Page 345 of 4331

NISSAN TIIDA 2009 Service Repair Manual AT-340< SERVICE INFORMATION > REPAIR FOR COMPONENT PARTS • Make sure bearings roll freely and are free from noise, cracks, pit- ting or wear. Replace if necessary. CAUTION: When replacing taper r

Page 346 of 4331

NISSAN TIIDA 2009 Service Repair Manual AT N O P c. Adjust the back clearance of side gear according to the following procedures. i. Insert feeler gauges (A) of the same thickness to the back of side gear from both sides, p

Page 347 of 4331

NISSAN TIIDA 2009 Service Repair Manual Final Drive " . Tool number A: ST33200000 (J-26082) SCIA8005E SCIA8004E

Page 348 of 4331

NISSAN TIIDA 2009 Service Repair Manual AT N O P ASSEMBLY Assembly (1) INFOID:0000000004305528 1. Drive each differential side oil seal evenly using Tools (Tran- saxle case side) and suitable tool (Convertor housing side)

Page 349 of 4331

NISSAN TIIDA 2009 Service Repair Manual SCIA3623E SCIA3625E

Page 350 of 4331

NISSAN TIIDA 2009 Service Repair Manual AT N O P • Measure dimension (C) between the surface of idler gear bearing inner race and the surface of transaxle case. • Measure dimension (C) in at least two places, and take the averag

Page 351 of 4331

NISSAN TIIDA 2009 Service Repair Manual Reduction Pinion Gear " . SAT682D SAT684D

Page 352 of 4331

NISSAN TIIDA 2009 Service Repair Manual ASSEMBLY AT-347 < SERVICE INFORMATION > D E F G H I J K L M A B AT N O P • Measure dimension (H) between end of output shaft and adjusting spacer mating surface of output shaft. • Measure
