2003 DAEWOO MATIZ Service Repair Manual

GENERAL ENGINE INFORMATION 1A–7
DAEWOO M-150 BL2
GENERAL DIAGNOSIS (Cont’d)
 Condition Probable cause Correction
Rough Engine IdlingMalfunction of
Ignition System
Loosening or damage of the
distributor rotor or cap.
Replace the rotor or cap.

Poor ignition timing.
Adjust the ignition timing.

Malfunction of the ignition
coil.
Replace the ignition coil.
Others
Clogged or contaminated air
cleaner element.
Clean or replace the air
cleaner element.

Leak of the intake manifold
gasket.
Replace the gasket.

Malfunction of Positive
Crankcase Ventilation (PCV)
valve.
Check the valve or replace it
if needed.

Poor connection or damage
or leakage of the vacuum
hose.
Connect the hose correctly
or replace it.
Engine Hesitate (Upon
pressing accelerating
pedal, the engineDecline of
Compression
Pressure
Refer to “Page 1A–5”.
Refer to “Page 1A–5”.
makes delayed
response. ThisMalfunction of
Poor ignition timing.
Adjust the ignition timing.response. This
situation is remarkable
when cruising orIgnition System
Poor spark plug or poor
adjustment of the plug gap.
Replace the plug or adjust
the gap.
starting.)
Electric leakage or poor
connection of the high
tension cable.
Connect the cable correctly
or replace it.
Others
Malfunction of the air cleaner
system.
Clean or replace the air
cleaner system.

Leak of the intake manifold
gasket.
Replace the gasket.
Engine Surging
(Engine power makes
fluctuation in a fixedDecline of
Compression
Pressure
Refer to “Page 1A–5”.
Refer to “Page 1A–5”.
speed and speed
changes withoutMalfunction of
Clogged fuel pipe.
Clean the pipe.changes without
operating the
accelerating pedal.)Fuel System
Clogged or contaminated
fuel filter.
Replace the filter.

Malfunction of the fuel
pressure regulator.
Replace the fuel pressure
regulator.
Malfunction of
Ignition System
Malfunction of the spark
plug.
Adjust or replace the spark
plug.

Electric leakage or poor
connection of the high
tension cable.
Connect the cable correctly
or replace it.

Worn distributor cap terminal
or accumulated carbon in
the distributor cap.
Clean or replace the
distributor cap.

Loosening or damage of the
distributor rotor or the cap.
Replace the distributor rotor
or the cap.

Poor ignition timing.
Adjust the ignition timing.

1A–8 GENERAL ENGINE INFORMATION
DAEWOO M-150 BL2
GENERAL DIAGNOSIS (Cont’d)

 Condition

 Probable cause

 Correction
Engine Surging
(Engine power makes
fluctuation in a fixedOthers
Leak of the intake manifold
gasket.
Clean or replace the gasket.
speed and speed
changes without
operating the
accelerating pedal.)
Leakage of the vacuum hose.
Connect the hose correctly
or replace it.
Excessive Detonation
(According to theOverheated
Engine
Refer to “Overheat” in this
page.
Refer to “Overheat” in this
page.
opening range of
throttle valve,Malfunction of
Abnormal spark plug.
Replace the spark plug.
knocking sound of
metallic is made withIgnition System
Poor ignition timing.
Adjust the ignition timing.metallic is made with
abnormal explosion.)

Electric leakage or poor
connection of the high tension
cable.
Connect the cable correctly
or replace it.
Malfunction of
Fuel System
Clogged or contaminated fuel
filter and fuel pipe.
Clean or replace the fuel
filter and the fuel pipe.
Others
Leak of the intake manifold
gasket.
Replace the gasket.

Excessive carbon deposit due
to abnormal combustion.
Remove the carbon.
OverheatMalfunction of
Lack of coolant.
Refill coolant.
Cooling System
Malfunction of the thermostat.
Replace the thermostat.

Malfunction of the cooling fan.
Check or replace the cooling
fan.

Poor water pump
performance.
Replace the pump.

Clogged or leaky radiator.
Clean, repair or replace the
radiator.
Malfunction of
Lubrication
Poor engine oil.
Replace engine oil with the
specified one.
System
Blocking oil filter or strainer.
Clean or replace the oil filter
or the strainer.

Lack of engine oil.
Refill oil.

Poor oil pump performance.
Replace or repair the pump.

Leakage of oil.
Repair.
Other
Damaged cylinder head
gasket.
Replace the gasket.
Poor Fuel
ConsumptionDecline of
Compression
Pressure
Refer to “Page 1A–5”.
Refer to “Page 1A–5”.
Malfunction of
Fuel System
Leakage of the fuel tank or
the fuel pipe.
Repair or replace the fuel
tank or the fuel pipe.

