STEERING WHEEL AND COLUMN 6E–11
DAEWOO M-150 BL2
D105A515
STEERING COLUMN
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the steering wheel. Refer to “Steering Wheel”
in this section.
Caution: Disconnect the negative battery cable and
let the vehicle sit for 1 minute to deactivate the air-
bag (For vehicle with SIR)
2. Remove the turn signal switch and wiper switch. Re-
fer to “Turn Signal Switch and Lever/Wiper Switch
and Lever in this section.
3. Remove the switch housing. Refer to “Switch Hous-
ing” in this section.
D105A516
4. Remove the ignition switch. Refer to “Ignition Switch”
in this section.
5. Remove the ignition lock cylinder. Refer to “Ignition
Lock Cylinder” in this section.
6. Remove the steering column.

Match–mark on the intermediate shaft and the
steering column shaft (1).

Remove the intermediate shaft upper pinch bolt
(2).

Remove the steering column lower nuts (3).

Remove the steering column upper nuts (4).
D15A517B
D15A518B
Installation Procedure
Important: Align the match–mark on the intermediate
shaft and the steering column shaft.
1. Install the steering column.

Install the intermediate shaft upper pinch bolt (1).
Tighten
Tighten the pinch bolt to 21–29 Nm (16–22 lb-ft).

Install the steering column lower nuts (2).
Tighten
Tighten the nuts to 15–20 Nm (11–15 lb-ft).

Install the steering column upper nuts (3).
Tighten
Tighten the nuts to 15–20 Nm (11–15 lb-ft).
2. Install the ignition lock cylinder. Refer to “Ignition Lock
Cylinder” in this section.
3. Install the ignition switch. Refer to “Ignition Switch” in
this section.
4. Install the switch housing. Refer to “Switch Housing”
in this section.
5. Install the turn signal switch and wiper switch. Refer
to “Turn Signal Switch and Lever/Wiper Switch and
Lever” in this section.
6. Install the steering wheel. Refer to “Steering Wheel”
in this section.

6E –12 STEERING WHEEL AND COLUMN
DAEWOO M-150 BL2
D105A520
INTERMEDIATE SHAFT COVER AND
INTERMEDIATE SHAFT
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the intermediate shaft.

In order to install the intermediate shaft correctly,
match–mark the intermediate shaft to the steering
column. (1).

Remove the intermediate shaft upper pinch bolt
(2).

Remove the intermediate shaft lower pinch bolt
(3).
D15A521A
Installation Procedure
1. Install the intermediate shaft with the bolts.
Tighten

Tighten the intermediate shaft lower pinch bolt to
21–29 Nm (16–22 lb-ft) (1).

Tighten the intermediate shaft upper pinch bolt to
21–29 Nm (16–22 lb-ft) (2).
Notice: Check the lower pinch bolt position correctly.

STEERING WHEEL AND COLUMN 6E–13
DAEWOO M-150 BL2
UNIT REPAIR
D105A701
D15A702A
D15A703A
STANDARD STEERING COLUMN
Disassembly Procedure
1. Remove the steering column from the vehicle. Refer
to “Steering Column” in this section.
Caution: Be careful not to impact on the steering
column shaft. Plastic sleeve may be broken that is
installed to secure the driver at the accident.
2. Remove the steering column shaft from the steering
column.

Remove the retaining ring (1).

Remove the washer (2).

Remove the spring (3).

Remove the washer (4).

Remove the locking of the alignment spacer (5).

Push strongly the steering column shaft downward
(6).

6E –14 STEERING WHEEL AND COLUMN
DAEWOO M-150 BL2
D15A704A
Assembly Procedure
Important: Position the alignment spacer on the lower
column shaft to install the spacer in the steering column
jacket easily.
1. Install the steering column shaft to the steering col-
umn.

Position the locking of the alignment spacer on the
groove of the steering column.

Install the washer.

Install the spring.

Install the washer.

Install the retaining ring.
2. Install the steering column to the vehicle. Refer to
“Steering Wheel” in this section.

STEERING WHEEL AND COLUMN 6E–15
DAEWOO M-150 BL2
SPECIFICATIONS
GENERAL SPECIFICATIONS

Application

Unit

Description
With Airbagmm (in.)

380 (14.96)
Steering Wheel
DiameterWithout Airbagmm (in.)

370 (14.57) Steering Wheel
Free Play (Engine Stop)mm (in.)

