2003 DAEWOO MATIZ Service Repair Manual

ENGINE CONTROLS 1F–31
DAEWOO M-150 BL2
No Malfunction Indicator Lamp
StepActionValue(s)YesNo
1
Attempt to start the engine.
Does the engine start?
–
Go to Step 2
Go to “Engine
Cranks But
Will Not Run”
2
1. Turn the ignition OFF.
2. Disconnect the engine control module (ECM)
connector.
3. Turn the ignition ON.
4. Connect a test light between terminal 68 of ECM
connector and ground.
Is the test light on?
–
Go to Step 3Go to Step 6
3Check terminals for damage or poor connection.
Does any problem found?–Go to Step 5Go to Step 4
4
Replace ECM
Is the repair complete?
–
Go to “On
Board
Diagnostic
System Check”
–
5
Repair any damaged terminals or poor connection.
Is the repair complete?
–
Go to “On
Board
Diagnostic
System Check”
–
6Check the fuse F1.
Is the fuse blown?–Go to Step 7Go to Step 8
7
1. Check for a short to ground in the circuit and
repair as needed.
2. Replace the blown fuse.
Is the repair complete?
–
Go to “On
Board
Diagnostic
System Check”
–
8
1. Check for an open circuit between fuse F16 and
terminal 68 of ECM connector and repair as
needed.
2. Check the MIL bulb and replace if blown.
Is the repair complete?
–
Go to “On
Board
Diagnostic
System Check”
–

1F–32 ENGINE CONTROLS
DAEWOO M-150 BL2
MAA1F030
MALFUNCTION INDICATOR LAMP ON STEADY
Circuit Description
When the ignition is turned ON, the Malfunction Indica-
tor Lamp (MIL) will be turned ON and remain ON until
the engine is running, if no Diagnostic Trouble Codes
(DTCs) are stored. Battery voltage is supplied throughthe ignition switch directly to the MIL telltale. The Engine
Control Module (ECM) controls the MIL by providing a
ground path through the MIL control circuit to turn ON
the MIL.

ENGINE CONTROLS 1F–33
DAEWOO M-150 BL2
Malfunction Indicator Lamp On Steady
StepActionValue(s)YesNo
1
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
Is the check complete.
–
Go to Step 2
Go to “Euro
On-Board
Diagnostic
System Check”
2
1. Turn the ignition OFF.
2. Install the scan tool.
3. Command the Malfunction Indicator Lamp (MIL)
on and off.
Does the MIL turn on and off when commanded?
–
Go to Step 7Go to Step 3
3
1. Turn the ignition OFF.
2. Disconnect the engine control module (ECM)
connector.
3. Turn the ignition ON.
Is the MIL off?
–
Go to Step 6Go to Step 4
4
Check the MIL control circuit for a short to ground
and repair as needed.
Is a repair necessary?
–
Go to Step 7Go to Step 5
5
Replace the instrument panel cluster. Refer to
Section 9E, Instrumentation/Driver Information.
Is the repair complete?
–
Go to Step 7
–
6Replace the ECM.
Is the repair complete?–Go to Step 7–
7
1. Using the scan tool, clear the Diagnostic Trouble
Codes(DTCs).
2. Attempt to start the engine.
Does the engine start and continue to run?
–
Go to Step 8Go to Step 1
8
Allow the engine to idle until normal operating
temperature is reached.
Check if any DTCs are set.
Are any DTCs displayed that have not been
diagnosed?
–
Go to applicable
DTC table
System OK