GENERAL ENGINE INFORMATION 1A–9
DAEWOO M-150 BL2
GENERAL DIAGNOSIS (Cont’d)
 Condition Probable cause Correction
Poor FuelMalfunction of
Improper ignition timing.
Adjust the ignition timing.
ConsumptionIgnition System
Abnormal spark plug
(Excessive carbon deposit,
inadequate gap, burnt
electrode).
Replace the plug.

Electric leakage or poor
connection of the high
tension cable.
Connect the cable normally
or replace it.
Malfunction of
Cooling System
Malfunction of the
thermostat.
Replace the thermostat.
Others
Improperly installed valve.
Repair or replace the valve.

Slipping clutch.
Repair or replace the clutch.

Low pressure of tires.
Adjust the pressure of tires.
ExcessiveLeakage of
Loosened oil drain plug.
Tighten the plug.
Consumption of
Engine OilEngine Oil
Loosened oil pan bolt.
Tighten the bolt.Engine Oil

Loosened oil filter.
Tighten the filter.

Loosened oil pressure
switch.
Tighten the switch.

Leakage of camshaft front oil
seal.
Replace the seal.

Leakage of crankshaft front
oil seal.
Replace the seal.

Leakage at the cylinder head
cover gasket.
Replace the gasket.

Damage of the cylinder head
gasket.
Replace the gasket.
Oil Mixing in
Combustion
Stuck piston ring.
Remove carbon and replace
the ring.
Chamber
Worn piston or cylinder.
Replace the piston or the
cylinder.

Worn piston ring or ring
groove.
Replace the piston or ring.

Inadequate position of the
piston ring cutting part.
Adjust the position.

Abrasion or damage of the
valve system.
Replace the valve system.
Low Oil PressureMalfunction of
Lubrication
Inadequate oil viscosity.
Replace with the specified
one.
System
Loosening of the oil pressure
switch.
Tighten the switch.

Lack of engine oil.
Refill oil.

Blocking oil strainer.
Clean the strainer.

1A–10 GENERAL ENGINE INFORMATION
DAEWOO M-150 BL2
GENERAL DIAGNOSIS (Cont’d)
 Condition Probable cause Correction
Low Oil PressureMalfunction of
Lubrication
Lowered function of the oil
pump.
Replace the pump.
System
Abrasion or damage of the
oil pump relief valve.
Replace the valve.
Engine NoiseValve Noise
Inadequate valve clearance.
Adjust the valve clearance.

Abrasion of valve stem or
guide.
Replace the valve stem or
the guide.

Weak valve spring.
Replace the spring.
Piston, Ring,
Cylinder Noise
Abrasion of the piston, the
ring or the cylinder.
Boring the cylinder or
replace the piston, the ring
or the cylinder.
Connecting Rod
Noise
Abrasion of the connecting
rod bearing.
Replace the bearing.

Loosened the connecting rod
nut.
Tighten to the specified
torque.
Crankshaft
Noise
Abrasion of the crankshaft
bearing.
Replace the bearing.

Abrasion of the crankshaft
journal.
Grind or replace the
crankshaft journal.

Loosened bearing cap bolt.
Tighten to the specified
torque.

Excessive clearance of the
crankshaft thrust bearing.
Adjust or replace.

Low oil pressure.
Refer to “Low Oil Pressure”
in this section.

GENERAL ENGINE INFORMATION 1A–11
DAEWOO M-150 BL2
CHECKING ENGINE FLUID LEVEL
Check the engine fluid level or condition. If needed, refill
or replace the oil.
Check the engine oil level within engine normal operat-
ing temperature as follows ;
1. After stopping the engine, wait for a few minutes to
accumulate oil into the oil pan.
2. After pulling out the oil level gauge (a), check the oil
level.
3. Clean the oil level gauge and insert the gauge into
guide.
4. After pulling out the oil level gauge again, recheck the
oil level and insert the gauge into guide again.
Important: Oil level should be between “MIN” mark and
“MAX” mark.
5. If oil level is below the “MIN” mark, refill engine oil as
much as the demanded quantify.
Important: If checking oil level under the engine cold
condition, oil is not accumulated into oil pan quickly and
correct level checking can not be performed. Therefore,
wait until temperature reaches the normal operating
condition and check the engine oil level.
D102A301
CHANGING ENGINE OIL OR OIL
FILTER
Tools Required
09915–47341 Oil Filter Wrench.
When checking engine oil level or condition, if needed,
change engine oil (including the filter) as follows ;
1. After stopping the engine, wait for a few minutes to
accumulate oil into the oil pan.
2. Remove the oil filter cap (b).3. Remove the oil drain plug (c) and draw oil off.
D102A302
4. After drawing oil completely, tighten the oil drain plug
to 30–40 Nm (22–30 lb-ft).
5. Replace the oil filter using the oil filter wrench
09915–47341 (d).

Remove the air cleaner/resonator/snorkel as-
sembly.

After removing the bolts, remove the heat
shield.

Loosen the power steering pump cap screw and
pull the power steering hose into the front.

