2003 DAEWOO MATIZ Service Repair Manual

INSTRUMENTATION/DRIVER INFORMATION 9E–3
DAEWOO M-150 BL2
COMPONENT LOCATOR
INSTRUMENT PANEL ASSEMBLY
(Left–Hand Drive Shown, Right–Hand Drive Similar)
D19B401A
1. Tie–Bar
2. Tie–Bar Center
3. Instrument Panel Guide
4. Defroster Grille
5. Instrument Panel Upper Cap
6. Passenger’s Airbag Blank Cover
7. Demister Grille
8. Side Ventilation Grille
9. Glove Box Bracket
10. Glove Box11. Instrument Cluster Housing Molding
12. Center Ventilation Grille
13. Switch Blank Cover (Fog Lamp Switch)
14. Hazard Warning Switch
15. Immobilizer LED Indicator Switch
16. Ashtray Bracket
17. Ashtray
18. Ashtray Lamp
19. Cigar Lighter Housing
20. Instrument Cluster Bracket
21. Instrument Panel

9E–4 INSTRUMENTATION/DRIVER INFORMATION
DAEWOO M-150 BL2
INSTRUMENT CLUSTER
D109B404
1. Instrument Cluster Lens
2. Instrument Cluster Window Plate
3. Speedometer Gauge
4. Fuel Gauge5. Temperature Gauge
6. Instrument Cluster Case
7. Fronted Circuit Plate
8. Instrument Cluster Bulb

INSTRUMENTATION/DRIVER INFORMATION 9E–5
DAEWOO M-150 BL2
DIAGNOSTIC INFORMATION AND PROCEDURES
D19B301B
CIGAR LIGHTER
Condition Probable Cause Correction
Cigar Lighter Inoperative

The open or a short in the power supply
circuit to the fuse F7.

Repair or Replace the wiring
harness.

Fuse F7 is blown.
Replace the fuse F7.





The circuit between the fuse F7 and the
terminal 2 of the cigar lighter connector is
the open circuit or a short circuit.


Repair or Replace the wiring
harness.




Faulty the cigar lighter connector.

Repair or Replace the cigar
lighter connector.

Cigar lighter element is blown.
Replace the cigar lighter.





Open ground (G201) circuit.


Repair the open ground
circuit.

9E–6 INSTRUMENTATION/DRIVER INFORMATION
DAEWOO M-150 BL2
D19B302B
HVAC PANEL ILLUMINATION
Condition Probable Cause Correction
HVAC Panel Illumination
Inoperative
The open or a short in the power supply
circuit to the fuse Ef12.
Repair or Replace the wiring
harness.

Fuse Ef12 is blown.
Replace the fuse Ef12






The circuit between the fuse Ef12 and the
terminal 2 of the HVAC panel illumination
connector is the open circuit or a short
circuit.



Repair or Replace the wiring
harness.







Faulty the HVAC panel illumination
connector.



Repair or Replace the
instrument panel illumination
connector.

HVAC panel illumination bulb is blown.
Replace the bulb.

Open ground (G201) circuit.
Repair the open ground
circuit.

INSTRUMENTATION/DRIVER INFORMATION 9E–7
DAEWOO M-150 BL2
D19B304B
DIGITAL CLOCK
Condition Probable Cause Correction


Digital Clock Inoperative


The open or a short in the power supply
circuit to the fuse Ef2 regardless of the
ignition position.


Repair or Replace the power
supply circuit wiring harness.





The open or a short in the power supply
circuit to the fuse F1 with the ignition
position I.


Repair or Replace the power
supply circuit wiring harness.







The open or a short in the power supply
circuit to the fuse Ef12 with the interior
courtesy lamp ON.




Repair or Replace the power
supply circuit wiring harness.





The circuit between the fuse Ef2 and the
fuse F12 is open or short.


Repair or Replace the wiring
harness.

Fuse Ef2, Ef12, F1 or F12 is blown.
Replace and fuse.

The circuit between the fuse F12 and the
digital clock connector.
Repair or Replace the wiring
harness.




The circuit between the fuse F1 and the
digital clock connector.

Repair or Replace the wiring
harness.





The circuit between the Ef12 and the
digital clock connector.


Repair or Replace the wiring
harness.

Faulty digital clock.
Replace the digital clock.

Open ground (G201) circuit.
Repair the open ground
circuit.

9E–8 INSTRUMENTATION/DRIVER INFORMATION
DAEWOO M-150 BL2
REPAIR INSTRUCTIONS
ON–VEHICLE SERVICE
D109B501
CIGAR LIGHTER
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the ashtray from the ashtray housing.
3. Remove the cigar lighter from the cigar lighter socket.
D19B502A
4. Remove the cigar lighter socket from the cigar lighter
housing.
Caution: Ashtray housing edge could cause seri-
ous injury.

Push out the socket.

Disconnect the electrical connector (1).

Remove the socket (2).
D109B503
Installation Procedure
1. Connect the electrical connector.
2. Install the cigar lighter socket.
3. Install the cigar lighter in the cigar lighter socket.
4. Install the ashtray.
5. Connect the negative battery cable.

INSTRUMENTATION/DRIVER INFORMATION 9E–9
DAEWOO M-150 BL2
D109B504
ASHTRAY
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the ashtray from the ashtray bracket.

Pull off the ashtray by pressing the upper button.
D19B505A
2. Remove the ashtray bracket from the instrument pan-
el.

Remove the screws (1).

Remove the ashtray bracket (3).
D109B506
Installation Procedure
1. Install the ashtray bracket with the screws.
2. Install the ashtray.
D109B507
INSTRUMENT CLUSTER TRIM PANEL
VENTS
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the instrument cluster trim panel from the in-
strument panel. Refer to “Instrument Cluster Trim
Panel” in this section.
2. Remove the vent from the instrument cluster trim
panel.

Remove the screws (1).

Remove the vents (2).

9E–10 INSTRUMENTATION/DRIVER INFORMATION
DAEWOO M-150 BL2
D109B508
Installation Procedure
1. Install the vents to the instrument cluster trim panel
with the screws.
2. Install the instrument cluster trim panel. Refer to “In-
strument Cluster Trim Panel” in this section.
D109B511
DIGITAL CLOCK
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Disconnect the negative battery cable.
2. Pry off the defroster grille.
3. Unlock the locking of the digital clock.
a. Digital clock.
D109B512
4. Remove the digital clock from the instrument panel.

Disconnect the electrical connector (1).

Remove the digital clock (2).
D109B513
Installation Procedure
1. Connect the electrical connector.
2. Install the digital clock to the instrument panel.
3. Connect the negative battery cable.
4. Set the clock.
