1989 MITSUBISHI GALANT Service Repair Manual

COOLING - Water Hose and Water Pipe ,I 4-25
7-lOft.lbs.
04AO123
11. Connection for heater hose12. Water by-pass hose13.Waterhose14. Connection for thermostat case15. Water inlet pipe16.O-ring
TSB Revision
INSPECTIONM07cAAal
WATER PIPE AND HOSE INSPECTION
Check the water pipe and hose for cracks, damage, clog and
replace them if necessary.

14-26COOLING - Water Hose and Water Pipe
WATER HOSE AND WATER PIPE
REMOVAL AND INSTALLATION
MlUA-B
IF‘re-removal and Post-installationOperation eDraIning
and Supplying of the En- glne
Coolant
(Refer to GROUP
00-Maintenance Service.)
12-15 Nm
9-11 ftlbs.
12-15 ‘Nm9-11 ft.lbs.
25-30 Nm’ 7
18-22
ft.lbs.68
A
40 50 Nm’&\29136 ft.lbs.4Ib.
q 2,h
40-50 Nm
9-11 ft.lbs.
30-40 Nm22 - 29 ft.lbs.
30-40 Nm\22-29 ft.lbs. \ OSAOOSS
Removal steps
1. Condenser fan motor assembly(FWD,
AWD-M/T)

2 Self-locking nut
3. Gasket4. Connection for oxygen sensor
5. Exhaust manifold cover (A)
6. Self-locking nut
7. Engine hanger
8. Exhaust manifold
9. Exhaust manifold gasket
10. Exhaust manifold cover (B)
1 TSB Revision

COOLING - Water Hose and Water PiDe 14-27
-55 Nm
Removal steps
11. Connection for oxygen sensor andcontrol harness
12. Water hose
13. Water by-pass hose
14. Connection for heater hose
15. Connection for radiator lower hose (Referto P.14-10.)
16. Water inlet pipe (Refer to P.14-18.)17. O-ring (Refer toP.14-18.)
04A0050
TSB Revision

14-28COOLING - Water Hose and Water Pipe
WATER HOSE AND WATER PIPE
Pre-removal and Post-installation Operation 1eDraining and Filling of the Engine Coolant
(Refer to GROUP 00-Maintenance Service.)
*Draining and Filling of the Engine Oil
(Refer to GROUP 11 -Service Adjustment Pro-
cedures.)
REMOVAL AND INSTALLATION
12-15 Nm
9-l 1 ft.lbs.25-30 Nm18-24 ft.lbs.
M141A-C
‘1
Flare nut 55-65
N
m
/-A 40-47 ft.lbs.
12-15 Nk9-11
ftlbs.
30-40 Nm
22-29 ft.lbs:
,“k.
Removal steps
I. Radiator (Refer to P.14-9.)2. Connection for air intake hose
3. Connection for vacuum hose
4. Connection for air hose A
5. Air outlet fitting6. Gasket
7. Heat protector A
8. Heat protector
B9. Self-locking nut10. Engine hanger
\40-50 Nm
29-36 ftlbs.
05Aoo54\40-60 Nm
29-43 ft.lbs.
II. Eye bolt12. Gasket
13. Connection for water hose
I 4. Connection for water pipe B15. Self-locking nut16. Gasket -17. Exhaust manifold
18. Exhaust manifold gasket
19. Ring
20. Gasket
i TSB Revision

-Wntmr Hncn andWater Pine14-29
21. Connection for oxygensensor harness connector22. Oil return pipe23.Gasket+, I)+ 24. Turbocharger25.Eye bolt26.Gasket27. Water pipe B28. Eye bolt
29. Gasket
30. Water pipe A27
35-50 Nm
8-10 Nm
6-7 ftlbs.230
/ ’ ,! I,!, ” /40s-i1 ft.lbs.lo-12 Nm 30-40 N
m
22-3t
7-9 ft.lbs.22-29 ft.lbs.
04c.0116
! Nm1 ftlbs.
31. Water hose (To turbocharger)32. Water hose33. Water by-pass hose
34. Connection for heater hose
35. Water hose
36. Water hose
37. Water hose
38. Exhaust pipe support bracket
39. Water pipe
40. Water inlet pipe (Refer to
P.14-18.)41. O-ring (Refer to P.14-18.)
TSB Revision1

