JEEP CHEROKEE 1995 Service Repair Manual Fig. 2 Engine Compartment Connections YJ 8W - 90 - 4 8W-90 CONNECTOR LOCATIONSÐYJ VEHICLESJ

Page 2170 of 2198

JEEP CHEROKEE 1995 Service Repair Manual Fig. 3 Engine Connections 2.5L YJ J8W-90 CONNECTOR LOCATIONSÐYJ VEHICLES 8W - 90 - 5

Page 2171 of 2198

JEEP CHEROKEE 1995 Service Repair Manual Fig. 4 Engine Connections 4.0L YJ 8W - 90 - 6 8W-90 CONNECTOR LOCATIONSÐYJ VEHICLESJ

Page 2172 of 2198

JEEP CHEROKEE 1995 Service Repair Manual Fig. 5 Transmission Connections YJ J8W-90 CONNECTOR LOCATIONSÐYJ VEHICLES 8W - 90 - 7

Page 2173 of 2198

JEEP CHEROKEE 1995 Service Repair Manual Fig. 6 Instrument Panel Connections YJ 8W - 90 - 8 8W-90 CONNECTOR LOCATIONSÐYJ VEHICLESJ

Page 2174 of 2198

JEEP CHEROKEE 1995 Service Repair Manual Fig. 7 Instrument Panel Connections YJ J8W-90 CONNECTOR LOCATIONSÐYJ VEHICLES 8W - 90 - 9

Page 2175 of 2198

JEEP CHEROKEE 1995 Service Repair Manual Fig. 8 Body Connections YJ 8W - 90 - 10 8W-90 CONNECTOR LOCATIONSÐYJ VEHICLESJ

Page 2176 of 2198

JEEP CHEROKEE 1995 Service Repair Manual Fig. 9 Frame Connections YJ J8W-90 CONNECTOR LOCATIONSÐYJ VEHICLES 8W - 90 - 11
