36-2PARKING BRAKES - Specifications/Troubleshooting/Service Adjustment Procedures
SPECIFICATIONS
GENERAL SPECIFICATIONS
ItemsSpecifications
TypeMechanical brake acting on rear wheels
Parking brake lever typeLever type
Cable arrangementV-type
SERVICE SPECIFICATION
Items
Standard value
Parking brake lever stroke Specifications5-7 notches
TROUBLESHOOTING
Symptom
Probable cause Remedy
Poor parking brake
function +Worn brake pad Poor condition of brake pad surface Replace
Parking brake cable sticking
Auto-adjuster malfunction Adjust
Excessive parking brake lever stroke
Adjust the parking brake lever
stroke or check the parking
brake cable arrangement
I
i
!14A023C
SERVICE ADJUSTMENT PROCEDURES
PARKING BRAKE LEVER STROKE CHECKM~~FEAJ
1.Pull the parking brake lever with a force of approx. 200 N
(45 Ibs.), and count the number of notches.
Caution
The 200 N (45 Ibs.) force of the parking brake lever must
be strictly observed.
Standard value: 5-7 notches
2.If the parking brake lever stroke is not the standard value,
adjust as described below.
(1) Remove the carpet in the floor console.
(2) Loosen the adjusting nut to the end of the cable rod,
thus freeing the parking brake cable.
(3) With the engine idling, firmly depress the brake pedal
five or six times and confirm that the pedal stroke stops
changing.
NOTE
If the pedal stroke stops changing, it indicates that the
automatic adjusting mechanism has functioned proper- ly to adjust the clearance
b&ween’the pads and the
disc to the correct value.
TSB Revision
PARKING BRAKES - Service Adiustment Procedures36-3
(4) Check to be sure that the clearance between the
stopper and the parking brake lever at the caliper side is
as shown in the figure.
NOTE
If the clearance between the parking brake lever and
the stopper exceeds 2 mm
(078 in.), the probable
causes are brake cable sticking, improper wiring, or a
malfunction of the automatic adjuster (within the rear
brake caliper), so it is necessary to check the parking
brake cable and to disassemble and check the rear
brake caliper.
(5) Turn the adjusting nut to adjust the parking brake lever stroke to within the standard value range.
Caution
If the number of brake lever notches engaged is less
than the standard value, the cable has been pulled excessively, and failure of the automatic adjuster
mechanism will result. Be sure to adjust it to within
the standard value.
(6) After making the adjustment, check to be sure that there is no play between the adjusting nut and the pin.
Also check to be sure that the adjusting nut is securely held at the nut holder.
(7) After adjusting the lever stroke, jack up the rear of the
vehicle.
(8) With the parking brake lever in the released position,
turn the rear wheel to confirm that the rear brakes are
not dragging.
PARKING BRAKE SWITCH CHECK M3SFDAB
(1) Disconnect the connector of the parking brake switch, and connect an ohmmeter to the parking brake switch and the
switch installation bolt.
(2) The parking brake switch is good if there is continuity when the parking brake lever is pulled and there is no continuity
when it is returned.
TSB Revision
I
PARKING BRAKES - Parking Brake Cable
PARKING BRAKE CABLE
REMOVAL AND INSTALLATION
~$y$y$Y&
M36xA-
(Refer to GROUP 52-Floor Console.)
*Removal of Rear Seat Cushion (Refer to GROUP 52-Rear
Seat.)
l Parking Brake Lever Stroke Adjustment
l installation of Rear Seat Cushion
3y_on,“6,:;;0; ConsoleA rl-~IIll(77 I i /
:/AWD-UP TO 1992 MODELS>
Parking brake cable removal steps
1. Adjusting nut
2. Clamn
-3.Gromrmet+44. Cableend5.Snap ring6.
Parking clip
7.Retainer spring++ 8. Parking brake cable
14A0544
14AO529 TSB
Revision
1
36-6PARKING BRAKES - Parking Brake Cable
Identification mark
14A0441
SERVICE POINTS OF INSTALLATIONWXDAE
8. INSTALLATION OF PARKING BRAKE CABLE Check the parking brake cables for an identification mark
and install as appropriate on the left and right sides.
Item Identifica-
tion mark Left
Yellow
Green None
Red*
Blue*
1 Right 1 Orange BrownIWhiteI I
Yellow green* I
Green*
NOTE*: Vehicles with automatic seat belt
4. INSTALLATION OF CABLE END
(1) Connect the cable end to the brake shoe assembly.
(2) Install the brake shoe assembly.
(3) Turn the brake shoe adjuster to adjust the outside diameter of brake shoe to the specified value.
NOTE
Adjusting the outside diameter of brake shoe to thespecified value will facilitate adjustment of the shoe
clearance. .‘,,
I.**i:,1;q ,.’
TSB Revision
