Page 257 of 4331

NISSAN TIIDA 2009 Service Repair Manual Adjusting shims, Needle Bearings, Thrust Washers and Snap Rings " .

Page 258 of 4331

NISSAN TIIDA 2009 Service Repair Manual AT N O P MR18DE ENGINE MODELS • Refer to AT-373, " Adjusting shims, Needle Bearings, Thrust Washers and Snap Rings " .

Page 259 of 4331

NISSAN TIIDA 2009 Service Repair Manual Adjusting shims, Needle Bearings, Thrust Washers and Snap Rings " .

Page 260 of 4331

NISSAN TIIDA 2009 Service Repair Manual AT N O P MR18DE ENGINE MODELS • Refer to AT-373, " Adjusting shims, Needle Bearings, Thrust Washers and Snap Rings " .

Page 261 of 4331

NISSAN TIIDA 2009 Service Repair Manual SAT008D SAT009D

Page 262 of 4331

NISSAN TIIDA 2009 Service Repair Manual AT N O P 5. Remove turbine revolution sensor (power train revolution sen- sor) (1) from transaxle case (2). : Bolt 6. Remove O-ring (3) from turbine revolution sensor (power train revol

Page 263 of 4331

NISSAN TIIDA 2009 Service Repair Manual . 14. Remove magnets from oil pan. 15. Remove control valve assembly according to the following procedures. a. Remove snap ring (1) from terminal body (2). CAUTION: Do not expand snap ring (1) excessi

Page 264 of 4331

NISSAN TIIDA 2009 Service Repair Manual AT N O P 16. Remove manual valve from control valve assembly. •Inspect the sliding surfaces of manual valve and valve body, and replace if damaged or dented. CAUTION: Be careful not to drop
