1989 MITSUBISHI GALANT Service Repair Manual

ENGINE - Engine Assembly 11-63
ENGINE ASSEMBLY
IEMOVAL AND INSTALLATION
Pre-removal Operationl Eliminating fuel pressure in fuel lines
(Refer to GROUP 13-On-Vehicle lnspectior
of MFI Components.)*Removal of the hood
(Refer to GROUP 42-Hood.)
eDraining of engine coolant(Refer to GROUP 00-Maintenance
Service.:@Removal of transaxle assembly
(Refer to GROUP 22, 23-Transaxle.)*Removal of radiator assembly
(Refer to GROUP 14-Radiator.)
MIISA-6
Post-installation Operationl installation of radiator assembly(Refer to GROUP 14-Radiator.)l Installation of transaxle assembly
Removal steps
1. Connection for accelerator cable or throttle cable (Refer to GROUP
13-Service Adjustment Procedures.)
2. Connection for throttle cable (Auto-cruise control)
3. Connection for fuel return hose
4. Connection
forbrake booster vacuum
hose
5. Connection for fuel pressure solenoid(Turbo)6. Connection for EGR solenoid (Turbo: California)
7. Connection for air hose A (Turbo) 8. Connection for air hose
D (Turbo)9. Connection for fuel high pressure hose10. O-ring11. Connection for heater hoses
TSB Revision

ENGINE - Engine Assembly
cl989 models>‘P15
4-6 Nm
3-4 ftlbs..
3-4 ftlbs.lo-12 Nm7-9 ft.lbs.
< 1990 models>
14
13
I15\/
Olb.0407
4-6 Nm3-
4
ftlbs. \
16
173*
4-6 Nmz

-
3-4 ftlbs.
iwz110-12 Nm7-9
ftlbs.
OlA0623
20
TSB Revision

ENGINE - Engine Assembly11-65
models>
4-6
Nm
25
18
05AO196
I
23\il4-6 Nm3-4 ftlbs.
12. Connection for engine coolanttemperature switch
13. Connection for oxygen sensor
14. Connection for engine coolant
temperature sensor
15. Connection for engine coolant
temperature gauge unit
16. Connection for air conditioning engine
coolant temperature switch
17. Connection for
IAC motor
18. Connection for closed throttle position switch 19. Connection for fuel injectors
20. Connection for EGR temperature sensor
(California vehicles only)
21. Connection for knock sensor (Turbo)
22. Connection for ignition coil
23. Connection for ignition power transistor
24. Connection for throttle position sensor
25. Connection for crankshaft position sensor
26. Connection for ground cable
27. Control wiring harness
TSB Revision
1

11-66ENGINE - Engine Assembly
28
29
30
35-45 Nm25-33 ftlbs.
50-65 Nm36-47 ft.lbs.
I
3132
40-50

Nm29-36 ftlbs.
43-56
ft.lbs.
-- .__.. 36-47
ft.lbs.* 54’q
28. z;tFhction for power steering pressure
29. Connection for generator
30. Generator wiring harness clamps
31. Connection for oil pressure switch 4W 1)432.
Connection for power steering oil pump
++ ++33. Connection for air conditioning
compressor
34. Self-locking nut
35. Gasket
36. Bracket
4*37. Engine mount bracket
38. Self locking nut
+e l + 39. Engine assembly
22- 29 ftlbs.c-rurbo>40-60 Nm29- 43 ftlbs.
OlAO405
NOTEFor tightening locations indicated by the l , symbol, firsttighten temporarily, and then make the final tlghtenlng withthe entire weight of the engine applied to the vehicle body.
TSB Revision

ENGINE - Engine AssemblyII-67
SERVICE POINTS OF REMOVAL
MllSBDF
32. DISCONNECTION OF POWER STEERING OIL PUMP Disconnect the oil pump with hoses from the bracket.
NOTE
The removed power steering oil pump should be fastened(by using rope, etc.) in a position that will not interfere
with the removal/installation of the engine assembly.
33. DISCONNECTION OF AIR CONDITIONING COMPRESSOR
Disconnect air conditioning compressor connector and re-
move it with hoses from the compressor bracket.
NOTE
The removed air conditioning compressor should be fas-
tened (by using rope, etc.) in a position that will not inter-
fere with the removal/installation of the engine assembly. OlA0177
37. DISCONNECTION OF ENGINE MOUNT BRACKETBefore removing the engine mount bracket installation
bolt, use a chain block or similar arrangement to suspend
the engine assembly (to the extent that there is no
looseness of the chain).
39. REMOVAL OF ENGINE ASSEMBLY After checking that the cables, hoses, harness connec-
tors, etc. are all removed, slowly raise the chain block tolift the engine assembly upward out of the engine
compartment.
SERVICE POINTS OF INSTALLATION MllSDAY
39. INSTALLATION OF ENGINE ASSEMBLY When mounting the engine, check to be sure that thecables, hoses, harness connectors, etc. are all in the
correct position.
33. INSTALLATION OF AIR CONDITIONING
COMPRESSOR/32. POWER STEERING OIL PUMP
Adjust belt tension. (Refer to P.l l-61.)
TSB Revision

