1996 TOYOTA TERCEL Service Repair Manual

BE-8
- BODY ELECTRICALBODY ELECTRICAL SYSTEM
1996 TERCEL (RM440U)
DEFOGGER SYSTEM
TroubleParts nameSee page
Rear window defogger does not operate.
(w/Timer)
1. DEF M-Fuse (I/P J/B)
2. GAUGE Fuse (I/P J/B)
3. Defogger Switch
4. Defogger Relay
5. Defogger Wire
6. Wire Harness-
-
BE-46
BE-46
BE-46
-
Rear window defogger does not operate.
(w/o Timer)
1. DEF M-Fuse (I/P J/B)
2. Defogger Switch
3. Defogger Wire
4. Wire Harness-
BE-46
BE-46
-
POWER WINDOW CONTROL SYSTEM
TroubleParts nameSee page
Power window does not operate.
(Door lock does not operate.)1. POWER M-Fuse (R/B No.7)
2. Wire Harness-
-
Power window does not operate.
(Door lock is normal.)
1. GAUGE Fuse (I/P J/B)
2. Ignition Switch
3. POWER M-Fuse (R/B No.7)
4. Power Main Relay (R/B No.7)
5. Power Window Master Switch
6. Wire Harness-
BE-1 1
-
BE-49
BE-49
-
ºOne Touch Power Window Systemº does not operate.1. Power Window Master SwitchBE-49
Only one window glass does not move.
1. Power Window Master Switch
2. Power Window Switch
3. Power Window Motor
4. Wire HarnessBE-49
BE-49
BE-49
-
ºWindow Lock Systemº does not operate.1. Power Window Master SwitchBE-49
ºWindow Lock Illuminationº does not light up.1. Power Window Master SwitchBE-49

BE0QR-01
I05952
Engine Room R/B
R/B No.5 (CANADA models)
I/P J/BR/B No.7
- BODY ELECTRICALPOWER SOURCE
BE-9
1031 Author
: Date
:
1996 TERCEL (RM440U)
POWER SOURCE
LOCATION

BE0QS-01
I05913
Ignition Switch

Key Unlock Warning Switch
I/P J/B

Integration Relay

GAUGE Fuse
Door Courtesy Switch
BE-10- BODY ELECTRICALIGNITION SWITCH AND KEY UNLOCK WARNING
SWITCH
1032 Author
: Date
:
1996 TERCEL (RM440U)
IGNITION SWITCH AND KEY UNLOCK WARNING SWITCH
LOCATION

BE0QT-02
N12789
Z10028
1
2 OFF
ON
N12790
N12791
- BODY ELECTRICALIGNITION SWITCH AND KEY UNLOCK WARNING
SWITCHBE-1 1
1996 TERCEL (RM440U)
INSPECTION
1. INSPECT IGNITION SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
LOCK-No continuity
ACC2 - 3Continuity
ON2 - 3 - 4
6 - 7Continuity
START1 - 2 - 4
6 - 7 - 8Continuity
If continuity is not as specified, replace the switch.
2. INSPECT KEY UNLOCK WARNING SWITCH
CONTINUITY
ConditionTester connectionSpecified condition
Switch OFF
(Key removed) -No continuity
Switch ON
(Key set)1 - 2Continuity
If continuity is not as specified, replace the switch.
3. INSPECT INTEGRATION RELAY OPERATION
(a) Connect the positive (+) lead from the battery to terminal
3.
(b) Connect the negative (-) lead from the battery to terminal
4, 7 and 8.
(c) Check the chime sounds.
(d) Disconnect the negative (-) lead from the battery to termi-
nal 8.
(e) Check that the chime stops sounding.

N12792
N12793
Junction Block Side BE-12
- BODY ELECTRICALIGNITION SWITCH AND KEY UNLOCK WARNING
SWITCH
1996 TERCEL (RM440U)
(f) Connect the negative (-) lead from the battery to terminal
8.
(g) Disconnect the negative (-) lead from the battery to termi-
nal 4.
(h) Check that the chime stops sounding.
If operation is not as specified, replace the relay.
4. INSPECT INTEGRATION RELAY CIRCUIT
Remove the relay from the instrument panel junction block and
inspect the connectors on the junction block side.
Tester connectionConditionSpecified condition
4 - GroundKey unlock warning switch OFFNo continuity
4 - GroundKey unlock warning switch ONContinuity
5 - GroundBuckle switch OFF
(Seat belt unfastened)No continuity
5 - GroundBuckle switch ON
(Seat belt fastened)Continuity
7 - GroundConstantContinuity
8 - GroundDriver's door courtesy switch OFFNo continuity
8 - GroundDriver's door courtesy switch ONContinuity
11 - GroundLight control switch OFFNo continuity
11 - GroundLight control switch TAIL or HEADContinuity
2 - GroundIgnition switch LOCK or ACCNo voltage
2 - GroundIgnition switch ONBattery positive voltage
3 - GroundConstantBattery positive voltage
9 - GroundIgnition switch LOCK or ACCNo voltage
9 - GroundIgnition switch ONBattery positive voltage
12 - GroundConstantBattery positive voltage
If the circuit is as specified, try replacing the relay with a new
one.
If the circuit is not as specified, inspect the circuits connected
to other parts.

BE0QU-01
I05914
D.R.L. : Daytime Running Light
* : CANADA Models OnlyEngine Room R/B

Headlight Control Relay

HEAD LH Fuse

HEAD RH Fuse

DOME Fuse

DIM M-Fuse

DRL Fuse
R/B No.5

D.R.L No.4 Relay

Headlight Dimmer Relay

HEAD LH-UPR Fuse

HEAD RH-UPR Fuse

HEAD LH-LWR Fuse

HEAD RH-LWR Fuse *
*
Combination Switch

Lignt Control Switch

Headlight Dimmer Switch*
* D.R.L. Main Relay
Door Courtesy Switch
Taillights I/P J/B

Integration Relay

Taillight Control Relay

TAIL Fuse

ECU-IG FuseHeadlights
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE-13
1035 Author
: Date
:
1996 TERCEL (RM440U)
HEADLIGHT AND TAILLIGHT SYSTEM
LOCATION

BE0QV-03
N12366
Light Control SwitchSwitch BodyWiper and Washer Switch
Spiral Cable BE-14
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
1996 TERCEL (RM440U)
COMPONENTS

BE0QW-03
N12796
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE-15
1996 TERCEL (RM440U)
REMOVAL
1. REMOVE UPPER AND LOWER COLUMN COVERS
(See page SR-13)
2. REMOVE LIGHT CONTROL SWITCH
(a) Disconnect the connector.
(b) Remove the 2 screws and the switch .
3. REMOVE WIPER AND WASHER SWITCH
(a) Disconnect the connector.
(b) Remove the 2 screws and the switch .
