1E–2 ENGINE ELECTRICAL
DAEWOO M-150 BL2
DESCRIPTION AND OPERATION
BATTERY
The battery has three major functions in the electrical
system. First, the battery provides a source of energy
for cranking the engine. Second, the battery acts as a
voltage stabilizer for the electrical system. Finally, the
battery can, for a limited time, provide energy when the
electrical demand exceeds the output of the generator.
The sealed battery is standard on all cars. There are no
vent plugs in the cover. The battery is completely
sealed, except for two small vent holes in the sides.
These vent holes allow the small amount of gas pro-
duced in the battery to escape.
The sealed battery has the following advantages over
conventional batteries:

No water need be added for the life of the battery.

It is protected against overcharge. If too much volt-
age is applied to the battery, it will not accept as much
current as a conventional battery. In a conventional
battery, the excess voltage will still try to charge the
battery, leading to gassing, which causes liquid loss.

It is not as liable to self-discharge as a conventional
battery. This is particularly important when a battery
is left standing for long periods of time.

It has more power available in a lighter and a smaller
case.
RATINGS
A battery has two ratings: (1) A reserve capacity rating
designated at 27C (81F), which is the time a fully
charged battery will provide 25 amperes current flow at
or above 10.5 volts; (2) A cold cranking amp rating de-
termined under testing at -18C (0F), which indicates
the cranking load capacity.
RESERVE CAPACITY
The reserve capacity is the maximum length of time it is
possible to travel at night with the minimum electrical
load and no generator output. Expressed in minutes,
Reserve Capacity (or RC rating) is the time required for
a fully charged battery, at a temperature of 27C (81F)
and being discharged at a current of 25 amperes, to
reach a terminal voltage of 10.5 volts.
COLD CRANKING AMPERAGE
The cold cranking amperage test is expressed at a bat-
tery temperature of -18C (0F). The current rating is
the minimum amperage, which must be maintained by
the battery for 30 seconds at the specified temperature,
while meeting a minimum voltage requirement of
7.2 volts. This rating is a measure of cold cranking ca-
pacity.The battery is not designed to last indefinitely. However,
with proper care, the battery will provide many years of
service.
If the battery tests well, but fails to perform satisfactorily
in service for no apparent reason, the following factors
may point to the cause of the trouble:

Vehicle accessories are left on overnight.

Slow average driving speeds are used for short peri-
ods.

The vehicle’s electrical load is more than the genera-
tor output, particularly with the addition of aftermarket
equipment.

Defects in the charging system, such as electrical
shorts, a slipping generator belt, a faulty generator, or
a faulty voltage regulator.

Battery abuse, including failure to keep the battery
cable terminals clean and tight, or a loose battery
hold-down.

Mechanical problems in the electrical system, such
as shorted or pinched wires.
BUILT-IN HYDROMETER
The sealed battery has a built-in, temperature-compen-
sated hydrometer in the top of the battery. This hydrom-
eter is to be used with the following diagnostic
procedure:
1. When observing the hydrometer, make sure that the
battery has a clean top.
2. Under normal operation, two indications can be ob-
served:

GREEN DOT VISIBLE – Any green appearance is
interpreted as a “green dot,” meaning the battery is
ready for testing.

DARK GREEN DOT IS NOT VISIBLE – If there is
a cranking complaint, the battery should be tested.
The charging and electrical systems should also
be checked at this time.
3. Occasionally, a third condition may appear:

CLEAR OR BRIGHT YELLOW – This means the
fluid level is below the bottom of the hydrometer.
This may have been caused by excessive or pro-
longed charging, a broken case, excessive tipping,
or normal battery wear. Finding a battery in this
condition may indicate high charging by a faulty
charging system. Therefore, the charging and the
electrical systems may need to be checked if a
cranking complaint exists. If the cranking com-
plaint is caused by the battery, replace the battery.

ENGINE ELECTRICAL 1E–3
DAEWOO M-150 BL2
CHARGING PROCEDURE
1. Batteries with the green dot showing do not require
charging unless they have just been discharged, such
as in cranking a vehicle.
2. When charging sealed-terminal batteries out of the
vehicle, install the adapter kit. Make sure all the char-
ger connections are clean and tight. For best results,
batteries should be charged while the electrolyte and
the plates are at room temperature. A battery that is
extremely cold may not accept current for several
hours after starting the charger.
3. Charge the battery until the green dot appears. The
battery should be checked every half-hour while
charging. Tipping or shaking the battery may be nec-
essary to make the green dot appear.
4. After charging, the battery should be load tested. Re-
fer to “Starter Motor” in this section.
CHARGING TIME REQUIRED
The time required to charge a battery will vary depend-
ing upon the following factors:

Size of Battery – A completely discharged large
heavy-duty battery requires more than twice the re-
charging as a completely discharged small passenger
car battery.

Temperature – A longer time will be needed to
charge any battery at -18C (0F) than at 27C
(81F). When a fast charger is connected to a cold
battery, the current accepted by the battery will be
very low at first. The battery will accept a higher cur-
rent rate as the battery warms.

