2022 TOYOTA PRIUS PLUG-IN HYBRID Owners Manual

4475-5. Using the driving support systems
Prius Plug-in Hybrid_OM_OM47E75E_(EE)
5
Driving
QSituations in which the system may not operate properly
The Rear Crossing Traffic Alert function may not detect vehicle s correctly in
the following situations:
O When the sensor is misaligned due to a strong impact to the sensor or its
surrounding area
O When mud, snow, ice, a sticker, etc. is covering the sensor or surrounding
area on the position above the rear bumper
O When driving on a road surface that is wet with standing water during bad
weather, such as heavy rain, snow, or fog
O When multiple vehicles are approaching with only a small gap between
each vehicle
O When a vehicle is approaching at high speed
O When equipment that may obstruct a sensor is installed, such as a towing
eyelet, bumper protector (an additional trim strip, etc.), bicy cle carrier, or
snow plow
O When towing a trailer
O When there is a significant difference in height between your vehicle and the
vehicle that enters the detection area
O When a sensor or the area around a sensor is extremely hot or cold
O If the suspension has been modified or tires of a size other than specified
are installed
O When backing up on a slope with a
sharp change in grade
O When backing out of a sharp angle park-
ing spot

4485-5. Using the driving support systems
Prius Plug-in Hybrid_OM_OM47E75E_(EE)
O If the front of the vehicle is raised or lowered due to the carried load
Q Situations in which the system may operate even if there is no possibil-
ity of a collision
Instances of the Rear Crossing Traffic Alert function unnecessa rily detecting
a vehicle and/or object may increase in the following situation s:
O When equipment that may obstruct a sensor is installed, such as a towing
eyelet, bumper protector (an additional trim strip, etc.), bicy cle carrier, or
snow plow
O When turning while backing up
O When a vehicle turns into the detection
area
O When the parking space faces a street
and vehicles are being driven on the
street
O When the distance between your vehicle
and metal objects, such as a guardrail,
wall, sign, or parked vehicle, which may
reflect electrical waves toward the rear
of the vehicle, is short

4495-5. Using the driving support systems
Prius Plug-in Hybrid_OM_OM47E75E_(EE)
5
Driving
OWhen there are spinning objects near your vehicle such as the fan of an air
conditioning unit
O When water is splashed or sprayed toward the rear bumper, such as from a
sprinkler
O Moving objects (flags, exhaust fumes, large rain droplets or snowflakes, rain
water on the road surface, etc.)
O When the distance between your vehicle and a guardrail, wall, etc., that
enters the detection area is short
O Gratings and gutters
O When a sensor or the area around a sensor is extremely hot or cold
O If the suspension has been modified or tires of a size other than specified
are installed
O If the front of the vehicle is raised or lowered due to the carried load
O When a vehicle passes by the side of
your vehicle
O When a detected vehicle turns while
approaching the vehicle

4505-5. Using the driving support systems
Prius Plug-in Hybrid_OM_OM47E75E_(EE)
Toyota parking assist-sensor
Front corner sensors
Front center sensors
Rear corner sensors
Rear center sensors
Front side sensors
Rear side sensors
The Toyota parking assist-sensor
can be enabled/disabled on the
screen ( P. 247) of the
multi-information display.
When on is selected, Toyota park-
ing assist-sensor indicator will
come on.
Once off is selected, the Toyota parking assist-sensor will not return to on
until it is turned to on by the screen of multi-information di splay again.
(The system does not automatically return to on even when the h ybrid sys-
tem is restarted.)
: If equipped
The distance from your vehicle to nearby obstacles when paral-
lel parking or maneuvering into a garage is measured by the
sensors and communicated via the displays and a buzzer.
Always check the surrounding area when using this system.
Types of sensors
1
2
3
4
5
6
Turning the Toyota parking assist-sensor on/off

