2014 MITSUBISHI OUTLANDER SPORT Owners Manual

Cautions and actions to deal with intense heat2-8 General information
2
E00204400021
E00203001069
zWhen the ambient temperature is approximately 45 °C or higher, the phenomena described below may occur. Please take the describ
ed action.
WA R N I N GzThe Plug-in Hybrid EV System uses highvoltage up to DC 300 volt. The system canbe hot during and after starting and whenthe vehicle is shut off. Be careful of boththe high voltage and
the high temperature.
Follow the warning labels that areattached to the vehicle.zAlways assume the
high voltage battery
and associated components are energizedand fully charged.zNever perform servicing when READYindicator is illuminating or when thecharging indicator is
illuminating or flash-
ing because the high-voltage system isoperating.
For persons with electro-medi-cal apparatus such as implanta-ble cardiac pacemaker or implantable cardioverter-defi-brillator
WA R N I N GzDo not bring your body close to the footarea of the rear seat and do not stay in theluggage compartment wh
ile the vehicle is
moving. Also, do not allow persons usingan electro-medical apparatus to stay in theluggage compartment wh
ile the vehicle is
moving. The operation
of electro-medical
apparatus may be affected.zBefore you perform charging work, askthe manufacturer of your electro-medicalapparatus about the effect from chargingwork. Charging may affect the operationof your electro-medical apparatus.Refer to “Normal charging (chargingmethod with rated AC 240 V outlet)” onpage 3-8.
zObserve the following precautions for nor-mal charging:•Keep away from the charge connector orcontrol box.•Do not stay inside
of the vehicle.
•Do not get in the vehicle (including theluggage comapartment) to take outsomething or for other purpose. Refer to “Normal charging (chargingmethod with rated AC 240 V outlet)” onpage 3-8.WA R N I N G
Cautions and actions to deal with intense heat BK0203201EN.book 8 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Cautions and actions to deal with intense cold
General information 2-9
2
zEven if the ambient temperature is approximately 45 °C or lower, when driving at high-speed and uphill repeatedly, the phenomen
a described
below may occur. Please take the described actions.
E00203101073
zWhen the ambient temperature is approximately -15 °C or lower, the phenomena described below may occur. Please take the described cor-rective action.Approx. ambi-ent temperature
Phenomena
Corrective action
Approx. 45 °C or
higher
Startup and driving
• The motor output is restricted and the vehicle performance may be decreased. Then, the limited driving mode warning display
*
may be displayed.
•Stop the vehicle at a safe place if needed with the plug-in hybrid EV system started.
Charging and battery
•Charging time becomes longer, charging may not be possible or it may stop on the way.
•Park in a well-ventilated, shady place.
NOTE
z*: Refer to “Limited driving mode warning
display” on page 6-33. Display of the limite
d driving mode warni
ng display does not i
ndicate a malfunction.
Cautions and actions to deal with intense cold
BK0203201EN.book 9 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Cautions and actions to deal with intense cold2-10 General information
2
Approx. ambi-ent temperature
Phenomena
Corrective action
Approx. -15 °C
or lower
Startup and driving
•The motor output is restricted and the vehicle performance may be decreased. Then, the limited driving mode warning display
*1
may be displayed.
•Keep driving if you can drive at a similar speed as sur-rounding vehicles.If you cannot drive at a simi-lar speed as surrounding vehi-cles, stop the vehicle at a safe place and charge the drive battery.
•Regenerative braking performance may decrease.
•When braking, depress the brake pedal harder.
Charging and battery
••Charging time becomes longer.Complete charging may not be possible.
•When you have finished driv-ing, charge the drive battery before its temperature falls.
BK0203201EN.book 10 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Cautions and actions to deal with intense cold
General information 2-11
2
Approx. -30 °C
or lower
Startup and driving
•The Plug-in Hybrid EV system may not be started. Then, blink-ing of the ready indicator
*2 may continue and “BATTERY TOO
COLD” may be displayed on the multi information display.
••In the daytime, wait for the temperature to rise, restart the plug-in hybrid EV system.On vehicles equipped with both MITSUBISHI Remote control and electric heater, if low temperature is predicted, even if the drive battery is full charge, connect EV charging cable beforehand.The drive battery is automati-cally warmed up
*3.
• The vehicle performance may be restricted and the normal driv-ing may become impossible. Then, “BATTERY TOO COLD” may be displayed.
•Stop the vehicle at a safe place immediately.
• Regenerative braking performance may decrease or lose. • When braking, depress the
brake pedal harder.
Charging and battery
•Charging may become impossible or it may stop on the way. •In the daytime, wait for the
temperature to rise, restart the plug-in hybrid EV system.
