REMOTE KEYLESS ENTRY AND ANTI-THEFT SYSTEM 9T – 1
DAEWOO M-150 BL2
SECTION 9T
REMOTE KEYLESS ENTRY AND
ANTI-THEFT SYSTEM
CAUTION: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless
otherwise noted.
TABLE OF CONTENTS
Description and Operation 9T-2. . . . . . . . . . . . . . . . . .
Remote Keyless Entry and
Anti-Theft System 9T-2. . . . . . . . . . . . . . . . . . . . . . .
Remote Locking and Unlocking 9T-2. . . . . . . . . . . . . .
Security Indicator 9T-2. . . . . . . . . . . . . . . . . . . . . . . . . .
Intrusion Sensing 9T-2. . . . . . . . . . . . . . . . . . . . . . . . . .
Siren 9T-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle Locator 9T-2. . . . . . . . . . . . . . . . . . . . . . . . . . .
Autolocking (Safety Lock) 9T-3. . . . . . . . . . . . . . . . . .
Control Module/Receiver 9T-3. . . . . . . . . . . . . . . . . . . Repair Instructions 9T-4. . . . . . . . . . . . . . . . . . . . . . . . .
On-Vehicle Service 9T-4. . . . . . . . . . . . . . . . . . . . . . . . . .
Siren 9T-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Password Programming 9T-5. . . . . . . . . . . . . . . . . . . .
Specifications 9T-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 9T-6. . . . . . . . . . .
Schematic and Routing Diagrams 9T-7. . . . . . . . . . .
Remote Keyless Entry and
Anti-Theft System 9T-7. . . . . . . . . . . . . . . . . . . . . . .

9T–2 REMOTE KEYLESS ENTRY AND ANTI-THEFT SYSTEM
DAEWOO M-150 BL2
DESCRIPTION AND OPERATION
REMOTE KEYLESS ENTRY AND
ANTI-THEFT SYSTEM
The remote keyless entry and anti-theft system can per-
form the following functions:

Remotely lock and unlock the vehicle doors with a
hand-held high-frequency transmitter.

Sense intrusion into the vehicle through the doors,
the tailgate, or the hood.

Activate a warning to signal an intrusion.

Help the driver find the vehicle in a parking area.

Automatically re-lock the doors if a door or the trunk is
not opened within 30 seconds after the vehicle has
been unlocked by the remote keyless entry.

Communicate serial data to a scan tool to help diag-
nose system faults.
The remote keyless entry and anti-theft system consists
of the following components:

Keyless entry and anti-theft control module/receiver.

Security indicator.

Tailgate open switch.

Door open switches.

Central locking unit.

Flashing turn signal lamps.

Siren.

Hood open switch.
REMOTE LOCKING AND UNLOCKING
The hand-held transmitter locks and unlocks the vehicle
doors by sending radio waves to the control module/re-
ceiver in the vehicle. The effective range of the transmit-
ter varies between 5 and 10 meters (approximately 16 to
32 feet), depending on whether or not objects such as
other vehicles are blocking the path of the radio waves.
The transmitter has a LOCK button and an UNLOCK
button which only function when the ignition is OFF.
Pressing the UNLOCK button has the following effects:

The doors are unlocked.

The turn signal lamps flash twice.

The control module is disarmed.
Pressing the LOCK button has the following effects:

The doors are locked.

The turn signal lamps flash once.

The control module is armed.
The transmitter has a replaceable battery. The battery is
designed to last at least two years before replacement is
necessary.
SECURITY INDICATOR
There is a security indicator on the instrument panel. Af-
ter the LOCK button of the transmitter is pressed, the
module is placed in the armed mode, and the security
indicator flashes. The security indicator turns ON for 1/8
second and OFF for 7/8 second. It then flashes at that
frequency until the control module/receiver is disarmed.
INTRUSION SENSING
The anti-theft function is armed if the transmitter sends
the LOCK message to the control module/receiver when
the ignition is OFF.
When the hood, the door, or the tailgate is opened, the
hood open switch, the door open switch, or the tailgate
open switch will change its input to ground. The alarm
will be activated if the hood open sensor, the door open
sensor, or the tailgate open sensor changes its input to
ground before either of the following conditions occurs:

An UNLOCK message is received from the transmit-
ter.
SIREN
The remote keyless entry system is armed when the
LOCK message is received from the transmitter when
the ignition is OFF. When the system is armed, it will ac-
tivate the siren and flash the turn signals for 28 seconds
if any of the following conditions occurs:

A door is opened (front door open switch input is
changed to ground).

