1996 TOYOTA TERCEL Service Repair Manual

- DIAGNOSTICSENGINE
DI-51
1996 TERCEL (RM440U)
4 Check injector injection (See page MF-19).
NG Replace injector.
OK
5 Check manifold absolute pressure sensor and engine coolant temp. sensor
(See page DI-20, DI-28).
NG Repair or replace.
OK
6 Check for spark and ignition (See page IG-1).
NG Repair or replace.
OK
Check and replace ECM (See page IN-26).

DI-52
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
DTC P0300 Random/Multiple Cylinder Misfire Detected
DTC P0301 Cylinder 1 Misfire Detected
DTC P0302 Cylinder 2 Misfire Detected
DTC P0303 Cylinder 3 Misfire Detected
DTC P0304 Cylinder 4 Misfire Detected
CIRCUIT DESCRIPTION
Misfire: The ECM uses the crankshaft position sensor and camshaft position sensor to monitor changes in
the crankshaft rotation for each cylinder.
The ECM counts the number of times the engine speed change rate indicates that misfire has occurred. And
when the misfire rate equals or exceeds the count indicating that the engine condition has deteriorated, the
MIL lights up.
If the misfire rate is high enough and the driving conditions will cause catalyst overheating, the MIL blinks
when misfiring occurs.
DTC No.DTC Detection ConditionTrouble Area
P0300Misfiring of random cylinders is detected during any particular
200 or 1,000 revolutions
Ignition system


Injector
P0301
P0302
For any particular 200 revolutions of the engine, misfiring is
detected which can cause catalyst overheating
(This causes MIL to blink)

Injector

Fuel line pressure

Compression pressure

Valve clearance not to specification
P0302
P0303
P0304For any particular 1,000 revolutions of the engine, misfiring is
detected which causes a deterioration in emissions
(2 trip detection logic)
Valve clearance not to s ecification

Valve timing

Manifold absolute pressure sensor

Engine coolant temp. sensor
HINT:
When the 2 or more codes for a misfiring cylinder are recorded repeatedly but no Random Misfire code is
recorded, it indicates that the misfires were detected and recorded at different times.
DI39Y-04

A15696
FI6588
FI6538
A00064
10V/
Division
GND
100 m sec./Division (Idling)GND(Magnification)
1 m sec./Division (Idling)
Injection duration10V/
Division
- DIAGNOSTICSENGINE
DI-53
1996 TERCEL (RM440U)
WIRING DIAGRAM
Reference: INSPECTION USING OSCILLOSCOPE
INJECTOR SIGNAL WAVEFORM
With the engine idling, measure between terminals #10, #20 and E01 of ECM.
HINT:
The correct waveform is as shown.

P25779S00553A05593
DI-54
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
INSPECTION PROCEDURE
1 Check spark plug and spark of misfiring cylinder.
PREPARATION:
(a) Disconnect the high-tension cord or ignition coil.
(b) Remove the spark plug.
CHECK:
(a) Check plug type.
(b) Check for carbon deposits on electrode.
(c) Check electrode gap.
OK:
(1) Twin ground electrodes type.
Recommended spark plug:
ND: K16TR11
NGK: BKR5EKB-11
(2) No large carbon deposit present.
Not wet with gasoline or oil.
(3) Electrode gap: 1.0 - 1.1 mm (0.039 - 0.043 in.)
PREPARATION:
(a) Install the spark plug to the high-tension cord or ignition
coil.
(b) Disconnect the injector connector.
(c) Ground the spark plug.
CHECK:
Check if spark occurs while engine is being cracked.
NOTICE:
To prevent excess fuel being injected from the injectors
during this test, do not crank the engine for more than 5 -
10 seconds at a time.
OK:
Spark jumps across electrode gap.
NG Replace or check ignition system (See page
IG-1).
OK

A15699
- DIAGNOSTICSENGINE
DI-55
1996 TERCEL (RM440U)
2 Check voltage of ECM terminals for injector of failed cylinder.
PREPARATION:
(a) Remove the lower finish panel.
(b) Turn the ignition switch ON.
CHECK:
Measure the voltage between applicable terminals of the ECM
connector and the body ground.
OK:
Voltage: 9 - 14 V
OK Go to step 4.
NG
3 Check injector resistance of misfiring cylinder (See page MF-16).
NG Replace injector.
OK
Check for open and short in harness and con-
nector between injector and ECM (See page
IN-26).
4 Check fuel pressure (See page MF-1).
NG Check and repair fuel pump, pressure regulator,
fuel pipe line and filter (See page MF-5).
OK
5 Check injector injection (See page MF-16).
NG Replace injector.

DI-56
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
OK
6 Check EGR system (See page EC-8).
NG Replace injector.
OK
7 Check manifold absolute pressure sensor and engine coolant temp. sensor (See
page DI-41 and DI-45).
NG Repair or replace.
OK
Check compression pressure (See page EM-3), valve clearance (See page EM-4) and valve tim-
ing (See page EM-17).

A15700
- DIAGNOSTICSENGINE
DI-57
1996 TERCEL (RM440U)
DTC P0325 Knock Sensor 1 Circuit Malfunction
CIRCUIT DESCRIPTION
A knock sensor is fitted to the cylinder block to detect engine knocking. This sensor contains a piezoelectric
element which generates a voltage when it becomes deformed, which occurs when the cylinder block vi-
brates due to knocking. If engine knocking occurs, ignition timing is retarded to suppress it.
DTC No.DTC Detection ConditionTrouble Area
P0325
No knock sensor 1 signal to ECM with engine speed 1,200 rpm
or more
(2 trip detection logic)
Open or short in knock sensor 1 circuit

Knock sensor 1 (looseness)

ECM
If the ECM detects the above diagnosis conditions, it operates the fail-safe function in which the corrective
retard angle value is set to the maximum value.
WIRING DIAGRAM
DI012-20

A15701
DI-58
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
INSPECTION PROCEDURE
1 Check continuity between terminal KNK of ECM connector and body ground.
PREPARATION:
(a) Remove the lower finish panel.
(b) Disconnect the E7 connector of ECM.
CHECK:
Measure the resistance between terminal KNK of the ECM con-
nector and the body ground.
OK:
Resistance: 1 MW or higher
OK Go to step 3.
2 Check knock sensor (See page MF-50).
NG Replace knock sensor.
OK
3 Check for open and short in harness and connector between ECM and knock
sensor (See page IN-26).
NG Repair or replace harness or connector.
OK
4 Does malfunction disappear when a good knock sensor is installed?
YES Replace knock sensor.
NO
Check and replace ECM (See page IN-26).