CAUTIONz“BATTERY TOO COLD” is displaye
d, contact a MITSUBISHI MOTO
RS Authorized Service Point.
zBlinking of the ready indicator
*2 continues and “BATTERY TOO COLD” is displayed on the mu
lti information display with vehicle conditions, the drive
battery can not be warm up.Approx. ambi-ent temperature
Phenomena
Corrective action
BK0203201EN.book 11 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Fuel selection2-12 General information
2
E00200104259
A mixture of up to 10 % ethanol (grain alco-hol) and 90 % unleaded petrol may be used in
your vehicle, provided the octane number isat least as high as that recommended forunleaded petrol.
NOTE
z*1: Refer to “Limited driving mode
warning display” on page 6-33.
Display of the Limited driving mode warni
ng display does not i
ndicate a malfunction.
z*2: Refer to “ready indicator” on page 6-37.
z*3: To make warm up the drive battery, you shoul
d perform to communicate with the wireless
LAN device (which conforms to IEEE 802
.11 b and supports
iOS or Android) for MITSUBISHI Remote Cont
rol to the vehicle. If the information of
“” mark on the wireless LAN device is displ
ayed, connect the
EV charging cable as soon as possible.Refer to “MITSUBISHI Remote
Control” on page 3-17.
If the warming up of the drive battery is activated during home
or public charging device (EVSE:
Electric Vehicles Supply Equip
ment) charging, the
charging and warming up of the
drive battery may be stopped.
While warm up the drive battery, the following phenomena may occur.• The operation sound of on board equipmen
t and the state of charge is displa
yed on the multi information display.
Refer to “Charging from rated
AC 240V outlet” on page 3-10.
• Inside of the vehicle may be heated automatically.•The drive battery may not become full charge, or th
e remaining capacity of
drive battery may decrease.
Fuel selection Recom-mended fuel
Unleaded petrol octane number 90 RON or higher
CAUTIONzYo u r v e h i c l e h a s a f u e l f i l l e r t u b e s p e c i a l l ydesigned to accept the smaller diameterunleaded fuel dispensing nozzles only.
Liquid Petroleum Gas (L.P.G.)
CAUTIONzYo u r v e h i c l e c a n n o t b e r u n o n L . P. G.Use of an L.P.G. fuel conversion may resultin significant damage to your vehicles fuelsystem, engine, engine
sensors and exhaust
system.
Ethanol
CAUTIONzDo not use more than 10 % concentration ofethanol (grain alcohol) by volume.Use of more than 10 % concentration maylead to damage to your vehicle fuel system,engine, engine sensor
s and exhaust system.
zDo not operate your ve
hicle on gasoline con-
taining methanol. Using this type of alcoholcould adversely affect
the vehicle’s perfor-
mance and damage critical parts of the vehi-cle’s fuel system.
BK0203201EN.book 12 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Filling the fuel tank
General information 2-13
2
E00200203572
45 litres1. Before filling with fuel, stop the plug-inhybrid EV system.
NOTE
zPoor quality petrol can cause problems suchas hard starting, sta
lling, engine noise and
hesitation. If your experience these prob-lems, try another brand and/or grade of pet-rol.If the check engine
warning lamp flashes,
have the system checked as soon as possibleat a MITSUBISHI MOTORS AuthorisedService Point.
Filling the fuel tank
WA R N I N GzWhen handling fuel, comply with thesafety regulations displayed by garagesand filling stations.zGasoline is highly flammable and explo-sive. You could be burned or seriouslyinjured when handling it. When refuelingyour vehicle, always
put the operation
mode of the power switch in OFF andkeep away from flames, sparks, and smok-ing materials. Always handle fuel in well-ventilated outdoor areas.zBefore removing the fuel cap, be sure toget rid of your body’s static electricity bytouching a metal part of the car or fuelpump. Any static electricity on your bodycould create a spark that ignites fuelvapor.
zPerform the whole refueling process(opening the fuel tank filler door, remov-ing the fuel cap, etc.) by yourself. Do notlet any other person come near the fueltank filler. If you allowed a person to helpyou and that person was carrying staticelectricity, fuel vapor could be ignited.zDo not perform chargi
ng and refueling at
the same time. If you charged with staticelectricity, fuel vapor could be ignited bythe discharge spark.zDo not move away from the fuel tank filleruntil refueling is finished. If you movedaway and did something else (for example,sitting on a seat) part-way through therefueling process, you could pick up afresh charge of st
atic electricity.
zBe careful not to inhale fuel vapor. Fuelcontains toxic substances.zKeep the doors and windows closed whilerefueling the vehicle. If they were open,fuel vapor could get into the cabin.zIf the tank cap must be replaced, use onlya MITSUBIHI MOTORS original part.WA R N I N G
CAUTIONzDepending on the opera
ting conditions of
your vehicle, the fuel in the fuel tank maynot be used for a long time and stay in thetank, resulting in deterioration of the fuelquality. As this may af
fect the engine and
fuel system parts, observe the followinginstructions:•Run the engine by pressing the batterycharge switch at least once in 3 months.Refer to “Battery charge switch” on page7-23.• Refuel 20 litres or more of fuel every 6months (to make the total refueling amountin 6 months be 20 litres or more).
zIf refueling of the above
amount is not possi-
ble due to a high fuel level because the vehi-cle has not been used for a long time or forsome other reason, consult a MITSUBISHIMOTORS Authorised Service Point.
