2014 MITSUBISHI OUTLANDER SPORT Owners Manual

Keyless entry system4-4 Locking and unlocking
4
approximately 15 seconds and the turn-signallamps will blink twice.The position and tail lamps can also be set toturn on for about 30 seconds. Refer to“Instruments and controls: Welcome light” onpage 6-43.
E00310801259
Within 30 seconds of locking the doors andtailgate using the LOCK switch (1), press theLOCK switch twice rapidly to fold the out-side rear-view mirrors.
Within 30 seconds of unlocking the doors andtailgate using the UNLOCK switch (2), pressthe UNLOCK switch twice rapidly to returnthe outside rear-view mirrors to theirextended positions.The outside rear-view mirrors are not initiallyset to work as described above. If you wantthem to work as described above, you need toset them so that they do not retract/extendwhen the doors and tailgate arelocked/unlocked using the keyless entry sys-tem or keyless operation function.Refer to “Starting and driving: Outside rear-view mirrors” on page 7-7.For details, please consult a MITSUBISHIMOTORS Authorised Service Point.In a vehicle equipped with the MitsubishiMulti-Communication System (MMCS), it ispossible to change the setting by means ofscreen operations.Refer to the separate owner’s manual fordetails.
NOTE
zThe door and tailgate
unlock function can be
set so that only the driver’s door unlockswhen the UNLOCK switch (2) is pressedonce.If the door and tailgate unlock function is setto work as described above, all the doors andthe tailgate unlock when the UNLOCKswitch is pressed two times in succession.Refer to “Setting of door and tailgate unlockfunction” on page 4-5.zIf the UNLOCK switch (2) is pressed andany of the doors or ta
ilgate is not opened
within approximately 30 seconds, relockingwill automatically occur.zIt is possible to modify
functions as follows:
For further informati
on, please contact your
MITSUBISHI MOTORS Authorised ServicePoint. On vehicles equipped
with Mitsubishi Multi-
Communication System (MMCS), screenoperations can be used to make the adjust-ment. Refer to the separate owner’s manualfor details.•The time for automatic relocking can bechanged.
•The confirmation function (blinking of theturn-signal lamps) can be set to operateonly when the doors and tailgate are lockedor only when the doors and tailgate areunlocked.•The confirmation func
tion (this indicates
locking or unlocking of
the doors and tail-
gate with the blink of the turn-signal lamps)can be deactivated.•The number of times the turn-signal lampsare blinked by the confirmation functioncan be changed.
Operation of the outside rear-view mirrors (Vehicles equipped with the mirror retractor switch) To f o l d
NOTE
To e x t e n d
NOTE
zThe outside rear-view mirrors automaticallyretract when all the doors and tailgate arelocked using the keyless operation function.Refer to “Starting and driving: Outside rear-view mirrors” on page 7-7.
BK0203201EN.book 4 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Keyless entry system
Locking and unlocking 4-5
4
E00310301296
The door and tailgate unlock function can beset to the following two conditions.Each time the door and tailgate unlock func-tion is set, a chime will sound to tell you thecondition of the door and tailgate unlockfunction.1. Put the operation mode in OFF.2. Place the combination headlamps and dip-per switch in the “OFF” position, andleave the driver’s door open.3. Press the LOCK switch (1) for 4 to 10seconds and press the UNLOCK switch(2) during this time.
4. Release in sequence the LOCK andUNLOCK switches within 10 seconds ofpressing the LOCK switch in step 3.
E00309501243
Before replacing the battery, remove staticelectricity from your body by touching ametal grounded object.
zThe keyless entry system does not operatewhen the door or tailgate is open.zThe remote control switch will operatewithin about 4 m from the vehicle. However,the operating range of the remote controlswitch may change if the vehicle is locatednear a power station,
or radio/TV broadcast-
ing station.zIf either of the following problems occurs,the battery may be exhausted.•The remote control switch is operated at thecorrect distance from the vehicle, but thedoors and tailgate are
not locked/unlocked
in response.•The indicator lamp (4) is dim or does notcome on.For further information, please consult yourMITSUBISHI MOTORS Authorised Ser-vice Point.If you replace the battery yourself, refer to“Procedure for replacing the remote controlswitch battery” on page 4-5.