0 ± 20 (0 ± 0.79)
FASTENER TIGHTENING SPECIFICATIONS
Application Nm Lb-Ft Lb-In
Steering Wheel Nut 23 – 33 17 – 24 –
Steering Column Upper Nuts 15 – 20 11 – 15 –
Steering Column Lower Nuts 15 – 20 11 – 15 –
Intermediate Shaft Upper Pinch Bolt 21 – 29 16 – 22 –
Intermediate Shaft Lower Pinch Bolt 21 – 29 16 – 22 –

6E –16 STEERING WHEEL AND COLUMN
DAEWOO M-150 BL2
SPECIAL TOOLS AND EQUIPMENT
SPECIAL TOOLS TABLE
D105A101
DW310–010
Steering Wheel Puller

DAEWOO M-150 BL2
SECTION 7A
HEATING AND VENTILATION SYSTEM
CAUTION: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in B unless otherwise
noted.
TABLE OF CONTENTS
Description and Operation 7A-2. . . . . . . . . . . . . . . . . .
Heating and Ventilation Systems 7A-2. . . . . . . . . . . .
Component Locator 7A-3. . . . . . . . . . . . . . . . . . . . . . . .
Control Assembly 7A-3. . . . . . . . . . . . . . . . . . . . . . . . .
Blower Module Assembly 7A-4. . . . . . . . . . . . . . . . . . .
Air Distributor and Heater Module
Assembly 7A-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Informatin and Procedures 7A-6. . . . . . .
Heater System 7A-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Insufficient Heating or Defrosting 7A-6. . . . . . . . . . . .
Blower Electrical 7A-10. . . . . . . . . . . . . . . . . . . . . . . . .
Improper Air Delivery or No Mode Shift 7A-11. . . . . .
Too Much Heat 7A-13. . . . . . . . . . . . . . . . . . . . . . . . . . .
Controls 7A-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blower Noise 7A-16. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Repair Instructions 7A-18. . . . . . . . . . . . . . . . . . . . . . . .
On-Vehicle Service 7A-18. . . . . . . . . . . . . . . . . . . . . . . . .
Control Assembly and Control Cables 7A-18. . . . . . . Blower Motor and Cooling Hose 7A-20. . . . . . . . . . . .
Blower Resistor 7A-20. . . . . . . . . . . . . . . . . . . . . . . . . .
Blower Motor Switch 7A-21. . . . . . . . . . . . . . . . . . . . . .
Heater Hoses 7A-22. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heater Module 7A-24. . . . . . . . . . . . . . . . . . . . . . . . . . .
Blower Module 7A-25. . . . . . . . . . . . . . . . . . . . . . . . . . .
Defroster Duct and Hoses 7A-26. . . . . . . . . . . . . . . . .
Ventilation Duct 7A-27. . . . . . . . . . . . . . . . . . . . . . . . . .
Unit Repair 7A-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heater Core 7A-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 7A-29. . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 7A-29. . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 7A-29. . . . . . . . . .
Special Tools and Equipment 7A-30. . . . . . . . . . . . . .
Special Tools Table 7A-30. . . . . . . . . . . . . . . . . . . . . . .
Schematic and Routing Diagrams 7A-31. . . . . . . . . .
Non-A/C Diagrams 7A-31. . . . . . . . . . . . . . . . . . . . . . .
Air Flow Through Ducts (Non–A/C) 7A-32. . . . . . . . .

7A–2 HEATING AND VENTILATION SYSTEM
DAEWOO M-150 BL2
DESCRIPTION AND SYSTEM OPERATION
HEATING AND VENTILATION
SYSTEMS
The base heater system is designed to provide heating,
ventilation, windshield defrosting, and side window de-
fogging.
The heater and fan assembly blower regulates the air-
flow from the air inlet for further processing and distribu-
tion.
The heater core transfers the heat from the engine cool-
ant to the inlet air.
The temperature door regulates the amount of the air
that passes through the heater core. The temperature
door also controls the temperature of the air by control-
ling the mix of the heated air and the ambient air.
The mode door regulates the flow and the distribution
of the processed air to the heater ducts and to the de-
froster ducts.
This console-mounted heating and ventilation panel
contains the following:
Three Rotary Control Knobs
1. The Rotary Temperature Control Knob

Actuates by cable.

Raises the temperature of the air entering the ve-
hicle by rotation toward the right, or the red portion
of the knob.
2. The Rotary Blower Control Knob

Turns on to operate the blower motor at four speeds.

Turns
to stop the blower.

Operates completely independently both from the
mode control that regulates the defroster door and
from the temperature control knob.
Changes the fan speed in any mode and at any
temperature setting.
3. The Rotary Mode Control Knob:

Actuates by cable.

Regulates the air distribution between the wind-
shield, the instrument panel, and the floor vents.
Push Knobs
1. The Rear Window Defogger Push Knob

Controls the rear window defogger.

Turns ON the rear window defogger when the push
knob is pressed and the indicator lamp is illumi-
nated.
2. The A/C Push Knob (if the vehicle is equipped with air
conditioning)

Controls the A/C.

Turns the A/C ON when the push knob is down.
However, if the blower control knob is OFF, the A/C
system is OFF, regardless of the position of the
A/C knob.
One Lever
1. The Fresh Air Control Lever

Operates by cable.

Switches between recirculating passenger compart-
ment air and bringing outside air into the passenger
compartment.

Draws in outside air when the lever is moved to the
left.

Recirculates inside air when the lever is moved to
the right.
