2003 DAEWOO MATIZ Service Repair Manual

MANUAL STEERING GEAR 6D–5
DAEWOO M-150 BL2
STRAIGHT-AHEAD CHECK
After all the necessary operations on the steering gear
are completed, check the exact straight-ahead position
of the steering in each case.
With the vehicle on the floor, place the steering wheel in
the straight-ahead position. Mark the centerline of both
tires on the floor. Turn the steering wheel all the way to
the right and mark the new centerline of both tires on the
floor.
Application Tire Specified Valve
145, 15537.5 – 41.5
Inside Angle 17532.9 – 36.9
145, 15531.5 – 35.5
Outside Angle 17528.5 – 32.5
D105B301
Front Outside Angle
Inside Angle
Straight Ahead Check Table
Step Action Value(s) Yes No



1



Place the steering wheel in the straight-ahead posi-
tion.
Is the wheel in the correct position?


–


Go to Step 2



–


2

Is the steering wheel off center by more than 5 de-
grees?
–
Go to Step 4
Go to Step 5

3

The pinion is displaced on the rack. The steering
pinion position must be corrected.
Is the repair complete?
–
Go to Step 2

–



4



Remove steering wheel and center on the spindle
splines.
Is the repair complete?


–


Go to Step 2



–



5



Turn the steering wheel all the way to the right. Mea-
sure the inner and the outer angles of the tire cent-
erline compared to the straight-ahead centerline. Do
the angles match the value specified?


Refer to
“Straight–
Ahead Check”
in this section

System OK


Go to Step 6


6



The rack assembly was not assembled correctly.
Repair as needed.
Is the repair complete?


–


Go to Step 5



–

6D –6 MANUAL STEERING GEAR
DAEWOO M-150 BL2
STEERING WHEEL RESTORATION
1. Turn the steering wheel fast to the right and left and
turn it slowly as the same way.
2. Check if the steering wheel restoration for the wheel
turning to right and the one to the left are same.
3. Turn the steering wheel to 90 about 1–2 seconds
and loosen the steering wheel during the low speed
driving.
4. If the steering wheel restores above 70%, the steer-
ing wheel restoration is OK.
5. If the restoration is poor, check the tire pressure,
steering gear preload, and steering gear operation.
And repair the fault.
CHECK THE TURNING RESISTANCE
OF THE TIE ROD END OR TIE ROD
1. Turn the ball joint of the tie rod end or the tie rod about
10 times.
2. Use a spring balance to check the turning resistance
of each ball joint.
D105B302
Application Specified Value
Tie Rod End Ball Joint0.49 – 3.43 Nm
(4.5 – 30 lb-in.)

Tie Rod Ball Joint0.49 – 3.43 Nm
(4.5 – 30 lb-in.)
3. If the values exceed the specified values, replace the
tie rod end or the tie rod.
4. But, If the ball joint of the tie rod end or the tie rod falls
down of itself, replace it.
ADJUST THE FREE LOAD OF THE
STEERING GEAR
1. Place the steering wheel in the straight–ahead posi-
tion.
2. Raise and suitably support the vehicle.
3. Check the torque of the adjuster plug.
4 When the measured torque is below the specification
value or the measured torque is over the specification
value, adjust the tightening torque.

Place the rack gear in the straight–ahead position.

Tighten the adjust plug to 95 Nm (70 lb-ft).

Turn the steering wheel all the way to the right and
the left about 5 times repeatedly.

Place the rack gear in the straight–ahead position.

Loosen the adjust plug.

Tighten the adjust plug to 8 Nm (71 lb-in.).

Set the torque in the 0.8–1.3 Nm (8–12 lb-in.) by
loosening the adjust plug to 0 − 90.
D105B303

MANUAL STEERING GEAR 6D–7
DAEWOO M-150 BL2
REPAIR INSTRUCTIONS
ON–VEHICLE SERVICE
D105B501
TIE ROD END
Tools Required
KM–507–B Ball Joint Remover
Removal Procedure
1. Remove the wheel. Refer to Section 2E, Tires and
wheels.
2. Disconnect the tie rod and from the steering knuckle.

Remove the cotter pin (1).

Remove the castellated nut (2).

Use a ball joint remover KM–507–B, separate the
tie rod end (3).
D105B502
3. Remove the tie rod end.

Mark the tie rod, tie rod end lock nut and tie rod end
(1).

Loosen the tie rod end lock nut anticlockwise (2).