14-30COOLING - Water Hose and Water Pipe
05AOO26
SERVICE POINTS OF REMOVALMWBAG
24. REMOVAL OF TURBOCHARGER ASSEMBLYRemove the turbocharger assembly with the exhaust
fitting, water pipe A, water pipe
B and the oil pipe attached
to it.
INSPECTION
WATER PIPE AND HOSE INSPECTION
Refer to
P.14-23.
Ml4lcAE
SERVICE POINTS OF INSTALLATIONMWDAR
24. INSTALLATION OF TURBOCHARGER ASSEMBLY Clean the alignment surfaces shown in the illustration.
Caution
When cleaning, care must be taken so that a piece of
the gasket does not enter the oil passage hole.
TSB Revision

COOLING -Engine Coolant Temperature Gauge Unit, Engine CoolantTemoerature Sensor and Engine Coolant Temperature Switch14-31
ENGINE COOLANT TEMPERATURE GAUGE UNIT, ENGINE COOLANT
TEMPERATURE SENSOR AND ENGINE COOLANT TEMPERATURE
SWITCHM14oE-
REMOVAL AND INSTALLATION
30-40
Nm/
gine Coolantlo-14 Nm(Refer to GROUP 00-Maintenance8-10 ft.lbs.Service.)
/ I r lcoolo
Sealant: 3M ATD Part No.8660or equivalent04A0118

< 1993 models>
10 12 Nrny~~~~~7-9 ft.lbs. 2
1. Engine coolant temperature gauge unit
2. Engine coolant temperature sensor
(Engine control)3. Air conditioning engine coolanttemperature switch type>4. Engine coolant temperature switch, . (Air condltloning
or A/T control)
Sealant: 3M Nut locking PartNo.4171 or equivalent
TSB Revision

14-32COOLING -Engine Coolant Temperature Gauge Unit, Engine Coolant
Temperature Sensor and Engine Coolant Temperature Switch
/
Sensor
J
046003
3
04GOO32
9FUO156
---
--I ‘Oi

l
QQQQQQ2cmn99
INSPECTIONM14OOAM
ENGINE COOLANT TEMPERATURE GAUGE UNIT
Raise the water temperature and measure the resistance if
within the standard value.
Standard value:
104k13.5 Q [at 70°C (158”F)]
ENGINE COOLANT TEMPERATURE SENSOR
(Engine control)
Raise the water temperature and measure the resistance if
within the standard value.
Standard value:
At
20°C (68°F)
At 80°C (176°F) 2.4520.24

klR
296232 R
<1993 models>
(1) Remove engine coolant temperature sensor from the in- take manifold.
(2) With temperature sensing portion of engine coolant tem- perature sensor immersed in hot water, check resistance
Temperature 1°C (OF)1Resistance (kR)
0 (32)5.8
20 (68)2.4
40
(I
04)1.1
80 (176)0.3
(3) If the resistance deviates from the standard value greatly,
replace the sensor.
AIR CONDITIONING ENGINE
COOLANT TEMPERATURE
SWITCH
(1) Immerse the air conditioning engine coolant temperature switch in oil and then heat (by using a gas stove flame or
similar method) so as to increase the oil temperature.
(2) Check to be sure that the air conditioning engine coolant temperature switch is switched OFF when the oil tempera-ture reaches the standard value.
Standard value:
112-l 18°C (234-244°F)
Caution
The oil used above should be engine oil and should be
stirred well while being heated; do not heat more than
necessary.
TSB Revision