The tailgate is opened (tailgate open switch input is
changed to ground).

The hood is opened while the anti-theft system is
armed (hood open switch input is changed to
ground).
The siren is disarmed when any of the following condi-
tions occurs:

The ignition switch is turned ON with the key.

The UNLOCK button or the LOCK button on the re-
mote transmitter is pressed.
VEHICLE LOCATOR
The remote keyless entry system assists the driver in lo-
cating the vehicle. When the vehicle is unlocked with the
remote control, the turn signals flash twice to indicate
the location of the vehicle. The duration of the flashes
and the length of time between flashes is used to indi-
cate certain vehicle conditions. Refer to “Fault or Alarm
Indication” in this section.

REMOTE KEYLESS ENTRY AND ANTI-THEFT SYSTEM 9T–3
DAEWOO M-150 BL2
AUTOLOCKING (SAFETY LOCK)
The remote keyless entry system features an autolock-
ing control. If the doors are unlocked with the remote
transmitter when the control module/receiver is in the
armed mode, the doors are automatically re-locked after
30 seconds unless any of the following events occur:

The door is opened.

The ignition switch is turned ON.

The tailgate is opened.

The hood is opened.
CONTROL MODULE/RECEIVER
The remote keyless entry control module/receiver is
contained in the tie-bar center. The module/receiver pro-
cesses signals from the remote transmitter and the in-
trusion sensors, and it activates the alarm if an intrusion
is detected.
The control module/receiver will not communicate with
transmitters from other vehicles because there are over
four billion possible electronic password combinations,
and passwords are not duplicated. The control module/
receiver has an attached antenna to detect signals from
the transmitter.

9T–4 REMOTE KEYLESS ENTRY AND ANTI-THEFT SYSTEM
DAEWOO M-150 BL2
REPAIR INSTRUCTIONS
ON-VEHICLE SERVICE
D19C501A
SIREN
Removal Procedure
1. Disconnect the negative battery cable.
2. Raise and suitably support the vehicle.
3. Remove the front wheels.
4. Remove the front wheel house splash shield.

Remove the clip and bolts.
a. Bolts and clips.

Remove the wheel house splash shield.
b. Splash shield.

D209B106
5 Remove the siren.

Remove the screws (1).

Disconnect the electrical connector (2).
D209B107
Installation Procedure
1. Install the siren with the screws.
2. Connect the electrical connector.
3. Install the front wheel house splash shield with the
clips and the bolts.
4. Install the front wheels.
5. Lower the vehicle.
6. Connect the negative battery cable.

REMOTE KEYLESS ENTRY AND ANTI-THEFT SYSTEM 9T–5
DAEWOO M-150 BL2
PASSWORD PROGRAMMING
If a transmitter is lost or damaged, the control module/
receiver must be re-programmed to communicate with a
new transmitter. The passwords recorded in the control
module/receiver should not be deleted when power is off
in the control module/receiver.
Each control module/receiver should be able to record
five passwords. The following method is used to record
new passwords in the control module/receiver:
1. Connect the scan tool to the data link connector
(DLC) connector.
2. Send the programming mode message to the control
module/receiver.
3. Press any button of the transmitter to generate a data
code including a password which will be recorded by
the control module/receiver. The control module/re-
ceiver sends a response message to the scan tool to
indicate that the first password has been recorded.
4. Press any button of the transmitter three more times
until the control module/receiver has responded that
the third, fourth, and fifth passwords have been re-
corded.
5. Disconnect the scan tool.
The control module/receiver leaves the programming
mode automatically and switches to the normal operat-
ing mode when either of the following conditions occurs:

The scan tool is disconnected from the DLC.

Five passwords are recorded in the control module/
receiver.

9T–6 REMOTE KEYLESS ENTRY AND ANTI-THEFT SYSTEM
DAEWOO M-150 BL2
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNmLb-FtLb-In
Hood Open Switch Mounting Screw8–71
Siren Bracket Mounting Bolt2216–
Siren Mounting Screws8–71
