1996 TOYOTA TERCEL Service Repair Manual

BO1HP-02
Z16116
Wiper Link Cowl Louver
Wiper MotorCap
Wiper Arm
Wiper Arm
Cap
BO-26
- BODYFRONT WIPER AND WASHER
1120 Author
: Date
:
1996 TERCEL (RM440U)
FRONT WIPER AND WASHER
COMPONENTS

BO33R-01
N12056
- BODYFRONT WIPER AND WASHER
BO-27
1996 TERCEL (RM440U)
REMOVAL
1. REMOVE WIPER ARMS
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
2. REMOVE COWL LOUVER
3. REMOVE WIPER MOTOR
(a) Disconnect the connector, then unfasten the 4 bolts.
(b) Connect the claw of the wiper link to the panel.
(c) Disconnect the motor from the wiper link and remove it.
4. REMOVE WIPER LINK
(a) Remove the 6 bolts.
(b) Remove the wiper link through the service hole.
5. REMOVE WIPER LINK
6. REMOVE WINDOW WASHER NOZZLE

BO33S-01
N15577
A
C
BA
B
D E
BE3367
2 ~ 2.5 mm
(0.079 ~ 0.098 in.)
0.7 ~ 0.75 mm
(0.028 ~ 0.030 in.) BO-28
- BODYFRONT WIPER AND WASHER
1996 TERCEL (RM440U)
ADJUSTMENT
1. INSPECT WASHER NOZZLE
(a) While operating the washer, check whether the upper
point where the washer fluid hits the windshield and the
upsurge area are within the range indicated by the
hatched line.
A: Approx. 150 mm (5.91 in.)
B: Approx. 50 mm (1.99 in.)
C: Approx. 0 - 50 mm (0 - 1.99 in.)
D: Approx. 30 mm (1.18 in.)
E: Approx. 20 mm (0.79 in.)
(b) Check if the lower point where the washer fluid hits the
windshield is within the range of the wiping pattern (the
area of the glass which is wiped by the wiper blades).
2. ADJUST WASHER NOZZLE
Using a tool like that one shown in the illustration, change the
direction of the nozzle hole to adjust the point where washer
fluid hits the windshield.

BO33T-01
- BODYFRONT WIPER AND WASHER
BO-29
1996 TERCEL (RM440U)
INSTALLATION
Installation is in the reverse order of removal procedure (See page BO-27).

BO1HX-02
N12583
Roof Drip Side Finish Moulding
BO-30
- BODYROOF DRIP SIDE FINISH MOULDING
1124 Author
: Date
:
1996 TERCEL (RM440U)
ROOF DRIP SIDE FINISH MOULDING
COMPONENTS

BO1HY-01
N12304
- BODYROOF DRIP SIDE FINISH MOULDING
BO-31
1996 TERCEL (RM440U)
REMOVAL
REMOVE ROOF DRIP SIDE FINISH MOULDING
Using SST, pull off the roof drip side finish moulding from front
ends.
SST 09806-30010

BO1HZ-01
N12303
BO-32
- BODYROOF DRIP SIDE FINISH MOULDING
1996 TERCEL (RM440U)
INSTALLATION
INSTALL ROOF DRIP SIDE FINISH MOULDING
(a) Attach the upper edge of the moulding to the body flange.
(b) Tap on the moulding by hand.

BO1I0-03
H05850
Inner rear View Mirror

Windshield Moulding

Dam
Front Pillar Garnish Cap
Wiper Arm
Windshield Glass
Cowl Louver

Non-reusable partFront Pillar Garnish
- BODYWINDSHIELD
BO-33
1127 Author
: Date
:
1996 TERCEL (RM440U)
WINDSHIELD
COMPONENTS
