Page 417 of 4331

NISSAN TIIDA 2009 Service Repair Manual AUDIO AV-33 < SERVICE INFORMATION > C D E F G H I J L M A B AV N O P OK or NG OK >> GO TO 2. NG >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector. 2.

Page 418 of 4331

NISSAN TIIDA 2009 Service Repair Manual AV-34< SERVICE INFORMATION > AUDIO 2. Check continuity between audio unit harness connector terminal and speaker harness connector terminal. 3. Check continuity between audio unit harness connector te

Page 419 of 4331

NISSAN TIIDA 2009 Service Repair Manual AV N O P Sound Is Not Heard from Su bwoofer (Premium System) INFOID:0000000004306978OK >> GO TO 2. NG >> If fuse is blown, be sure to eliminate cause of blown fuse before installing new fuse. Refer to

Page 420 of 4331

NISSAN TIIDA 2009 Service Repair Manual OK >> GO TO 6. NG >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector. OK >> GO TO 7. NG >> • Check connector housings for disconnected or loo

Page 421 of 4331

NISSAN TIIDA 2009 Service Repair Manual AV N O P OK or NG OK >> Replace subwoofer. Refer to AV-37, " Removal and Installation " . NG >> Replace audio unit. Refer to AV-37, " Removal and Installation " . Removal and Installation INFOID:0

Page 422 of 4331

NISSAN TIIDA 2009 Service Repair Manual . 2. Remove the tweeter screw (A), disconnect the connector and remove the tweeter (1). Installation Installation is in the reverse order of removal. SATELLITE RADIO TUNER Hatchback

Page 423 of 4331

NISSAN TIIDA 2009 Service Repair Manual AV N O P Sedan Removal 1. For hatchback, remove the luggage side lower finisher (LH) (hatchback only). Refer to EI-53 . 2. For sedan, remove the trunk side finisher (LH). Refer to EI-55, " Removal a

Page 424 of 4331

NISSAN TIIDA 2009 Service Repair Manual Removal and Installation " . 2. Remove the steering wheel finisher cover. 3. Remove the screws and the steering wheel audio control switches. Installation Installation is in the reverse order of remov