zIf your remote control switch is lost or dam-aged, please contact
your MITSUBISHI
MOTORS Authorised Service Point for areplacement remote control switch.zIf you wish to add a remote control switch,we recommend you to contact yourMITSUBISHI MOTORS Authorised ServicePoint.The below remote control switches are avail-able for your vehicle.NOTE
•Keyless operation key: up to 4 remote con-trol switches
Setting of door and tailgate unlock function Number of chimes
Condition
One chime
All doors and the tailgate unlock
Tw o chimes
Driver’s door unlock only
NOTE
NOTE
zOn vehicles equipped
with Mitsubishi Multi-
Communication System (MMCS), screenoperations can be used to make the adjust-ment. Refer to the se
parate owner’s manual
for details.
Procedure for replacing the remote control switch battery
BK0203201EN.book 5 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Keyless operation system4-6 Locking and unlocking
4
1. With the MITSUBISHI mark facing you,insert the cloth-covered tip of a straightblade (or minus) screwdriver into thenotch in the case and use it to open thecase.2. Remove the old battery.
3. Install a new battery with the + side (A)up.4. Close the case firmly.5. Check the keyless operation function tosee that it works.
E00305601608
The keyless operation system allows you tolock and unlock the doors and tailgate andstart the engine simply by carrying the key-less operation key with you.The keyless operation key can also be used asthe keyless entry system remote controlswitch.Refer to “Keyless entry system” on page 4-3.The driver should always carry the keylessoperation key. This key is necessary for lock-ing and unlocking the doors and tailgate,starting the engine and otherwise operatingthe vehicle, so before locking and leaving thevehicle, be sure to check that you have thekeyless operation key.
NOTE
zBe sure to perform the procedure with theMITSUBISHI mark facing you. If theMITSUBISHI mark is not facing you whenyou open the case, the transmitter may comeout.
NOTE
zYo u m a y p u r c h a s e a r e p l a c e m e n t b a t t e r y a tan electric appliance store.zA MITSUBISHI MOTORS Authorised Ser-vice Point can replace the battery for you ifyou prefer.CAUTIONzWhen the remote control switch case isopened, be careful to keep water, dust, etc.out. Also, do not touch
the internal compo-
nents.
+ side- side
Coin type battery CR2032
Keyless operation system
WA R N I N GzPeople with implantable cardiac pacemak-ers or implantable
cardiovascular-defi-
brillators should no
t go near the exterior
transmitters (A) or the interior transmit-ters (B). The radio waves used by the key-less operation system could adverselyaffect implantable cardiac pacemakers orimplantable cardiovascu
lar-defibrillators.
BK0203201EN.book 6 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Keyless operation system
Locking and unlocking 4-7
4
Yo u c a n l i m i t t h e p o s s i b l e o p e r a t i o n s o fthe keyless operation system in the fol-lowing ways. (The keyless operation sys-tem can be used as a keyless entrysystem.) Please consult a MITSUBISHIMOTORS Authorised Service Point.
•You can limit operations to locking andunlocking the doors and tailgate.•You can limit operations to starting theengine.• The keyless operation system can be dis-abled.When keyless operation system opera-tions are modified, the transmitters oper-ate as follows.•Only locking and unlocking doors ortailgate: exterior transmitter and interiortransmitter•Only starting the engine: interior trans-mitter
E00305700556
If you are carrying the keyless operation key,enter the operating range of the keyless oper-
WA R N I N GzWhen using electromedical devices otherthan implantable cardiac pacemakers orimplantable cardiovascular-defibrilla-tors, contact the electromedical devicemanufacturer ahead of time to determinethe affects of radio waves on the devices.Electromedical device operations could beaffected by radio waves.
NOTE
zThe keyless operation ke
y uses an ultra-weak
electromagnetic wave. In the followingcases, the keyless ope
ration system may not
operate properly or
may be unstable.
•When there is equipment nearby that emitsstrong radio waves, such as: a power sta-tion, a radio/TV broa
dcasting station or an
airport.•The keyless operation system is carriedtogether with a communications devicesuch as a cellular phone
or radio set, or with
an electronic device such as a personalcomputer.•The keyless operati
on key is touching or
covered by a metal object.
