AUTOMATIC TRANSAXLE - Transaxle Control23-95

4-6‘Nm3-4 ftlbs.
Pre-removal and Post-installation Operation*Removal and Installation of Console Box Assembly(Refer to GROUP 52-Floor Console.)@Removal and Installation of Instrument Under Cover Assem-
s;bly, Column Cover, Lap Shower Duct and Foot Shower
(Refer to GROUP 5’2-Instrument
Panel.)
9-14 Nm7-10 ftlbs.
4-6 Nm
3-4 ftlbs.
09A0138
Key-interlock cable removal steps
1. Snap pinl +2. Key-interlock cable (selector lever
assembly side)
3. Clamp
4. Cover
I)* 5. Key-interlock cable (steering lock assembly side)
I)+ 6. Slide lever
NOTEBefore connecting the key-interlock cable or the shift-lock
cable, be sure to first connect and adjust the transaxle Shift-lock
cable removal steps
3. Clam
I)+ 7
.
Shift- ock cable
P(selector lever assembly side)
8. Coffer pin
9. Shift-lock cable (brake pdeal side)
control cable.
TSB Revision

23-96AUTOMATIC TRANSAXLE - Transaxle ControlI<1989
models>
/ switch 16A046318A077E
09*0029
09A0039

Neutral
oosition
INSPECTIONM23lcAK
l Check the control cable for function and for damage.
lCheck the bushing for wear or damage.
POWER (PWR)/ECONOMY (ECO) SWITCH
(1) Remove the POWER (PWRVECONOMY
(ECO) switch from
the console box.
(2) Check for continuity between terminals when the switch is OFF and when ON.
NOTEO-O indicates that there is continuity between the terminals.
OVERDRIVE CONTROL SWITCH
Check for continuity between terminals when the switch is OFF
and when ON.
ON (Overdrive activation) 0 0
OFF (Overdrive non-activation) 03
NOTEO-O indicates that there is continuity between the terminals.
SERVICE POINTS OF INSTALLATIONM231DAO
15. INSTALLATION OF TRANSAXLE CONTROL CABLE
Move the selector lever and the park/neutral position
switch to the “N” position, and install the transaxle control
cable.
I OSAO179
1
TSB Revision

AUTOMATIC TRANSAXLE - Transaxle Control23-97
mount
\09R0058
3tent pin A ~ r\,I, ./
/
lock cable
0910143
Key interlock cableO0A0125
,T’--
@ ;:-.-
09AO126
09A0142
14. INSTALLATION OF CLIP
When connecting the control cable to the transaxle mount
bracket, install the clip until it contacts the control cable, in
the position shown in the figure.
. ADJUSTMENT OF TRANSAXLE CONTROL CABLE
Refer to the section concerning adjustment of the park/
neutral position switch. (Refer to
P.23-84.)
7. INSTALLATION OF SHIFT LOCK CABLE (SELECTOR
LEVER ASSEMBLY SIDE)
(1) Move the selector lever to the “R” position.
(2) Clamp the shift lock cable.
(3) Connect the shift lock cable to the selector lever
assembly, and temporarily tighten the nut.
(4) Slide the shift lock cable so that the distance between the selector lever assembly’s detent pin and the end of
the shift lock cable is the standard value, and then
tighten the nut at the specified torque.
Standard value (A):
1-4 mm (.04-.15 in.)
(5) After connecting the shift lock cable, check the shift lock mechanism. (Refer to
P.23-84.)
6. INSTALLATION OF SLIDE LEVERI5. KEY INTERLOCK
CABLE (STEERING LOCK ASSEMBLY SIDE)
(1) With the ignition key either at the “LOCK” position orremoved, install the slide lever to the key cylinder.
(2) Connect, as shown in the figure, the key interlock cable to the slide lever and the key cylinder.
(3) Apply a light coating of multi-purpose grease where shown in the figure.
(4) Install the key interlock cable.
2.INSTALLATION OF KEY INTERLOCK CABLE (SELECTOR
LEVER ASSEMBLY SIDE)
(1) Move the selector lever to the “P” postion.
(2) Connect the key interlock cable to the selector lever assembly’s lock cam. Be sure that the spring installed
to the key interlock cable is as shown in the figure.
(3) While gently pressing the lock cam in the
F direction,
tighten the nut to secure the key interlock cable.
(4) After connecting the key interlock cable, check the key interlock mechanism. (Refer to
P.23-83.)
11 TSB RevisionI

23-98AUTOMATIC TRANSAXLE - Transaxle Control
DISASSEMBLY AND REASSEMBLY (SELECTOR LEVER ASSEMBLY)
2.0 Nm or more 1.4 ft.lbs. or more
2.0
Nm or more/ 1.4 ft.lbs. or more
k%-h.lbs.
Disassembly steps
*I)1. Overdrive control switch connector2.Cover3.Selector knoba*4. Overdrive control switch button4,5.Overdrive controlswitch6.Pin
7.Pushbutton8.Spring9.Indicator panel10.Slider
11. Indicator panel lower
12.l 413.Socket assemblySleeve14.Lever assembly15.Bushina
16. Pipe
”17. Cotter pin
18. Lock cam
19. Bracket assembly
-10
-11 09190135
TSB Revision