Fuel tank capacity Refuelling
BK0203201EN.book 13 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Installation of accessories2-14 General information
2
2. The fuel tank filler is located on the rearleft side of your vehicle.Open the fuel tank filler door with therelease lever located the side of thedriver’s seat.3. Open the fuel tank filler tube by slowlyturning the cap anticlockwise.
4. Insert the gun in the tank port as far as itgoes.
5. When the gun stops automatically, do notfill with fuel any more.6. To close, turn the fuel cap slowly clock-wise until you hear clicking sounds, thengently push the fuel tank filler doorclosed.
E00200300963
We r e c o m m e n d y o u t o c o n s u l t y o u rMITSUBISHI MOTORSAuthorised Service Point.zThe installation of accessories, optionalcomponents, etc., should only be carriedout within the limits prescribed by law inyour country, and in accordance with theguidelines and warnings contained withinthe documents accompanying this vehicle.zInstalling electric components incorrectlycould lead to a fire. See the “Modifica-tion/alterations to the electrical or fuelsystems” section within this owner’s man-ual.zUsing a cellular phone or radio set insidethe vehicle without an external antennamay cause electrical system interference,which could lead to unsafe vehicle opera-tion.
1- Remove2- Close
CAUTIONzSince the fuel system
may be under pressure,
remove the fuel tank filler tube cap slowly.This relieves any pressure or vacuum thatmight have built up in the fuel tank. If youhear a hissing sound, wait until it stopsbefore removing the cap. Otherwise, fuelmay spray out, injuring you or others.NOTE
zWhile filling with fuel, hang the fuel cap onthe hook (A) located on the inside of the fueltank filler door.CAUTIONzDo not tilt the gun.
Installation of accessories
BK0203201EN.book 14 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Modification/alterations to th
e electrical or fuel systemsGeneral information 2-15
2
zTy r e s a n d w h e e l s w h i c h d o n o t m e e t s p e c -ifications must not be used.Refer to the “Specifications” section forinformation regarding wheel and tyresizes.
Due to large number of accessory andreplacement parts of different manufacturesavailable in the market, it is not possible, notonly for MITSUBISHI MOTORS, but also aMITSUBISHI MOTORS Authorised ServicePoint, to check whether the attachment orinstallation of such parts affects the overallsafety of your MITSUBISHI-vehicle.Even when such parts are officially author-ised, for example by a “general operators per-mit” (an appraisal for the part) or through theexecution of the part in an officially approvedmanner of construction, or when a singleoperation permit following the attachment orinstallation of such parts, it cannot bededuced from that alone, that the drivingsafety of your vehicles has not been affected.Consider also that there basically exists noliability on the part of the appraiser or theofficial. Maximum safety can only be ensuredwith parts recommended, sold and fitted orinstalled by a MITSUBISHI MOTORS
authorised Service Point (MITSUBISHIMOTORS GENUINE replacement parts andMITSUBISHI MOTORS accessories). Thesame also pertains to modifications ofMITSUBISHI vehicles with respect to theproduction specifications. For safety reasons,do not attempt any modifications other thanthose that follow the recommendations of aMITSUBISHI MOTORS authorised ServicePoint.
E00200400368
MITSUBISHI MOTORS CORPORATIONhas always manufactured safe, high qualityvehicles. In order to maintain this safety andquality, it is important that any accessory thatis to be fitted, or any modifications carriedout which involve the electrical or fuel sys-tems, should be carried out in accordancewith MITSUBISHI guidelines.
E00200500499
MITSUBISHI MOTORS has gone to greatlengths to bring you a superbly crafted auto-mobile offering the highest quality anddependability.Use MITSUBISHI MOTORS GENUINEParts, designed and manufactured to maintainyour MITSUBISHI MOTORS automobile attop performance. MITSUBISHI MOTORSGENUINE Parts are identified by this markand are available at all MITSUBISHIMOTORS Authorised Service Points.
E00200600155
Important points!
Modification/alterations to the electrical or fuel systems
CAUTIONzIf the wires interfere
with the vehicle body or
improper installation methods are used (pro-tective fuses not included, etc.), electronicdevices may be adversely affected, resultingin a fire or other accident.
Genuine Parts Safety and disposal informa-tion for used engine oil
WA R N I N GzProlonged and repeated contact maycause serious skin disorders, includingdermatitis and cancer.zAv o i d c o n t a c t w i t h t h e s k i n a s f a r a s p o s s i -ble and wash thoroughly after any con-tact.
BK0203201EN.book 15 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分
