REAR AXLE - Differential Carrier27-37
(6) Install the drive pinion assembly and companion flange
with mating marks properly aligned, and tighten the
companion flange self-locking nut to the specified
torque by using the special tools.
(7) Measure the drive pinion turning torque (with oil seal) to verify that the drive pinion turning torque complies with
the standard value.
Standard value:
BearingBearingclassification lubrication Rotation torque
(starting friction torque)Nm (in.lbs.1
;;oy:;; (;5,,,,,, 1 ~%L; !
If there is a deviation from the standard value, check
whether or not there is incorrect tightening torque of
the companion flange tightening self-locking nut, or incorrect fitting of the oil seal.
. ADJUSTMENT OF DIFFERENTIAL GEAR BACKLASH Adjust the differential gear backlash by the followingprocedures:
(1) Assemble the side gears, side gear spacers, pinion gears, and pinion washers into the differential case.
(2) Temporarily install the pinion shaft.
NOTE
Do not drive in the lock pin yet.
(3) Adjust the differential gear backlash by the following procedures:
@ While locking the side gear with the wedge,
measure the differential gear backlash with a dial
indicator on the pinion gear.
NOTE
The measurement should be made for both pinion
gears individually.
Standard value:O-0.076 mm (O-.003 in.)
Limit:0.2 mm (.008 in.1

27-38REAR AXLE - Differential Carrier
@ If the differential gear backlash exceeds the limit,
adjust the backlash by installing thicker side gear
spacers. @ Measure the differential gear backlash once again,
and confirm that it is within the limit.
NOTE
(1) After adjustment, check that the backlash is the
less than the limit and differential gear rotates
smoothly.
(2) When adjustment is impossible, replace the side
gear and the pinion gear as a set.
Spring pin
‘\ /
Drive gear TNyh fl
l~1/p(---\y-jj !5Lz+ /
17. INSTALLATION OF DRIVE GEAR/18. SPRING PIN
(1) Before installing the drive gear, drive the spring pin into the differential case.
At this time, face the notch in the spring pin in the
direction shown in the figure and have it stick out from
the differential case by the dimension shown in the
figure.
I I II II\ \\ II
llAO262llA026
1 / / MB990890-01
Chamfering
(large) llA0316
llA0101
(2)Use the special tool to press fit the drive gear until it hits
the end of the differential case.
At this time, the large chamfering of the inner cir-
cumference of the drive gear should be to the inside
(side touching the differential case).
(3)
ii,“;k that the drive gear and end of the spring pin are
24. INSTALLATION OF LOCK PIN
(1) Align the pinion shaft lock pin hole with the differential case lock pin hole, and drive in the lock pin.
(2) Stake the lock pin with a punch at two points.
25. INSTALLATION OF DRIVE GEAR
(1) Clean the drive gear attaching bolts.
(2) Use an
Ml0 X 1.25 tap to remove the adhesive
adhering to the threaded holes of the drive gear, and
then clean the threaded holes by applying compressed
air.
(3) Install the drive gear onto the differential case with the mating marks properly aligned. Tighten the bolts to the
specified torque in a diagonal sequence.
TSB Revision

REAR AXLE - Differential Carrier27-39
26. PRESS-FITTING OF SIDE BEARING INNER RACE
Press-fit the side bearing inner races to the differential case
by using the special tool.
=Thickness of the
spacer on one side
llY241
l ADJUSTMENT OF FINAL DRIVE GEAR BACKLASH
Adjust the final drive gear backlash by the followingprocedures:
(1) Install the side bearing spacers, which are thinner than those removed, to the side bearing outer races, and
then mount the differential case assembly into the gear
carrier.
NOTE
Select side bearing spacers with the same thickness for
both the drive pinion side and the drive gear side.
(2) Push the differential case to one side, and measure the clearance between the gear carrier and the side
bearing.
(3) Measure the thickness of the side bearing spacers on one side, select two pairs of spacers which correspond
to that thickness plus one half of the clearance plus0.05 mm I.002
in.), and then install one pair each to the
drive pinion side and the drive gear side.
(4) Install the side bearing spacers and differential case
, assembly, as shown in the illustration, to the gear
carrier.
TSB RevisionI

31-I
WHEEL
AND TIRE
CONTENTSMJlAA-
SERVICE ADJUSTMENT PROCEDURES . . . . . . .4
TROUBLESHOOTING. . . . . . . . . . . . . . ..*.....................3
Tire Inflation Pressure Check. . . . . . . . . . . . . . . . . . . . . .4 Bald Spots
TireWearCheck. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .4
Cracked Treads
Wheel Runout Check . . . . . . . . . . . . .._....................4
Feathered Edge
SPECIFICATIONS2 Rapid Wear at Center
.............................................
General Specifications
2Rapid Wear at Shoulders
..................................
Service Specifications
2Scalloped Wear
...................................
Torque Specifications
2Wear on One Side
...................................
WHEELANDTIRE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .5