Loosen the tie rod end (3).
D105B503

6D –8 MANUAL STEERING GEAR
DAEWOO M-150 BL2
D15B504B
Installation Procedure
1. Install the tie rod end.
2. Install the tie rod lock nut (1).
Tighten
Tighten the tie rod end lock nut to 35–55 Nm (25–41
lb-ft).
3. Connect the tie rod end to the knuckle.
4. Install the tie rod end castellated nut (2).
Tighten
Tighten the castellated nut to 30–55 Nm (21–41 lb-
ft).
5. Install the split pin.
6. Install the wheel. Refer to Section 2E, Tires and
Wheels.
7. Make the toe–in adjustment by turning the tie rod ad-
juster. Refer to Section 2B, Wheel Alignment.
D105B505
RACK AND PINON BOOT
Removal Procedure
1. Remove the tie rod end. Refer to “Tie Rod End” in this
section.
2. Remove the tie rod end lock nut.
D105B506
3. Remove the rack and pinion boot.

Remove the boot clamp (1).

Cut off the boot wire clamp (2).

MANUAL STEERING GEAR 6D–9
DAEWOO M-150 BL2
D105B507

Coat the greases on the tie rod to ease removal
(3).

Remove the boot (4).
D105B508
Installation Procedure
1. Install the rack and pinion boot with the clamp and the
wire clamp.
2. Install the tie rod end nut.
3. Install the tie rod end. Refer to “Tie Rod End” in this
section.
D105B509
D105B510
RACK AND PINION STEERING GEAR
ASSEMBLY
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the intermediate shaft lower pinch bolt. Re-
fer to Section 6E, Steering Wheel and Column.
2. Remove the wheels. Refer to Section 2E, Tires and
Wheels.
3. Disconnect the tie rod end from the steering knuckle.
Refer to “Tie Rod End” in this section.
4. Remove the front exhaust pipe nuts. Refer to Section
1G, Engine Exhaust.
5. Remove the steering gear assembly from the vehicle.

Remove the steering gear bracket bolts (1).

Remove the steering gear bracket (2).

Remove the steering gear assembly.

Remove the packing (3).

6D –10 MANUAL STEERING GEAR
DAEWOO M-150 BL2
D15B511A
Installation Procedure
1. Install the mounting to the steering gear assembly.
2. Install the steering gear assembly.
3. Install the steering gear bracket with the bolts.
Tighten
Tighten the steering gear bracket bolts to 50–55 Nm
(36–41 lb-ft).
4. Install the front exhaust pipe nuts. Refer to Section
1G, Engine Exhaust.
5. Connect the tie rod end to the steering knuckle. Refer
to “Tie Rod End” in this section.
6. Install the wheels. Refer to Section 2E, Tires and
Wheels.
7. Install the intermediate shaft lower pinch bolt. Refer
to Section 6E, Steering Wheel and Column.

MANUAL STEERING GEAR 6D–11
DAEWOO M-150 BL2
UNIT REPAIR
D105B701
TIE ROD END BOOT
Disassembly Procedure
1. Remove the tie rod end. Refer to “Tie Rod End” in this
section.
2. Remove the tie rod end boot.
a. Tie rod end boot.
D105B702
Assembly procedure
Important : Coat the grease inside of the boot.
1. Install the boot to the tie rod end.
2. Install the tie rod end wire clamp.
3. Install the tie rod end. Refer to “Tie Rod End” in this
section.
D105B703
RACK AND PINION
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Disassembly Procedure
1. Remove the rack and pinion steering assembly from
the vehicle. Refer to “Rock and Pinion Assembly” in
this section.
2. Remove the rack and pinion boot.

Remove the tie rod end. Refer to “Tie Rod End” in
this section (1).

Remove the tie rod lock nut (2).

Remove the rack and pinion boot clamp (3).

Cut off the rack and pinion boot wire (4).

6D –12 MANUAL STEERING GEAR
DAEWOO M-150 BL2
D105B704

Coat the greases on the tie rod (5).

Remove the rack and pinion boot (6).
D105B705
3. Remove the tie rod

Pull the rack gear perfectly from the steering gear
housing by turning the pinion gear (1).

Disconnect the shock damper ring from the tie rod
ball joint (2).
D15B706A

Vise the rack gear (3).
Important: Clothe the rack gear with a cloth before vis-
ing the rack gear.
Notice: Do not vise the rack gear over two teeth face.
D105B707

Remove the tie rod (4).

Remove the shock damper ring (5).
