33A-16FRONT SUSPENSION - Stabilizer Bar
SERVICE POINTS OF INSTALLATION
M33TDAK
13. INSTALLATlON OF STABILIZER BAR BRACKET
(1) Temporarily tighten the stabilizer bar bracket.
(2) Align the bushing end with the marked part of the
stabilizer bar, and then fully tighten the stabilizer bar
bracket.
10. INSTALLATION OF STABILIZER LINK MOUNTING
NUT
Using a wrench or similar tool to secure the ball studs at
both ends of the stabilizer link, tighten the mounting nuts.
6. INSTALLATION OF STABILIZER BAR MOUNTING NUT
Tighten the nut on the stabilizer bar bolt to the specified distance.
Protruding length of stabilizer bar mounting bolt Standard value: 16-18 mm (.63-.70
in.)
TSB Revision

FRONT SUSPENSION - Stabilizer Bar
STABILIZER BAR

REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation@Removal of Front Exhaust Pipe(Refer to GROUP 15-Exhaust Pipe and Main
\:M/T> 55-60 Nm40-43 ftlbs.
:A/T>
60-80 Nm44-57 ft.lbs. *
Iemoval steps
::3.4.
::
i:9.
Left member
Gusset
Transfer
Stabilizer link mounting nut
(Refer to P.33A-14, 16.)
Stabilizer link
Stabilizer bar bracket installation
Stabilizer bar bracket (Refer to
PBushing
Stabilizer bar 80-100

Nm58-72 ftlbs.
35-45
25-33
bolt
.33A-16.)
70-80 Nm51-58 ftlbs. MBJTA-B
-42
Nmiik.30 ft.lbs
TSB Revision

33A-18FRONT SUSPENSION - Stabilizer Bar
SERVICE POINTS OF REMOVAL
9. REMOVAL OF STABILIZER BAR (1) Disconnect the coupling of the knuckle and lower armat the right side.
(2) Pull out the left side stabilizer bar edge, pulling it out between the drive shaft and lower arm.
(3) Pull out the right side stabilizer bar edge, pulling it out from below the lower arm.
INSPECTION
Refer to P.33A-15.
hl33lcAI
BALL JOINT DUST COVER REPLACEMENTM~E
Refer to P.33A-15.
TSB Revision

339-l