Charger Capacity – A charger which can supply only
5 amperes will require a much longer charging period
than a charger that can supply 30 amperes or more.

State-of-Charge – A completely discharged battery
requires more than twice as much charge as a one-
half charged battery. Because the electrolyte is nearly
pure water and a poor conductor in a completely dis-
charged battery, the current accepted by the battery
is very low at first. Later, as the charging current
causes the electrolyte acid content to increase, the
charging current will likewise increase.
CHARGING A COMPLETELY
DISCHARGED BATTERY
(OFF THE VEHICLE)
Unless this procedure is properly followed, a perfectly
good battery may be needlessly replaced.
The following procedure should be used to recharge a
completely discharged battery:
1. Measure the voltage at the battery terminals with an
accurate voltmeter. If the reading is below 10 volts,
the charge current will be very low, and it could take
some time before the battery accepts the current inexcess of a few milliamperes. Refer to “Charging
Time Required” in this section, which focuses on the
factors affecting both the charging time required and
the rough estimates in the table below. Such low cur-
rent may not be detectable on ammeters available in
the field.
2. Set the battery charger on the high setting.
Important: Some chargers feature polarity protection
circuitry, which prevents charging unless the charger
leads are correctly connected to the battery terminals. A
completely discharged battery may not have enough
voltage to activate this circuitry, even though the leads
are connected properly, making it appear that the bat-
tery will not accept charging current. Therefore, follow
the specific charger manufacturer’s instruction for by-
passing or overriding the circuitry so that the charger will
turn on and charge a low-voltage battery.
3. Battery chargers vary in the amount of voltage and
current provided. The time required for the battery to
accept a measurable charger current at various volt-
ages may be as follows:
VoltageHours
16.0 or moreUp to 4 hours
14.0–15.9Up to 8 hours
13.9 or lessUp to 16 hours

If the charge current is not measurable at the end
of the above charging times, the battery should be
replaced.

If the charge current is measurable during the
charging time, the battery is good, and charging
should be completed in the normal manner.
Important: It is important to remember that a complete-
ly discharged battery must be recharged for a sufficient
number of ampere hours (AH) to restore the battery to a
usable state. As a general rule, using the reserve capac-
ity rating (RC) as the number of ampere hours of charge
usually brings the green dot into view.

If the charge current is still not measurable after
using the charging time calculated by the above
method, the battery should be replaced.

If the charge current is measurable during the
charging time, the battery is good, and charging
should be completed in the normal manner.
JUMP STARTING PROCEDURE
1. Position the vehicle with the good (charged) battery
so that the jumper cables will reach from one battery
to the other.
2. Turn off the ignition, all the lights, and all the electrical
loads in both vehicles. Leave the hazard flasher on if
there may be other traffic and any other lights needed
for the work area.

