2014 MITSUBISHI OUTLANDER SPORT Owners Manual

Bluetooth® 2.0 interface8-60 For pleasant driving
8
1. Press the SPEECH button.2. Say “Phonebook.”3. The voice guide will say “Select one ofthe following: new entry, edit number,edit name, list names, delete, erase all, orimport contact.” Say “Import contact.”4. The voice guide will say “Would you liketo import a single entry or all contacts?”Say “All contacts.”
5. The voice guide will say “Importing thecontact list from the mobile phonebook.This may take several minutes to com-plete. Would you like to continue?”Answer “Yes,” transferring to the mobilephonebook the phonebook stored in thecellular phone will start.Answer “No,” the system will return tothe main menu.
6. When the transfer is complete, the voiceguide will say “Import complete” andthen the system will return to the mainmenu.
zThe maximum supported telephone numberlength is 19 digits. Any telephone number of20 digits or more will be truncated to the first19 digits.zIf telephone numbers contain charactersother than 0 to 9,
*, # or +, these characters
are deleted before the transfer.zFor the connection settings on the cellularphone side, refer to the instructions for thecellular phone.NOTE
NOTE
zThe transfer may take some time to completedepending on the number of contacts.zIf the Bluetooth
® 2.0 interface could not be
connected to the Bluetooth
® compatible cel-
lular phone, the voice guide will say “Unableto transfer contact
list from phone” and then
the system will return to the main menu.zIf you press the HANG-UP button or pressand hold the SPEECH button during the datatransfer, the transfer will be cancelled andthe system will return to the main menu.zIf an error occurs during the data transfer, alltransfer will be cancelled and the voice guidewill say “Unable to complete the phonebookimport” and then the system will return tothe main menu.zIf there are no contacts in the phonebook, thevoice guide will say “There are no contactson the connected phone.”
BK0203201EN.book 60 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

USB input terminal
For pleasant driving 8-61
8
E00732400249
E00761901126
Yo u c a n c o n n e c t y o u r U S B m e m o r y d e v i c e o riPod
* to play music files stored in the USB
memory device or iPod.The following explains how to connect andremove a USB memory device or iPod.*: “iPod” is a registered trademark of AppleInc. in the United States and other countries.
E00762001401
1. Park your vehicle in a safe place and putthe operation mode in OFF.
2. Open the USB input terminal cover (A) inthe floor console box.
Enrollment commands USB input terminal
How to connect a USB memory device
BK0203201EN.book 61 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

USB input terminal8-62 For pleasant driving
8
3. Connect a commercially available USBconnector cable (C) to the USB memorydevice (B).4. Connect the USB connector cable (C) tothe USB input terminal (D).
5. To remove the USB connector cable, putthe operation mode in OFF first and per-form the installation steps in reverse.
E00762101301
1. Park your vehicle in a safe place and putthe operation mode in OFF.
2. Open the USB input terminal cover (A) inthe floor console box.3. Connect the Dock connector (C) to theiPod (B).
CAUTIONzKeep the lid of the floor console box closedwhile driving the vehicle. A lid or the con-tents of the floor console box could other-wise cause injuries.NOTE
zDo not connect the USB memory device tothe USB input terminal directly.The USB memory device may be damaged.zWhen closing the floor console box, be care-ful not to trap the USB connector cable.
How to connect an iPod
NOTE
zUse a genuine Dock connector from AppleInc.
BK0203201EN.book 62 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

