1996 TOYOTA TERCEL Service Repair Manual

SR05Q-17
R11229
NormalAbnormal
R11025Engine Idling Engine Stopped5 mm (0.20 in.)
or less SR-6
- STEERINGPOWER STEERING FLUID
1996 TERCEL (RM440U)
INSPECTION
1. CHECK FLUID LEVEL
(a) Keep the vehicle level.
(b) With the engine stopped, check the fluid level in the oil
reservoir.
If necessary, add fluid.
Fluid: ATF DEXRON® II or III
HINT:
Check that the fluid level is within the HOT LEVEL range on the
reservoir cap dipstick. If the fluid is cold, check that it is within
the COLD LEVEL range.
(c) Start the engine and run it at idle.
(d) Turn the steering wheel from lock to lock several times to
boost fluid temperature.
Fluid temperature: 80°C (176°F)
(e) Check for foaming or emulsification.
If there is foaming or emulsification, bleed power steering sys-
tem. (See page SR-5)
(f) With the engine idling, measure the fluid level in the oil
reservoir.
(g) Stop the engine.
(h) Wait a few minutes and remeasure the fluid level in the oil
reservoir.
Maximum fluid level rise: 5 mm (0.20 in.)
If a problem is found, bleed power steering system.
(See page SR-5)
(i) Check the fluid level.

Q10145
Attachment
Attachment
IN
OUT
Pressure Feed TubeSST
PS Vane Pump
Z15498
Oil
Reservoir
PS Vane
Pump PS Gear
SST Closed
- STEERINGPOWER STEERING FLUID
SR-7
1996 TERCEL (RM440U)
2. CHECK STEERING FLUID PRESSURE
(a) Disconnect the pressure feed tube from the PS vane
pump. (See page SR-24)
(b) Connect SST, as shown in the illustration below.
SST 09640-10010 (09641-01010, 09641-01030,
09641-01060)
NOTICE:
Check that the valve of the SST is in the open position.
(c) Bleed the power steering system.
(d) Start the engine and run it at idle.
(e) Turn the steering wheel from lock to lock several times to
boost fluid temperature.
Fluid temperature: 80 °C (176 °F)
(f) With the engine idling, close the valve of the SST and ob-
serve the reading on the SST.
Minimum fluid pressure:
6,374 kPa (65 kgf/cm
2, 925 psi)
NOTICE:

Do not keep the valve closed for more than 10 se-
conds.

Do not let the fluid temperature become too high.

Z15499
Oil
Reservoir
PS Vane
Pump PS Gear
SST Open
Z15500
Oil
Reservoir
PS Vane
Pump PS Gear
SST Open Lock Position SR-8
- STEERINGPOWER STEERING FLUID
1996 TERCEL (RM440U)
(g) With the engine idling, open the valve fully.
(h) Measure the fluid pressure at engine speeds of 1,000 rpm
and 3,000 rpm.
Difference fluid pressure:
490 kPa (5 kgf/cm
2, 71 psi) or less
NOTICE:
Do not turn the steering wheel.
(i) With the engine idling and valve fully opened, turn the
steering wheel to full lock position.
Minimum fluid pressure:
6,374 kPa (65 kgf/cm
2, 925 psi)
NOTICE:

Do not maintain lock position for more than 10 se-
conds.

Do not let the fluid temperature become too high.
(j) Disconnect the SST.
(k) Connect the pressure feed tube (See page SR-33).
(l) Bleed the power steering system.

SR0KE-01
R14423
Vacuum Hose
- STEERINGAIR CONTROL VALVE
SR-9
929 Author
: Date
:
1996 TERCEL (RM440U)
AIR CONTROL VALVE
INSPECTION
1. TURN AIR CONDITIONING SWITCH OFF
2. CHECK IDLE-UP
(a) Start the engine and run it at idle.
(b) Fully turn the steering wheel.
(c) Check that the engine rpm decreases when the vacuum
hose is pinched.
(d) Check that the engine rpm increases when the hose is re-
leased.

SR4208
Maximum
Freeplay
30 mm (1.18 in.)SR05R-1 1
R12030
SR-10
- STEERINGSTEERING WHEEL
930 Author
: Date
:
1996 TERCEL (RM440U)
STEERING WHEEL
INSPECTION
1. CHECK STEERING WHEEL FREEPLAY
With the vehicle stopped and tires pointed straight ahead, rock
the steering wheel gently back and forth with light finger pres-
sure.
Freeplay should not exceed the maximum.
Maximum freeplay: 30 mm (1.18 in.)
2. CHECK STEERING EFFORT
(a) Center the steering wheel.
(b) Remove the steering wheel pad (See page SR-13).
(c) Start the engine and run it at idle.
(d) Measure the steering effort in both directions.
Reference: 7.8 N´m (80 kgf´cm, 69 in.´lbf)
HINT:
Be sure to consider the tire type, pressure and contact surface
before making your diagnosis.
(e) Torque the steering wheel set nut.
Torque: 34 N´m (350 kgf´cm, 25 ft´lbf)
(f) Install the steering wheel pad (See page SR-20).

SR17Z-02
- STEERINGNON-TIL T STEERING COLUMN
SR-1 1
931 Author
: Date
:
1996 TERCEL (RM440U)
NON-TIL T STEERING COLUMN
COMPONENTS

SR-12
- STEERINGNON-TIL T STEERING COLUMN
932 Author
: Date
:
1996 TERCEL (RM440U)

SR17R-02
R12031
Torx ScrewScrew Case
R11976
Airbag
Connector
CorrectWrong
R11977
SST Matchmarks
- STEERINGNON-TIL T STEERING COLUMN
SR-13
1996 TERCEL (RM440U)
REMOVAL
1. w/ Airbag:
REMOVE STEERING WHEEL PAD
NOTICE:

If the airbag connector is disconnected with the igni-
tion switch at ON or ACC, DTCs will be recorded.

Never use airbag parts from another vehicle. When
replacing parts, replace with new ones.
(a) Place the front wheels facing straight ahead.
(b) Using a torx socket wrench, loosen the 2 torx screws.
HINT:
Loosen the 2 screws until the groove along the screw circumfer-
ence catches on the screw case.
(c) Pull the wheel pad from the steering wheel and discon-
nect the airbag connector.
CAUTION:

When storing the wheel pad, keep the upper surface
of the pad facing upward.

Never disassemble the wheel pad.
NOTICE:
When removing the wheel pad, take care not to pull the air-
bag wire harness.
2. w/o Airbag:
REMOVE STEERING WHEEL PAD
(a) Remove the screw.
(b) Remove the 3 clips.
3. REMOVE STEERING WHEEL
(a) Disconnect the connector.
(b) Remove the steering wheel set nut.
(c) Place matchmarks on the steering wheel and main shaft
assembly.
(d) Using SST, remove the wheel.
SST 09950-50010 (09951-05010, 09952-05010,
09953-05020, 09954-05020)
