NISSAN TIIDA 2009 Service Repair Manual YES >> GO TO 2. NO >> Repair the terminal and connector. YES >> GO TO 3. NO >> Repair the ECM branch line. How to Check Vehicle Type " . • MR TYPE 1: EC-628, " Diagnosis Procedure " • MR TYPE 2:

Page 3578 of 4331

NISSAN TIIDA 2009 Service Repair Manual LAN N O P BCM BRANCH LINE CIRCUIT Diagnosis Procedure INFOID:0000000004749306YES >> GO TO 2. NO >> Repair the terminal and connector. YES >> GO TO 3. NO >> Repair the BCM branch line. BCM Power Supply

Page 3579 of 4331

NISSAN TIIDA 2009 Service Repair Manual YES >> GO TO 2. NO >> Repair the terminal and connector. YES (Present error)>>Check CAN system type decision again. YES (Past error)>>Error was detected in the data link connector branch line circuit

Page 3580 of 4331

NISSAN TIIDA 2009 Service Repair Manual LAN N O P EPS BRANCH LINE CIRCUIT Diagnosis Procedure INFOID:0000000004749308YES >> GO TO 2. NO >> Repair the terminal and connector. YES >> GO TO 3. NO >> Repair the EPS control unit branch line. DTC

Page 3581 of 4331

NISSAN TIIDA 2009 Service Repair Manual YES >> GO TO 2. NO >> Repair the terminal and connector. YES >> GO TO 3. NO >> Repair the combination meter branch line. Power Supply and Ground Circuit Inspection " . Is the inspection result normal?

Page 3582 of 4331

NISSAN TIIDA 2009 Service Repair Manual LAN N O P ABS BRANCH LINE CIRCUIT Diagnosis Procedure INFOID:0000000004749311YES >> GO TO 2. NO >> Repair the terminal and connector. YES >> GO TO 3. NO >> Repair the ABS actuator and electric unit (c

Page 3583 of 4331

NISSAN TIIDA 2009 Service Repair Manual YES >> GO TO 2. NO >> Repair the terminal and connector. YES >> GO TO 3. NO >> Repair the IPDM E/R branch line. IPDM E/R Power/Ground Circuit Inspection " . Is the inspection result normal? YES (Pre

Page 3584 of 4331

NISSAN TIIDA 2009 Service Repair Manual CAN COMMUNICATION CIRCUIT LAN-189 < COMPONENT DIAGNOSIS > [CAN SYSTEM (TYPE 14)] C D E F G H I J L M A B LAN N O P CAN COMMUNICATION CIRCUIT Diagnosis Procedure INFOID:00000000047493141. CONNECTOR INS