4515-5. Using the driving support systems
Prius Plug-in Hybrid_OM_OM47E75E_(EE)
5
Driving
When the sensors detect an obstacle, the following displays inform
the driver of the position and distance to the obstacle.
QMulti-information display
Front center sensor opera-
tion
Front corner sensor opera-
tion
Front side sensor operation
Rear side sensor operation
Rear corner sensor operation
Rear center sensor operation
• The operation display is gray when the sensors are operating.
• The front side sensor operation displays and rear side sensor operation
displays are not shown until a scan of the side areas is completed.
Q
Audio system screen
When the Toyota parking assist
monitor is displayed:
A simplified image is displayed
on the right upper corner of the
audio system screen when an
obstacle is detected.
Display
1
2
3
4
5
6

4525-5. Using the driving support systems
Prius Plug-in Hybrid_OM_OM47E75E_(EE)Q
Distance display
Sensors that detect an obstacle will illuminate continuously or blink.
Sensor detection display, obstacle distance
Multi-informa-
tion display
*
Audio system
screen
*
Approximate distance to obstacle
Front corner,
front center and
front side
sensorsRear corner,
rear center and
rear side
sensors
(continuous)(blinking
slowly)
100 cm (3.3 ft.)
to 60 cm (2.0 ft)150 cm (4.9 ft.)
to 60 cm
(2.0 ft.)
(continuous)(blinking)
60 cm (2.0 ft.) to
45 cm (1.5 ft)
60 cm (2.0 ft.)
to 45 cm
(1.5 ft.)
100 cm (3.3 ft.)
to 70 cm (2.3 ft.)100 cm (3.3 ft.)
to 70 cm (2.3 ft.)
60 cm (2.0 ft.)
to 45 cm
(1.5 ft.)
60 cm (2.0 ft.) to
45 cm (1.5 ft)
(continuous)(blinking
rapidly)
45 cm (1.5 ft.) to
35 cm (1.2 ft.)
45 cm (1.5 ft.)
to 35 cm
(1.2 ft.)
70 cm (2.3 ft.) to
30 cm (1.0 ft.)70 cm (2.3 ft.) to
30 cm (1.0 ft.)
45 cm (1.5 ft.)
to 35 cm
(1.2 ft.)
45 cm (1.5 ft.) to
35 cm (1.2 ft.)
(blinking)(continuous)
Less than
35 cm (1.2 ft.)
Less than
35 cm (1.2 ft.)
Less than
30 cm (1.0 ft.)Less than
30 cm (1.0 ft.)
Less than
35 cm (1.2 ft.)
Less than
35 cm (1.2 ft.)
Far
Near
16
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6

4535-5. Using the driving support systems
Prius Plug-in Hybrid_OM_OM47E75E_(EE)
5
Driving
*: The images may differ from those shown in the illustrations depending on
the detection status. (P. 451)
Front center sensors
Front corner sensors
Front side sensorsRear side sensors
Rear corner sensors
Rear center sensors1
2
3
4
5
6

4545-5. Using the driving support systems
Prius Plug-in Hybrid_OM_OM47E75E_(EE)
When an obstacle is detected, the buzzer sounds.
OAs the obstacle is approached, the buzzer sounds more rapidly.
When the obstacle is extremely close, the buzzer switches from
sounding intermittently (short beeps) to continuously (a long beep).
• Distance to obstacle detected by front corner sensor is approxi-
mately 35 cm (1.2 ft.) or less
• Distance to obstacle detected by front side sensor or rear side
sensor is approximately 30 cm (1.0 ft.) or less
• Distance to obstacle detected by front sensor is approximately
35 cm (1.2 ft.) or less
• Distance to obstacle detected by rear corner sensor is approxi-
mately 35 cm (1.2 ft.) or less
• Distance to obstacle detected by back sensor is approximately
35 cm (1.2 ft.) or less
OWhen an obstacle is detected by multiple sensors simultaneously,
the buzzer sounds according to the distance to the closest obsta-
cle.
OWhen obstacles are simultaneously detected to the front and rear
of the vehicle, separate buzzers sound patterns according to the
distance to each obstacle.
The volume and timing of the buzzer can be changed. (P. 724)
Buzzer
