FORD MONDEO 1993  Service Repair Manual 5If you are renewing the battery, make sure
that you get one that’s identical, with the
same dimensions, amperage rating, cold
cranking rating, etc. Dispose of the old battery
in a responsible fashi

Page 114 of 279

FORD MONDEO 1993  Service Repair Manual 3Using an ohmmeter, measure the
resistance of the coil’s primary windings,
connecting the meter between the coil’s
terminal pins as follows. Measure first from
one outer pin to the centre pin, the

Page 115 of 279

FORD MONDEO 1993  Service Repair Manual 5Undo the sensor’s retaining screw and
withdraw the sensor. The sensor’s bracket
cannot be unbolted from the cylinder
block/crankcase unless the transmission and
flywheel/driveplate have been remo

Page 116 of 279

FORD MONDEO 1993  Service Repair Manual at the top, two at the bottom). Withdraw the
alternator from the engine, and manoeuvre it
out through the wheel arch (see illustration).
Do not drop it, it is fragile.
7If you are renewing the alterna

Page 117 of 279

FORD MONDEO 1993  Service Repair Manual starter motor must be overhauled or renewed.
(Other possibilities are that the starter motor
mounting bolts are very loose, or that teeth
are missing from the flywheel/driveplate ring
gear.)
4If, when

Page 118 of 279

FORD MONDEO 1993  Service Repair Manual Brush renewal
2Remove the brushes as shown (see
illustrations).
3In some cases, the brushes will have wear
limit marks, in the form of a groove etched
along one face of each brush; when the
brushes ar

Page 119 of 279

FORD MONDEO 1993  Service Repair Manual Chapter 9 Braking system
ABS hydraulic unit - removal and refitting  . . . . . . . . . . . . . . . . . . . . 20
ABS relay box - removal and refitting  . . . . . . . . . . . . . . . . . . . . . . . . 2

Page 120 of 279

FORD MONDEO 1993  Service Repair Manual Torque wrench settingsNm lbf ft
Front caliper bracket  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120 89
Rear caliper bracket  . . . . . . . . . . . . . . . . . .