•A keyless entry system is being usednearby.•When the keyless operation key battery isworn out.•When the keyless operation key is set downin an area with strong radio waves or noise.In such cases, use the emergency key.Refer to “To operate
without using the key-
less operation functi
on” on page 4-13.
zBecause the keyless operation key receivessignals in order to communicate with thetransmitters in the vehicle, the battery con-tinually wears down regardless of keylessoperation key use. The battery life is 1 to 3years, depending on usage conditions. Whenthe battery wears out, replace the batteryaccording to the description in this manual orhave it replaced at your MITSUBISHIMOTORS Authorised Service Point.Refer to “Procedure for replacing the remotecontrol switch battery” on page 4-5.zBecause the keyless
operation key continu-
ally receives signals, strong radio wavereception could affect battery wear. Do notleave the key near a TV, personal computer,or other electronic device.
Operating range of the keyless operation system
NOTE
BK0203201EN.book 7 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Keyless operation system4-8 Locking and unlocking
4
ation system, and press the driver’s or frontpassenger’s door lock/unlock switch, the tail-gate LOCK switch or the tailgate openswitch, the ID code for your key is verified.Yo u c a n o n l y l o c k a n d u n l o c k t h e d o o r s a n dtailgate and start the engine if the ID codes ofyour keyless operation key and the vehiclematch.
E00306200516
The operating range is about 70 cm from thedriver’s door handle, front passenger’s doorhandle, and tailgate handle.
E00306300285
The operating range is the interior of thevehicle.
NOTE
zIf the keyless operation
key battery is wear-
ing out or there are strong electromagneticwaves or noise present, the operating rangemay become smaller and operation maybecome unstable.
Operating range for locking and unlocking the doors and tailgate
*:Forward direction:Operating range
NOTE
zLocking and unlocki
ng are only possible
when the door or tailgate is operated whilethe keyless operation ke
y is being detected.
zOperation may not be possible if you are tooclose to the front door, door window, or tail-gate.
zEven if the keyless
operation key is within
70 cm of the driver’s door handle, front pas-senger’s door handle, or
tailgate handle, if
the key is near to the ground or high up, thesystem may not operate.zIf the keyless operation
key is within the
operating range, even someone not carryingthe key can lock and unlock the doors andtailgate by pressing the driver’s or front pas-senger’s door lock/unlock switch, the tail-gate lock switch or the tailgate open switch.
Operating range for starting the engine
*:Forward direction:Operating range
NOTE
BK0203201EN.book 8 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Keyless operation system
Locking and unlocking 4-9
4
E00305800922
When you are carrying the keyless operationkey, if you press the driver’s or front passen-ger’s door lock/unlock switch (A), or the tail-gate LOCK switch (B) within the operatingrange, the doors and the tailgate are locked.The turn-signal lamps will blink once.Also refer to “Locking and unlocking: Doors,Central door locks, Tailgate” on pages 4-14,4-15 and 4-16.
When you are carrying the keyless operationkey, if you press the driver’s or front passen-ger’s door lock/unlock switch (A), or the tail-gate open switch (B) within the operatingrange, all the doors and the tailgate areunlocked.If the front room lamp switch is in the“DOOR” position or the rear room lampswitch is in the middle (
z) position at this
NOTE
zEven if it is within the operating range, if thekeyless operati
on key is in a small item
holder such as the glove box, on top of theinstrument panel, door pocket or in the lug-gage area, it may be impossible to start theengine.zIf you are too close to the door or door win-dow, the engine may start even though thekeyless operation
key is outside the vehicle.
To o p e r a t e u s i n g t h e k e y l e s s operation function Locking the doors and tailgate
NOTE
zFor vehicles equipped wi
th the mirror retrac-
tor switch, the outside rear-view mirrorsautomatically retract when all the doors andtailgate are locked using the keyless opera-tion function.Refer to “Starting and driving: Outside rear-view mirrors” on page 7-7.zThe keyless operati
on function does not
operate under the following conditions:
Driver’s or front passenger’s door lock/unlock switchesTa i l g a t e s w i t c h e s
•The keyless operation
key is inside the
vehicle.•A door or the tailgate is open or ajar.zThe tailgate open switch (C) can be used tocheck that the vehicle is locked properly.Press the tailgate open switch within about 3seconds of locking the vehicle. If you waitlonger than 3 seconds
and press the tailgate
open switch, the doors and tailgate will beunlocked.zThe time allowed for checking that the vehi-cle is locked can be adjusted. For furtherinformation, please contact your authorisedMITSUBISHI MOTORS dealer.On vehicles equipped
with Mitsubishi Multi-
Communication System (MMCS), screenoperations can be used to make the adjust-ment. Refer to the se
parate owner’s manual
for details.