Remove the oil filter.
Important: Whenever changing engine oil, replace the
oil filter. When replacing new oil filter, apply engine oil on
oil filter sealing.
D102A303

1A–12 GENERAL ENGINE INFORMATION
DAEWOO M-150 BL2
CHECKING ENGINE TIMING BELT
After checking the timing belt for looseness, crack, wear
or tension, replace the belt if necessary.
CHECKING ACCESSORY BELT
After checking the alternator belt (e), air conditioning/
power steering belt (f), air conditioning belt (g), power
steering belt (h), for looseness, crack, wear or tension,
replace the belt if necessary.
D102A304
CHECKING SPARK PLUG
After checking the spark plug for bad clearance, exces-
sive carbon deposit, worn electrode or damaged insula-
tor, replace the new one if necessary.
Remove and check the spark plug as follows ;
1. Pull the high tension cable cap portion (i), and discon-
nect the high tension cable from the spark plug.
If pulling the high tension cable (j), circuit could be
disconnected. Therefore, the cap portion should be
used.
D102A305
2. Remove the spark plugs from cylinder head using a
wrench.
3. Measure the spark plug clearance (k) with the filler
gauge. If measured value is not within the specified
value, adjust the grounding electrode.
When installing new spark plug, check the clearance
for equality and install it.
D102A306

GENERAL ENGINE INFORMATION 1A–13
DAEWOO M-150 BL2
CHECKING AIR CLEANER ELEMENT
If the air cleaner element becomes dirty, engine efficien-
cy could be deteriorated.
Be sure to check the element often.
Especially, if a vehicle frequently runs on a dusty road,
check and replace the element often.
CHECKING FUEL FILTER
If fuel filter is used over the specified period, engine effi-
ciency is deteriorated by dust or foreign material.
Therefore, replace a new one within the specified peri-
od.
CHECKING FUEL SYSTEM
Check the fuel system as follows ;

Check the fuel line or line connection portion for dam-
age or leakage.

Check the fuel hose surface for damage.

Check the fuel cap for looseness.
CHECKING HOSE SYSTEM
Check the engine vacuum hose, PCV hose or canister
hose as follows ;

Check the hose surface for damage by heat or ma-
chine.

Check the hose for hardening, crack, tear, or coming
off.

1A–14 GENERAL ENGINE INFORMATION
DAEWOO M-150 BL2
SPECIFICATIONS
GENERAL SPECIFICATIONS
 Application Description
  Maximum Speed 144 km/h (90 mph)
 Vehicle Capacity Gradeability 0.420 tan θ

Vehicle Capacity
 Minimum Turning Radius 4.5 m (14.8 ft)
  Bore × Stroke 68.5 × 72.0 mm (2.70 × 2.83 inch)
  Displacement 796 cm3 (48.6 in3)
  Compression Ratio 9.3 : 1
  Maximum Power 37.5 KW (6,000 rpm)

Engine Information
 Maximum Torque 68.6 Nm (50.59 lb-ft) (at 4,600 rpm)
Ignition Timing (Ignition Sequence)5 BTDC (1–3–2) / 10 BTDC (1–3–2)
Air Conditioning System (ON)

1,000 ± 50 rpm  Idle Speed Air Conditioning System (OFF) 950 rpm  Engine Overhead Cam L–3


 Ignition Type

 Direct Ignition System (DIS) /
High Energy Ignition (HEI)
  Distributor Optical Sensor Type
  Starter SD 80
   Unleaded BPR5EY–11, RN9YC4, WR8DCX
  Spark–Plug Leaded BPR5EY, RN9YC, WR8DC
  Fuel Injection Type MPI
  Fuel Pump Electric Motor Pump
Engine Part TypeFuel FilterCartridge Engine Part Type
Lubricating Type

Forced Feed Type  Oil Pump Rotary Pump Type  Cooling Type Forced Water Circulation  Radiator Cross – Flow  Water Pump Centrifugal  Thermostat Pellet Type
  Air Cleaner Element Non Woven Fablic
  Muffler Catalytic Converter, Closed Circuit
  Battery MF
Engine PartEngine OilSJ Grade
SAE 5W30, SAE 10W30, SAE 15W40
CapacityRefrigerantFour Seasons
Engine Disassembly

3.0 L (3.17 qt)   Oil Change (Including filter) 2.7 L (2.85 qt)  Engine Oil Oil Change (Not including filter) 2.5 L (2.64 qt)   Oil Level Gauge 1 L (1.06 qt) (MIN to MAX)  Coolant 3.8 L (4.02 qt) Engine Information Battery 12V–35 AH, 246 CCA
 Engine Information

Generator

65 A
  Starter 0.8 kW
   Output Capacity 90 – 133 Lph
  Fuel Pump Output Pressure 380 kPa (55.1 Psi)
  Fuel Tank Capacity 35 L (9.2 gal), 38 L (10 gal)