AUTOMATIC TRANSAXLE - Transaxle Control23-99
Screwdriver
I09A0043 (
SERVICE POINTS OF DISASSEMBLYmz3oFhC
1. REMOVAL OF OVERDRIVE CONTROL SWITCH CON-
NECTOR
Disconnect the overdrive control switch connector and
then remove the terminal from the overdrive control
switch connector.
4. REMOVAL OF OVERDRIVE CONTROL SWITCH
BUlTON/5. OVERDRIVE CONTROL SWITCH
(1) Using the flat-tip screwdriver, remove the overdrive control switch button.
(2)
FW&ng the switch, remove the overdrive control
INSPECTIONMuOOAD
l Check the detent plate for wear.
l Check the bushing for wear or damage.
l Check the spring for damage or deterioration.
SERVICE POINTS OF REASSEMBLYMz3oHhL
13. INSTALLATION OF SLEEVE
(1) Place the selector lever in the “N” position, and then turn the sleeve so that the clearance between the
sleeve and the lever assembly end is within the
standard value.
Standard value (A): 15.2-15.9
mm (.598-.825
in.)
(2) Apply a coating of multi-purpose grease to the surface of the sleeve.
TSB Revision

23-100AUTOMATIC TRANSAXLE - Transaxle Oil Cooler Hoses
TRANSAXLE OIL COOLER HOSES
REMOVAL AND INSTALLATION
3-5 Nm2-4 ft.lbs.4-6 Nm\3-4 ft.lbs.
3-4 ft.lbs.
4-6 Nm3-4 ft.lbs.09A0041
< 1993 models>
2Pre-removal and Post-installation
Operationl
Drainage and Filling of Automatic Trans-axle Fluid(Refer to GROUP 00 - MaintenanceService.)
Removal steps
1. Hose clamp
2. Cable clamp
3. Oil cooler hose assembly
Caution1.Take care not to spill the transaxle fluidwhen removing components.2. After removing the oil cooler hose as- sembly, plug so that foreign materials
cannot enter the transaxle.
2-4 ftlbs.
bs.I /-\nhu-l,no
INSPECTION
l Check the hose for crack, damage and clog.
l Check for rusted or clogged radiator oil cooler.
TSB Revision

AUTOMATIC TRANSAXLE - Transaxle Assembly
TRANSAXLE ASSEMBLY
REMOVAL AND INSTALLATION
23-101
mz3u-
Pre-removal and Post-installation Op-eration@Draining and Supplying of the TransaxleFluid(Refer to GROUP 00-Maintenance Ser-vice.)*Removal and Installation of the Batteryand Battery TrayofRemoval and Installation of the Air Clean-
fRrefer to GROUP 15-Air
Cleaner.)*Removal and Installation of the Air Com-pressor(Vehicles with ACTIVE-ECS)(Refer to GROUP 33B-Air Compressor.)
cl989 models>27-34 Nm20-25ft.lbs.I360-80Nm43-58ft.lbS.60-80Nm43-58ft.lbs.
43-55 Nm
IO-12 Nm7.2-8.7 ft.lbs.
27-34 Nm20-25 ft.lbs.
30-35 km
b22-25 ft.lbs.
Iii ’30-35 Nm
22-25 ft.lbs.
ternoval steps
1. Snap pin
3. Connection for transaxle control cable
(Refer to
P.23-84.)4. Solenoid connector5. Park/neutral position switch connector
6. Pulse generator connector
7. Kickdown
servo switch connector
8. Oil temperature sensor connector 9. Connection for sppedometer cable
10. Connection for oil cooler hose
11. Connection for starter motor
12. Upper coupling bolt for transaxle assembly and engine assembly
13. Transaxle mount bracket
TSB Revision

23-102AUTOMATIC TRANSAXLE - Transaxle Assemblv

27-34 Nm220-25 ftlbs.
\
43-55 Nm
60-80 Nm
60-80 Nm
/43-58 ftlbs.
43-58
ftlbs.
/\ /\ 930-35 NmDm 30-35 N

m
22-25
ftlbs.22-25 ft.lbs.
Iemoval steps
2. Adjusting nut
3. Connection for transaxle control cable (Refer to
P.23-85.)4. Solenoid connector
5. Park/neutral position switch connector
6. Pulse generator connector
7. Kickdown
servo switch connector
8. Oil temperature sensor connector
9. Connection for speedometer cable
10. Connection for oil cooler hose
11. Connection for starter motor
12. Upper coupling bolt for transaxle assembly and engine assembly
13. Transaxle mount bracket
TSB Revision
