Page 329 of 1202
DI4MA-01
DI-154
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TERCEL (RM440U)
PROBLEM SYMPTOMS TABLE
Proceed with troubleshooting of each circuit in the table below.
SymptomSuspect AreaSee page
With the ignition switch at ACC or ON, the SRS warning light
sometimes lights up after approx. 6 seconds have elapsed.
SRS warning light is always lit up even when ignition switch is in
the LOCK position.
SRS warning light system malfunction
(Always lit up when ignition switch is in LOCK position.)DI-180
With the ignition switch at ACC or ON, the SRS warning light
does not light up.SRS warning light system malfunction
(Does not light up, when ignition switch is turned to ACC
or ON.)
DI-182
DTC not displayed.
SRS warning light is always lit up a DTC check procedure.
DTC displayed without Tc and E1 terminal connection.
Tc terminal circuitDI-185
Page 330 of 1202

DI4MB-02
R15075
D squib (w/o Front Passenger Airbag)
1
Spiral
2
D
-
D+
Airbag Sensor Assembly
Cable
B
4
3 (w/ Front Passenger Airbag)
D squib
Spiral
Cable
1
2W
P squib1
22
1 D
-
D+2
1
P
-
P+
B
B W
W
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-155
1996 TERCEL (RM440U)
CIRCUIT INSPECTION
DTC 11 Short in Squib Circuit (to Ground)
CIRCUIT DESCRIPTION
The squib circuit consists of the airbag sensor assembly, spiral cable, steering wheel pad and front passen-
ger airbag assembly. If causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see FUNCTION OF COMPONENTS on page RS-2.
DTC 11 is recorded when ground short is detected in the squib circuit.
DTC No.DTC Detection ConditionTrouble Area
11
Short circuit in squib wire harness (to ground)
Squib malfunction
Spiral cable malfunction
Airbag sensor assembly malfunctionSteering wheel pad (D squib)
Front passenger airbag assembly (P squib)
Spiral cable
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
Page 331 of 1202
R05901
R14290H00004
Airbag Sensor
Assembly
P Squib
D SquibSpiral
Cable
D+
D-
DI-156
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TERCEL (RM440U)
INSPECTION PROCEDURE
1 Preparation. (See step 1 on page DI-177)
2 Check D squib circuit.
CHECK:
For the connector (on the spiral cable side) between the spiral
cable and steering wheel pad, measure the resistance between
D
+, D- and body ground.
OK:
Resistance: 1MW or higher
NG Go to step 7.
OK
Page 332 of 1202
R05896 R14291H00005
Spiral
CableAirbag Sensor
Assembly
P Squib
D SquibP+
P-
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-157
1996 TERCEL (RM440U)
3 Check P squib circuit.
CHECK:
For the connector (on the airbag sensor assembly side) be-
tween the airbag sensor assembly and front passenger airbag
assembly, measure the resistance between P
+, P- and body
ground.
OK:
Resistance: 1MW or Higher
NG Repair or replace harness or connector be-
tween the airbag sensor assembly and front
passenger airbag assembly.
OK
Page 333 of 1202

AB0069
W01933
AB0118
R13006AB0069
AB0118
W02042
H00006
Airbag Sensor
Assembly
Spiral
Cable P Squib
D SquibP+
P-
D+ D-ACCON
or
Code 11
DLC1
Tc
E1
DI-158
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TERCEL (RM440U)
4 Check airbag sensor assembly.
PREPARATION:
(a) Connect connector to airbag sensor assembly.
(b) Using a service wire, connect D+ and D- on spiral cable
side of connector between spiral cable and steering
wheel pad.
(c) Using a service wire, connect P+ and P- on airbag sensor
assembly side of connector between airbag sensor as-
sembly and front passenger airbag assembly.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least 20 se-
conds.
(b) Clear malfunction code stored in memory.
(See page DI-148)
(c) Turn ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least 20 se-
conds.
(e) Using SST, connect terminals Tc and E1 of DLC 1.
SST 09843-18020
(f) Check DTC
OK:
DTC 11 is not output.
HINT:
Codes other than code 11 may be output at this time, but they
are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 334 of 1202

R05896
AB0118
R13006AB0119
W02042
H00007
Spiral
Cable P Squib
D Squib
ACCON
or
DLC1Code 11
E1TcAirbag Sensor
Assembly
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-159
1996 TERCEL (RM440U)
5 Check D squib.
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least 90 seconds.
(c) Connect steering wheel pad connector.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least 20 se-
conds.
(b) Clear malfunction code stored in memory.
(See page DI-148)
(c) Turn ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least 20 se-
conds.
(e) Using SST, connect terminals Tc and E1 of DLC 1.
SST 09843-18020
(f) Check DTC.
OK:
DTC 11 is not output.
HINT:
Codes other than code 11 may be output at this time, but they
are not relevant to this check.
NG Replace steering wheel pad.
OK
Page 335 of 1202

R05897
AB0118
R13006AB0119
W02042H00008
Airbag Sensor
Assembly
Spiral
Cable P Squib
D Squib
ACCON
or
DLC1
E1TcCode 11
DI-160
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TERCEL (RM440U)
6 Check P squib.
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least 90 seconds.
(c) Connect front passenger airbag assembly connector.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least 20 se-
conds.
(b) Clear malfunction code stored in memory.
(See page DI-148)
(c) Turn ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least 20 se-
conds.
(e) Using SST, connect terminals Tc and E1 of DLC 1.
SST 09843-18020
(f) Check DTC.
OK:
DTC 11 is not output.
HINT:
Codes other than code 11 may be output at this time, but they
are not relevant to this check.
NG Replace front passenger airbag assembly.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 336 of 1202
R05899
R14301H00009
Airbag Sensor
Assembly
Spiral
Cable P Squib
D Squib
D+
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-161
1996 TERCEL (RM440U)
7 Check spiral cable.
PREPARATION:
Disconnect connector between airbag sensor assembly and
spiral cable.
CHECK:
Measure resistance between D+ on spiral cable side of connec-
tor between spiral cable and steering wheel pad and body
ground.
OK:
Resistance: 1MW or Higher
NG Repair or replace spiral cable.
OK
Repair or replace harness or connector be-
tween airbag sensor assembly and spiral
cable.