II-68ENGINE -Camshaft and Camshaft Oil Seals
CAMSHAFT AND CAMSHAFT OIL SEALS
REMOVAL AND INSTALLATIONMIIZA-0
*Il Servtce Adjustment Procedures
2.5-3.5 Nm2.5-3.5 Nm^ ^ *. I.-3 -3YIL-L--J I-LIDS.L-S TLIDS.
19-21 Nm14-15 ft.lbs.
4
I ^
19-21 NmAlo-13 Nm-.. -IL-14-15 ft.lbs.-Y I-LIDS. 80-100

Nm58-72 ft.lbs.
Removal steps
I Connection for accelerator cable or throttle cable (Refer to GROUP
13-Service Adjustment Procedures.)
2. Timing belt (Refer to P.l I-80.)3. Center cover
6. Connection for spark plug cables
7. Rocker cover
8. Semi-circular packing
9. Throttle body stay
++ 10. Crankshaft position sensor
4,11. Exhaust camshaft sprocket
4*12. Intake camshaft sprocket+e I)+ 13. Camshaft oil seals 41)
l + 14. Front camshaft bearing caps
+e l * 15. Camshaft bearing caps+e l + 16. Rear camshaft bearing cap (R.H+e l a 17. Rear camshaft bearing cap (L.H.l + 18. Exhaust camshafte+ 19. Intake camshaft
NOTE+1 : *2 :
Nmft.lbs.
head
7
10 mm
@
10 mm(.4 in.)10 mmc.4 In.)(.4 In )
OlAca
Sealant: 3M ATD Part No.8880or equivalent
TSB Revision

ENGINE - Camshaft and Camshaft Oil Seals
11-69
SERVICE POINTS OF REMOVAL
MllZBAD
11. REMOVAL OF EXHAUST CAMSHAFT SPROCKET/ 12. INTAKE CAMSHAFT SPROCKET
(1) Using a wrench at the hexagonal part of the camshaft (to prevent the crankshaft from turning), loosen the
cramshaft sprocket bolt.
(2) Remove the camshaft sprokets.
Plastic hammer
Intake side Exhaust side
q 48
Slits 13. REMOVAL OF CAMSHAFT OIL SEALS
Remove the oil seals using a screwdriver or similar tool.
Caution
Take care not to damage front camshaft bearing cap and camshaft.
14./15./16./17. REMOVAL OF CAMSHAFT BEARING CAPS
(1) Loosen the bearing cap installation bolts in two or three steps.
(2) Remove the bearing cap.
NOTE
If the bearing cap is difficult to remove, use a plastic
hammer to gently tap the rear part of the camshaft,
and then remove.
SERVICE POINTS OF INSTALLATION M, 1zDAF
19. INSTALLATION OF INTAKE
CAMSHAFT/18.
EXHAUST
CAMSHAFT
(1) Install the camshafts on the cylinder head.
Caution
Be sure not to mistake the intake side and
th!
exhaust side. There are slits for crankshaft posl-
tion sensor drive in the rear end of the intake cam-
shaft.

ENGINE - Camshaft and Camshaft Oil Seals
zI?mo”e the rocker arms.
Install new camshafts using the following procedure.
(2) Lay the camshafts on the cylinder head and install the bearing caps.
(3) Check that the camshaft can be easily turned by
hand.
(4) After checking, remove the bearing caps and the camshafts, and install the rocker arms.
3iF-Dowel Din
(2) The camshaft’s dowel pins should be at the positions
shown in the figure.
Intake.side
17./16./15./14. INSTALLATION OF CAMSHAFT BEARING
CAPS
Tighten the bearing cap installation bolts to the specified
torque in two or three steps.
Caution
Tighten uniformly, otherwise the rocker arms will not be straight.
ADDIY a coatioi ‘oil to the outer
circumferenceCahshaft
Mating markat plate side/
at hoising sidellA0361(3) Check that the ignition timing is set at the standard
value. (Refer to GROUP
16-Ignition system.)
TSB Revision 13. INSTALLATION OF CAMSHAFT OIL SEALS
Using the special tool, press in the oil seal as shown in the
figure.
10. INSTALLATION OF THE CRANKSHAFT POSITIO
N
SENSOR
(1) Align the mating mark (punch mark) on the housing of
the crankshaft position sensor with the mating mark(notch) in the plate.
(2) Install the crankshaft position sensor to the engine.
Caution
When tightening the nut of the crankshaft posi-
tion sensor, make sure that the crankshaft posi-
tion sensor does not turn.