1E–4 ENGINE ELECTRICAL
DAEWOO M-150 BL2
3. In both vehicles, apply the parking brake firmly.
Notice: Make sure the cables are not on or near pulleys,
fans, or other parts that will move when the engine
starts, damaging the parts.
4. Shift a manual transaxle to NEUTRAL.
Caution: Do not use cables that have loose or miss-
ing insulation, or injury could result.
5. Clamp one end of the first jumper cable to the positive
terminal on the battery. Make sure it does not touch
any other metal parts. Clamp the other end of the
same cable to the positive terminal on the other bat-
tery. Never connect the other end to the negative ter-
minal of the discharged battery.
Caution: Do not attach the cable directly to the neg-
ative terminal of the discharged battery. Doing so
could cause sparks and possible battery explosion.
6. Clamp one end of the second cable to the negative
terminal of the booster battery. Make the final con-
nection to a solid engine ground, such as the engine
lift bracket, at least 450 millimeters (18 inches) from
the discharged battery.
7. Start the engine of the vehicle with the good battery.
Run the engine at a moderate speed for several min-
utes. Then start the engine of the vehicle which has
the discharged battery.
8. Remove the jumper cables by reversing the above
sequence exactly. Remove the negative cable from
the vehicle with the discharged battery first. While re-
moving each clamp, take care that it does not touch
any other metal while the other end remains at-
tached
.
GENERATOR
The Delco-Remy CS charging system has several mod-
els available, including the ∅114D (A-type) or CS114D
(B-type). The number denotes the outer diameter in
millimeters of the stator lamination.
CS generators are equipped with internal regulators.
The Y connection (A-type) or Delta (B-type) stator, a
rectifier bridge, and a rotor with slip rings and brushes
are electrically similar to earlier generators. A conven-
tional pulley and fan are used. There is no test hole.
Unlike three-wire generators, the ∅114D (A-type) or
CS114D (B-type) may be used with only two connec-
tions: battery positive and an ‘‘L’’ terminal to the charge
indicator lamp.
As with other charging systems, the charge indicator
lamp lights when the ignition switch is turned to ON, and
goes out when the engine is running. If the charge indi-
cator is on with the engine running, a charging system
defect is indicated.
The regulator voltage setting varies with temperature
and limits the system voltage by controlling the rotorfield current. The regulator switches rotor field current
on and off. By varying the on-off time, correct average
field current for proper system voltage control is ob-
tained. At high speeds, the on-time may be 10 percent
and the off-time 90 percent. At low speeds, with high
electrical loads, on-time may be 90 percent and the off-
time 10 percent.
CHARGING SYSTEM
The Delco-Remy CS charging system has several mod-
els available, including the ∅114D (A-type) or CS114D
(B-type). The number denotes the outer diameter in
millimeters of the stator laminations.
CS generators use a new type of regulator that incorpo-
rates a diode trio. The Y connection (A-type) or Delta (B-
type) stator, a rectifier bridge, and a rotor with slip rings
and brushes are electrically similar to earlier generators.
A conventional pulley and fan are used. There is no test
hole.
STARTER
Wound field starter motors have pole pieces, arranged
around the armature, which are energized by wound
field coils.
Enclosed shift lever cranking motors have the shift lever
mechanism and the solenoid plunger enclosed in the
drive housing, protecting them from exposure to dirt, icy
conditions, and splashes.
In the basic circuit, solenoid windings are energized
when the switch is closed. The resulting plunger and
shift lever movement causes the pinion to engage the
engine flywheel ring gear. The solenoid main contacts
close. Cranking then takes place.
When the engine starts, pinion overrun protects the ar-
mature from excessive speed until the switch is opened,
at which time the return spring causes the pinion to dis-
engage. To prevent excessive overrun, the switch
should be released immediately after the engine starts.
STARTING SYSTEM
The engine electrical system includes the battery, the
ignition, the starter, the generator, and all the related wir-
ing. Diagnostic tables will aid in troubleshooting system
faults. When a fault is traced to a particular component,
refer to that component section of the service manual.
The starting system circuit consists of the battery, the
starter motor, the ignition switch, and all the related elec-
trical wiring. All of these components are connected
electrically
.
DISTRIBUTOR
Distributor distributes the high tension voltage induced
from ignition coil, to each spark plug of each cylinder in

ENGINE ELECTRICAL 1E–5
DAEWOO M-150 BL2
the sequence of ignition order. It also adjusts the ignition
timing according to the engine condition.
This vehicle uses the distributor (optical sensor type)
which controls the preminary current of the ignition coil
by the ECM.
The ignition timing change is controlled electronically by
the ECM.
When diagnosing the ignition system, refer to Section
1F, Engine Controls.
IGNITION COIL
Ignition coil is a sort of transformer to generate high volt-
age (15,000–25,000V) which can bring spark at the
spark plugs and has an iron cored closed magnetic type.The closed magnetic typed ignition coil is used for the
High Energy Ignition (H.E.I) system. Comparing with the
iron cored open magnetic type, the closed type almost
has no loss of magnetic flux, and smaller in size, so it
produces the high voltage of secondary voltage.
SPARK PLUG
It is a part of ignition secondary current, and it burns the
compressed mixture by sparking the high voltage in-
duced from the ignition coil.

1E–6 ENGINE ELECTRICAL
DAEWOO M-150 BL2
COMPONENT LOCATOR
STARTING SYSTEM
D102E401
1 Starter Motor Assembly
2 Starter Solenoid Assembly
3 Starter Housing
4 Shift Lever
5 Armature Set
6 Armature7 Pinion Gear Assembly
8 Ring Set
9 Field Frame Assembly
10 Brush Holder Assembly
11 Contact End Frame Assembly
12 Starter Through - Bolts

ENGINE ELECTRICAL 1E–7
DAEWOO M-150 BL2
CHARGING SYSTEM (A-TYPE : MANDO)
D102E402
1 Generator Assembly
2 Generator Shackle
3 Generator Drive End Nut
4 Generator Pully
5 Generator Collar (Large)
6 Generator Front Bracket
7 Front Bearing
8 Bearing Spot Plate
9 Generator Collar (Small)10 Generator Rotor Assembly
11 Rear Bearing
12 Generator Stator Assembly
13 Rectifier Assembly
14 Voltage Regulator / Brush Holder Assembly
15 Generator Rear Bracket
16 Battery Positive Terminal Nut
17 Through Bolt

1E–8 ENGINE ELECTRICAL
DAEWOO M-150 BL2
CHARGING SYSTEM (B-TYPE : DAC)
D102E403
1 Generator Assembly
2 Generator Shackle
3 Generator Drive End Nut
4 Generator Pully
5 Generator Collar
6 Generator Drive End Bracket
7 Generator Stator Assembly
8 Frame Bearing
9 Generator Fan
10 Generator Rotor Assembly11 Frame Bearing
12 Generator Frame
13 Regulator Assembly
14 Brush Holder Assembly
15 Rectifier Assembly
16 Shield
17 Through - Bolt
18 Generator Cover
19 Battery Positive Terminal Nut
