5-21Supplemental restraint system (SRS)-airbag ..................................5-21
