2003 DAEWOO MATIZ Service Repair Manual

SEATS 9H–3
DAEWOO M-150 BL2
COMPONENT LOCATOR
FRONT SEAT
D109B402
1. Head Restraint
2. Guide Sleeve
3. Seatback
4. Seatback Frame
5. Seat Cushion6. Seat Cushion Frame
7. Recliner
8. Recliner Knob
9. Seat Side Cover
10. Guide Rail

9H –4 SEATS
DAEWOO M-150 BL2
REAR SEAT
D19B403A
1. Rear Seatback Cushion
2. Rear Seatback Frame
3. Rear Seat Hinge
4. Rear Seat Lock
5. Rear Seat Cushion6. Seat Release Knob
7. Eyelet
8. Seat Back Hinge
9. Rear Cushion Pull Loop

SEATS 9H–5
DAEWOO M-150 BL2
REPAIR INSTRUCTIONS
ON–VEHICLE SERVICE
D109B528
FRONT SEATS
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the front seat.

Remove the bolts (1).

Disconnect the seat belt warning lamp connector
(2).

Remove the seat (3).
23–28 Nm
D19B529A
Installation Procedure
1. Connect the seat belt warning lamp connector.
2. Install the front seat with the bolts.
Tighten
Tighten the seat bolt to 23–28 Nm (17–21 lb-ft).
a. Seat bolt.
3. Connect the negative battery cable.
D109B530
HEAD RESTRAINT
Removal Procedure
1. Pull the head restraint up to the stop position.
2. Insert a small flathead screwdriver in the notch in the
left guide sleeve and pull up the head restraint by
pushing the head restraint left.

9H –6 SEATS
DAEWOO M-150 BL2
D109B531
Installation Procedure
1. Install the head restraint into the guide sleeves. Press
down in order to engage the stop pin.
D109B532
FRONT SEATBACK
Removal Procedure
1. Disconnect the negative battery.
2. Remove the front seat assembly. Refer to “Front
Seats” in this section.
3. Remove the recliner knob from the front seat.

Remove the screw (1).

Remove the recliner knob (2).
D109B533
4. Remove the recliner cover from the front seat.

Remove the screws (1).

Remove the recliner cover (2).
D109B534
5. Remove the recliner from the front seat.

Remove the bolts on the seat cushion (1).

Remove the seatback cover hog rings.

Remove the seatback cover (2).

Remove the bolts on the seatback (3).

SEATS 9H–7
DAEWOO M-150 BL2
D109B535
2
1
6. Remove the seatback bolt from the seat cushion (1).
7. Remove the seatback assembly (2).
D109B536
Installation Procedure
1. Install the seatback assembly with the bolt.
2. Install the recliner with the bolts
3. Install the seatback cover with the hog rings.
D109B537
4. Install the recliner knob and the cover with the
screws.
5. Install the front seat assembly. Refer to “Front Seat”
in this section.
6. Connect the negative battery cable.
D109B532
FRONT SEAT CUSHION
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the front seat assembly. Refer to “Front
Seat” in this section.
3. Remove the seat belt buckle. Refer to Section 8A,
Seat Belts.
4. Remove the recliner knob.

Remove the screw (1).

Remove the recliner knob (2).

9H –8 SEATS
DAEWOO M-150 BL2
D109B533
5. Remove the recliner cover.

Remove the screws (1).

Remove the recliner cover (2).
D109B538
6. Remove the seat cushion.

Remove the recliner bolts on the seat cushion (1).

Remove the seatback bolt (2).

Remove the seat cushion (3).
D109B536
Installation Procedure
1. Install the seat cushion with the seatback bolt and the
recliner bolts.
D109B537
2. Install the recliner cover and the recliner knob with the
screws.
3. Install the seat belt buckle. Refer to Section 8A, Seat
Belts.
4. Install the front seat assembly. Refer to “Front Seats”
in this section.
5. Connect the negative battery cable.

SEATS 9H–9
DAEWOO M-150 BL2
D109B539
FRONT SEATS GUIDE RAIL
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the front seat assembly. Refer to “Front
Seats” in this section.
3. Remove the guide rail from the seat.

Remove the bolts (1).

Remove the guide rail (2).
D109B540
Installation Procedure
1. Install the guide rail to the seat with the bolts.
2. Install the front seat assembly. Refer to “Front Seat”
in this section.
3. Connect the negative battery cable.
D109B539
FRONT SEAT CUSHION FRAME
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the front seat cushion. Refer to “Front Seat
Cushion” in this section.
3. Remove the guide rail.

Remove the bolts (1).

Remove the guide rail (2).
D109B541
4. Remove the seat cushion cover.

Remove the hog rings.
5. Remove the seat cushion frame.

9H –10 SEATS
DAEWOO M-150 BL2
D109B541
Installation Procedure
1. Install the seat cushion cover with the hog rings.
D109B540
2. Install the guide rail with the bolts.
3. Install the front seat cushion. Refer to “Front Seat
Cushion” in this section.
4. Connect the negative battery cable.
D109B542
REAR SEATBACK
Removal Procedure
1. Remove the rear seatback.

Remove the rear seatback lock by pulling the lock
knob upward (1).

Remove the seatback hinge bolts (2).

Remove the rear seatback (3).
D19B543A
23–28 Nm
Installation Procedure
1. Install the rear seatback with the hinge bolts.
Tighten
Tighten the hinge bolts to 23–28 N.m (17–21 lb-ft).
a. Rear seatback hinge bolt.
2. Press the lock knob.