1F–34 ENGINE CONTROLS
DAEWOO M-150 BL2
FUEL SYSTEM DIAGNOSIS
Circuit Description
The fuel pump is an in-tank type mounted to a fuel send-
er assembly. The fuel pump will remain on as long as the
engine is cranking or running and the Engine Control
Module (ECM) is receiving reference pulses from the
crankshaft position (CKP) sensor. If there are no refer-
ence pulses, the ECM will turn off the fuel pump two sec-
onds after the ignition switch is turned ON or two
seconds after the engine stops running. The fuel pump
delivers fuel to the fuel rail and the fuel injectors, where
the fuel system pressure is controlled from 380 kPa (55
psi) by the fuel pressure regulator. The excess fuel is re-
turned to the fuel tank.
Caution: The fuel system is under pressure. To
avoid fuel spillage and the risk of personal injury orfire, it is necessary to relieve the fuel system pres-
sure before disconnecting the fuel lines.
Caution: Do not pinch or restrict nylon fuel lines.
Damage to the lines could cause a fuel leak, result-
ing in possible fire or personal injury.
Fuel Pressure Relief Procedure
1. Remove the fuel cap.
2. Remove the fuel pump fuse EF23 from the engine
fuse block.
3. Start the engine and allow the engine to stall.
4. Crank the engine for an additional 10 seconds.
Fuel System Pressure Test
Step Action Value(s) Yes No




1




1. Relieve the fuel system pressure.
2. Install a fuel pressure gauge.
3. Turn the ignition ON.
Is the fuel pressure around the values specified and
holding steady?



380 kPa
(55 psi)



System OK



Go to Step 2




2




1. Relieve the fuel system pressure.
2. Install a fuel pressure gauge.
3. Turn the ignition ON.
Is the fuel pressure around the values specified but
not holding steady?


380 kPa
(55 psi)



Go to Step 13



Go to Step 3

3

Inspect the fuel lines for a leak.
Is the problem found?
–

Go to Step 4

Go to Step 5




4




1. Replace the fuel line(s) as needed.
2. Install a fuel pressure gauge.
3. Turn the ignition ON.
Is the fuel pressure around the values specified and
holding steady?


380 kPa
(55 psi)



System OK




–




5




1. Remove the fuel pump assembly.
2. With the fuel pump under pressure, inspect the
fuel pump coupling hoses for leaking.
Is the problem found?



–



Go to Step 6



Go to Step 7





6





1. Tighten or replace the fuel pump coupling hoses
as needed.
2. Install a fuel pressure gauge.
3. Turn the ignition ON.
Is the fuel pressure around the values specified and
holding steady?




380 kPa
(55 psi)




System OK




Go to Step 8

7


With the fuel system under pressure, inspect the fuel
return outlet for leaking.
Is the problem found?
–

Go to Step 8

Go to Step 9

ENGINE CONTROLS 1F–35
DAEWOO M-150 BL2
Fuel System Pressure Test (Cont’d)
Step Action Value(s) Yes No




8




1. Replace the fuel pressure regulator.
2. Install a fuel pressure gauge.
3. Turn the ignition ON.
Is the fuel pressure around the values specified and
holding steady?



380 kPa
(55 psi)



System OK




–



9



With the fuel system under pressure, inspect the fuel
return inlet for leaking.
Is the problem found?


–


Go to Step 10


Go to Step 11




10




1. Replace the fuel pump assembly.
2. Install a fuel pressure gauge.
3. Turn the ignition ON.
Is the fuel pressure around the values specified and
holding steady?



380 kPa
(55 psi)



System OK




–




11




1. Remove the fuel rail and the fuel injectors as an
assembly.
2. With the fuel system under pressure, inspect all
of the fuel injectors for leaking.
Is the problem found?



–



Go to Step 12




–




12




1. Replace the leaking fuel injector(s).
2. Install a fuel pressure gauge.
3. Turn the ignition ON.
Is the fuel pressure around the values specified and
holding steady?


380 kPa
(55 psi)



System OK




–





13





1. Replace the fuel pressure regulator.
2. Start the engine.
3. Allow the engine to idle.
Is the fuel pressure around the values specified and
holding steady?