31-2WHEEL AND TIRE - Specifications
SPECIFICATIONS
GENERAL SPECIFICATIONS
Items
Wheel Tire size
Wheel type
Wheel size
Amount of wheel offset
Tire inflation pressure Front
Rear ;pare
wheel
Tire size mm (in.)
kPa (psi)
Wheel size
Amount of wheel offset
Tire inflation pressure mm (in.)
kPa (psi)
NOTE*: brakingsystem>
SERVICE SPECIFICATIONS
SOHC PI
85/7OR 14 87s
Steel type or
Aluminium type
14
x 5% JJ
46 (1.8)
200 (29)
180 (26)
l-l 25/70D15
ITx 15
$6 (1.8)
120 (60)
TSB Revision
I
DOHC-FWD
195/65Fil4 89H or 195/60R15
86H
< 1993models>
195/60R15
86H
Steel type or
Aluminium type
14
x 5’/2 JJ or15~6JJ
46 (1.8)
210 (30)
180 (26)
rl25/70D15Tl25/70016*
4Tx 154Tx 16*
46 (1.8)
420 (60)
DOHC-AWD 195/65R14

89H or 195/60R15
86H or 195/60R15
87V
Steel type or
Aluminium type ; g
x ;‘$JJJ
orX
46 (1.8)
220 (32)
200 (29) T135/70D16
!Tx 16
$6 (1.8)
420 (60)
M3lcA--
Items1 Specifications
Limit Wheel runout
Radial
Lateral
Tread depth of tire
mm (in.)
1.2 j.047)
mm (in.)1.2 (.047)
mm (in.) 1.6 (.06)

1 .o (.039)
1 .o (.039)
TORQUE SPECIFICATIONS
Items
Wheel nutsNm
90-I 10
ft.lbs.
65-80

WHEEL AND TIRE - Troubleshooting31-3
TROUBLESHOOTING
M31EA-
Symptom Remedy
Probable cause
Under-inflation or
lack of rotation Adjust the tire pressure
Rapid wear
at shoulders
Rapid wear
at center Over-inflation or
lack of rotation
Cracked
treads Under-inflation
Excessive camber nspect
the camber
Near on )ne
side
idjust the toe-inIeathered?dge ncorrect
oe-in laid
spots
Jnbalancedvheel Adjust the imbalanced
wheels calloped
ack of rotation of tyres or worn or
ut-of-alignment suspension Rotate the tires Inspect the front sus-
pension alignment fear
TSB Revision

31-4WHEEL AND TIRE - Service Adjustment Procedures
SERVICE ADJUSTMENT PROCEDURES
TIRE INFLATION PRESSURE CHECKM3lFOAC
Check the inflation pressure of the tires. If it is not within the
standard value, make the necessary adjustment.
W
ear indicator
53YJlO
TIRE WEAR CHECKM31FBAB
Measure the tread depth of tires.
Limit: 1.6 mm
(.06 in.)
If the remaining tread depth is less than the limit, replace the
tire.
NOTE
When the tread depth of tires is reduced to 1.6 mm LO6 in.) or
less, wear indicators will appear.
WHEEL RUNOUT CHECKWlFcAB
Jack up the vehicle so that the wheels are clear of the floor.
While slowly turning the wheel, measure wheel runout
with a
dial indicator.
Limit: Radial
1.2 mm (.047 in.)
1 .O mm (.039 in.)
Lateral
1.2 mm (.047 in.)
1 .O mm (.039 in.)
If wheel runout
exceeds the limit, replace the wheel.
TSB RevisionI

WHEEL AND TIRE - Wheel and Tire
WHEEL AND TIREM31GA..
REMOVAL AND INSTALLATION
Steel wheel
, /-----%10lm65-80 ft.lbs.3
1

>
mode
1110396
Aluminium type wheel
<14 inch- SOHC><14 inch-DOHC>

2
0
Removal steps
1. Wheel cover
/ - llAO279/llA0395
twit7~- . .
(15 inch>
<15 inch>Q wheel cover>
2. Center cover
center cover>
3. Wheel nuts
4. Center cap center cap>
5. Spring
6. Ornament
7. Balance weight
8. Tire9. Wheel 9
dLit
3
11
A0408
1 TSB RevisionI