Unlocking the doors and tailgate
NOTE
BK0203201EN.book 9 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Keyless operation system4-10 Locking and unlocking
4
time, the room lamp will turn on for 15 sec-onds. The turn-signal lamps will blink twice.If the driver’s or front passenger’s doorlock/unlock switch is pressed and any of thedoors or tailgate is not opened within approx-imately 30 seconds, relocking will automati-cally occur.Also refer to “Locking and unlocking: Doors,Central door locks, Tailgate” on pages 4-14,4-15 and 4-16.
Operation can be confirmed as shown below.However, the room lamp will only illuminateif the front room lamp switch is in the“DOOR” position or the rear room lampswitch is in the middle (
z) position.
Driver’s and front passenger’s door lock/unlock switchesTa i l g a t e o p e n s w i t c h
NOTE
zFor vehicles equipped wi
th the mirror retrac-
tor switch, the outside rear-view mirrorsautomatically extend when all the doors andtailgate are unlocked us
ing the keyless oper-
ation function.Refer to “Starting and driving: Outside rear-view mirrors” on page 7-7.zThe keyless operation f
unction can be set so
that only the driver’s door unlocks when thedriver’s door lock/unlock switch is pressed.If the keyless operati
on function is set to
work as described above, all the doors andthe tailgate unlock when the driver’s doorlock/unlock switch is pressed two times insuccession.Refer to “Setting of door and tailgate unlockfunction” on page 4-5.zThe keyless operation function does notoperate under the following conditions:•A door or the tailgate is open or ajar.zIn order to make it possible to check that thedoors and tailgate are locked, you cannotunlock them by using the tailgate openswitch for 3 seconds after locking them.zThe time allowed for checking that the vehi-cle is locked can be adjusted. For furtherinformation, please contact your authorisedMITSUBISHI MOTORS dealer.On vehicles equipped
with Mitsubishi Multi-
Communication System (MMCS), screenoperations can be used to make the adjust-ment. Refer to the se
parate owner’s manual
for details.
zThe time between unlocking and automaticlocking can be adjusted. Please consult aMITSUBISHI MOTORS Authorised ServicePoint.On vehicles equipped with Mitsubishi Multi-Communication System (MMCS), screenoperations can be used to make the adjust-ment. Refer to the separate owner’s manualfor details.
Operation confirmation when lockingand unlockingWhen lock-ing:
The turn-signal lamps blinkonce.
Whenunlocking:
The room lamp illuminates forabout 15 seconds, the turn-signallamps blink twice.
NOTE
BK0203201EN.book 10 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Keyless operation system
Locking and unlocking 4-11
4
E00305901715
In order to prevent vehicle theft or the accidental operation of
the keyless operation system, the buzzer and the display on th
e information screen
in the multi-information display are used to alert the driver.If a warning is activated, always check the vehicle and the keyless operation key. The warning is also displayed if there is a
fault in the keyless
operation system.
NOTE
zFunctions can be modified as stated below.For further information, please contact yourMITSUBISHI MOTORS Authorised ServicePoint.On vehicles equipped with Mitsubishi Multi-Communication System (MMCS), screenoperations can be used
to make the adjust-
ment. Refer to the se
parate owner’s manual
for details.
•Set the confirmation function (blinking ofthe turn-signal lamps) to operate only whenthe vehicle is locked or only when the vehi-cle is unlocked.•Disable the operation confirmation function(blinking of the turn-signal lamps).•Change the number of blinks for the opera-tion confirmation function (blinks of theturn-signal lamps).NOTE
Wa r n i n g a c t i v a t i o n
Item
Display
Buzzer
Note (Solution)
Detection of failure
Inner buzzer sounds once
There is a fault in the keyless operation system.
Fall of battery voltage
Inner buzzer sounds once
The battery starts to run out, the warning is activated.
（The warning is
not activated if the battery is completely dead.
）