380 kPa
(55 psi)




System OK





–

1F–36 ENGINE CONTROLS
DAEWOO M-150 BL2
MAA1F040
FUEL PUMP RELAY CIRCUIT CHECK
Circuit Description
When the ignition switch is turned ON, the Engine Con-
trol Module (ECM) will supply battery voltage to activate
the fuel pump relay and run the in-tank fuel pump. The
fuel pump will operate as long as the engine is cranking
or running and the ECM is receiving ignition reference
pulses.If there are no reference pulses, the ECM will shut off
the fuel pump within 2 seconds after the ignition switch
is turned ON.
Diagnostic Aids
An intermittent problem may be caused by a poor con-
nection, rubbed through wire insulation, or a broken wire
inside the insulation.
Fuel Pump Relay Circuit Check
StepActionValue(s)YesNo
1
1. Turn the ignition OFF for 10 seconds.
2. Turn the ignition ON.
3. Listen for in-tank fuel pump operation.
Does the fuel pump operate for the time specified?
2 secSystem OKGo to Step 2
2
1. Turn the ignition OFF.
2. Connect battery positive to fuel pump test
connect.
3. Listen for in-tank fuel pump operation.
Does the fuel pump operate?
–
Go to Step 4Go to Step 3

ENGINE CONTROLS 1F–37
DAEWOO M-150 BL2
Fuel Pump Relay Circuit Check (Cont’d)
StepActionValue(s)YesNo
3
1. Check for an open circuit between fuel pump test
connector and ground G401, and repair as
needed.
2. Check for the fuel cut-off switch and reset or
replace the fuel cut off switch.
Is the repair complete?
–
System OKGo to Step 4
4
1. Turn the ignition OFF.
2. Disconnect the fuel pump relay.
3. Connect a test light between the fuel pump relay
connector terminal 66 and battery positive.
4. Turn the ignition ON.
Is the test light on?
–
Go to Step 6Go to Step 5
5
Check for an open circuit between terminal 66 of fuel
pump relay and battery positive and repair as
needed.
Is the repair complete?
–
System OK
–
6
1. Turn the ignition OFF.
2. Connect a test light between the fuel pump relay
connector terminal 85 and ground.
3. Turn the ignition ON.
Is the test light on?
2 secGo to Step 8Go to Step 7
7
Check for an open circuit between terminal 85 of fuel
pump relay and terminal 10 of ECM, and repair as
needed.
Is the repair complete?
–
System OK
–
8
1. Turn the ignition OFF.
2. Connect a test light between the fuel pump relay
connector terminal 30 and ground.
Is the test light on?
–
Go to Step 10Go to Step 9
9
1. Check the fuse EF19, if blown, repair short circuit
between fuel pump relay 30 terminal.
2. Replace the fuse as needed.
3. Repair an open circuit as needed.
Is the repair complete?
–
System OK
–
10
1. Turn the ignition OFF.
2. Measure the resistance between following
terminals:

Terminal 87 of fuel pump relay and terminal 1
of the fuel cut-off switch(or terminal 1 of
connector C201).
Does the resistance within the value specified.
0 ΩGo to Step 12Go to Step 11
11Repair an open circuit as needed.
Is the repair complete?–System OK–
12Replace the fuel pump relay.
Is the repair complete?–System OKGo to Step 13
13Replace the ECM.
Is the repair complete?–System OK–

1F–38 ENGINE CONTROLS
DAEWOO M-150 BL2
MAA1F050
MAIN RELAY CIRCUIT CHECK
Circuit Description
When the ignition is turned On or to the START position,
the main relay is energized. The main relay then supply
voltage to the engine fuse block fuse EF25 and EF26.
The Electronic Ignition (EI) system ignition coil is sup-
plied voltage through the engine fuse block fuse EF26.
The fuel injectors are supplied voltage through the en-
gine fuse block fuse EF25.Diagnostic Aids

An intermittent problem may be caused by a poor
connection, rubbed through wire insulation, or a bro-
ken wire inside the insulation.

A fault main relay will cause a no start condition.
There will be no voltage supplied to the EI system
ignition coil, or the fuel injectors. Without voltage sup-
plied to these components, they will not operate.