USB input terminal
For pleasant driving 8-63
8
4. Connect the Dock connector (C) to theUSB input terminal (D).5. To remove the Dock connector, put theoperation mode in OFF first and performthe installation steps in reverse.
E00762200015E00762301361
Devices of the following types can be con-nected.
CAUTIONzKeep the lid of the floor console box closedwhile driving the vehicle. A lid or the con-tents of the floor c
onsole box could other-
wise cause injuries.NOTE
zWhen closing the floor console box, be care-ful not to trap the connector cable.
Ty p e s o f c o n n e c t a b l e d e v i c e s and supported file specifica-tions Device types Model name
Condition
USB memory device
Storage capacity of 256 Mbytes or more
iPod
*
fifth genera-tion
F/W Ver.1.3 or later
iPod classic
*
80GB/180GB
F/W Ver.1.1.2 or later
120GB
F/W Ver.2.0.1 or later
160GB (late 2009)
F/W Ver.2.0.4 or later
iPod nano
*
first genera-tion
F/W Ver.1.3.1 or later
second gen-eration
F/W Ver.1.1.3 or later
third genera-tion
F/W Ver.1.1.3 or later
fourth gener-ation
F/W Ver.1.0.4 or later
fifth genera-tion
F/W Ver.1.0.2 or later
sixth genera-tion
F/W Ver.1.0 or later
iPod touch
*
first genera-tion
F/W Ver.3.1.3 or later
second gen-eration
F/W Ver.4.2.1 or later
third genera-tion
F/W Ver.4.3.1 or later
fourth gener-ation
F/W Ver.4.3.1 or later
Model name
Condition
BK0203201EN.book 63 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Sun visors8-64 For pleasant driving
8
*: “iPod,” “iPod classic,” “iPod nano,” “iPodtouch” and “iPhone” are registered trade-marks of Apple Inc. in the United States andother countries.
E00762400033
Yo u c a n p l a y m u s i c f i l e s o f t h e f o l l o w i n gspecifications that are saved in a USB mem-ory device or other device supporting massstorage class. When you connect your iPod,playable file specifications depend on theconnected iPod.
E00711202277
A vanity mirror is fitted to the back of the sunvisor.Operating the lid of the vanity mirror willautomatically turn on the mirror lamp (A).
iPhone
*
iPhone
F/W Ver.3.1.3 or later
iPhone 3G
F/W Ver.4.2.1 or later
iPhone 3GS
F/W Ver.4.3.1 or later
iPhone 4
F/W Ver.4.3.1 or later
iPhone 4S
F/W Ver.5.0.1 or later
Models other than USB memory devices and iPods
Digital audio player supporting mass storage class
NOTE
zDepending on the type of the USB memorydevice or other device connected, the con-nected device may not function properly orthe available functions may be limited.zIt is recommended to use an iPod with firm-ware updated to th
e latest version.
zYo u c a n c h a r g e y o u r i P o d b y c o n n e c t i n g i t t othe USB input terminal when the operationmode is in ON or ACC.
Model name
Condition
zDo not keep your USB memory device oriPod in your vehicle.zIt is recommended that you back up the filesin case of data damage.zDo not connect to the USB input terminalany device (hard disk, card reader, memoryreader, etc.) other than the connectabledevices specified in the previous section.The device and/or data
may be damaged. If
any of these devices
was connected by mis-
take, remove it after putting the operationmode in OFF.
File specifications Item
Condition
File format
MP3, WMA, AAC
Maximum number of levels(including the root)
Level 8
Number of folders 700Number of files 65,535
NOTE
Sun visors 1- To eliminate front glare2- To eliminate side glareVa n i t y m i r r o r
BK0203201EN.book 64 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Ashtray
For pleasant driving 8-65
8
Cards can be slipped into the holder (B) onthe back of the sunvisor.
E00711402165
To u s e t h e a s h t r a y, o p e n t h e l i d .
The moveable ashtray can be fitted at theindicated position.
CAUTIONzIf the lid of vanity mirror with lamp is keptopen for prolonged periods of time, the aux-iliary battery will be discharged.
Card holder
Ashtray
CAUTIONzPut out matches and cigarettes before theyare placed in the ashtray.zDon’t put papers and ot
her things that burn
into your ashtrays. If you do, cigarettes orother smoking material
s could set them on
fire, causing damage.zAlways close the ashtra
y. I f l e f t o p e n , o t h e r
cigarette butts in the ashtray may be rekin-dled.
Mounting position for move-able ashtray
BK0203201EN.book 65 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Accessory socket8-66 For pleasant driving
8
E00711602516
To u s e a p l u g - i n t y p e a c c e s s o r y, o p e n t h e l i dor remove the cap, and insert the plug in theaccessory socket.The accessory socket can be used while theoperation mode is in ON or ACC.
E00712002328
Accessory socket
CAUTIONzBe sure to use a “plug-in” type accessoryoperating at 12 V and
at 120 W or less.
When using more than one socket at thesame time, make sure that the electricalaccessories are 12 V accessories and that thetotal power consumption does not exceed120 W.zLong use of the electric appliance when theready indicator is not illuminated may rundown the auxiliary battery.zWhen the accessory socket is not in use, besure to close the lid or install the cap,because the socket might become clogged byforeign material and
be short-circuited.
NOTE
zAccessory sockets in 2 locations can be usedat the same time.
Floor consoleFloor console box
Interior lamps 1- Luggage room lamp2- Room lamp (rear)3- Map & room lamps (front)4- Downlight
m P.6-40
NOTE
zIf you leave the lamps on when the readyindicator is not illuminated, you will rundown the auxiliary battery.Before you leave the vehicle, make sure thelamps are turned off.
BK0203201EN.book 66 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Interior lamps
For pleasant driving 8-67
8
E00712102404
E00712400168
Push the lens (A) to turn on the lamp. Push itagain to turn it off.
Room lamps Posi-tion of lamp switch
On/off control
1-ON ()
The lamp illuminates regardless of whether a door or the tailgate is open or closed.
FrontRear
2-DOOR (•)
The lamp illuminates when a door or the tailgate is opened. It goes off about 15 seconds after all doors and the tailgate are closed.However, the lamp goes off immediately with all doors and the tailgate closed in the follow-ing cases:•When the operation mode is put in ON.•When the central door lock function is used to lock the vehicle.•When the keyless operation key is used to lock the vehicle.•When the keyless operation function is used to lock the vehicle.
3-OFF ()
The lamp goes off regardless of whether a door or the tailgate is open or closed.
Posi-tion of lamp switch
On/off control
NOTE
zWhen the operation mode is put in OFFwhile the doors and tailgate are closed, thelamp illuminates and after about 15 secondsit goes off.zThe time until the lamp goes off can beadjusted. For details, please consult a MIT-SUBISHI MOTORS Authorised ServicePoint. On vehicles e
quipped with Mitsubishi
Multi-Communication System (MMCS),screen operations can be used to make theadjustment. Refer to the separate owner’smanual for details.
Map lamps
BK0203201EN.book 67 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分
