1999 DODGE RAM Service Repair Manual

Fig. 2: Vacuum Hose Diagram (Caravan & Voyager - 2.4L - Except
Calif.)
Courtesy of Chrysler Corp.
Fig. 3: Vacuum Hose Diagram (Caravan, Town & Country, & Voyager -
3.3L & 3.8L - Calif.)
Courtesy of Chrysler Corp.

Fig. 4: Vacuum Hose Diagram (Caravan, Town & Country, & Voyager -
3.3L & 3.8L - Except Calif.)
Courtesy of Chrysler Corp.
Fig. 5: Vacuum Hose Diagram (Dakota - 2.5L - Calif.)
Courtesy of Chrysler Corp.

Fig. 6: Vacuum Hose Diagram (Dakota - 2.5L - Except Calif.)
Courtesy of Chrysler Corp.
Fig. 7: Vacuum Hose Diagram (Dakota - 3.9L & 5.2L - Calif.)
Courtesy of Chrysler Corp.

Fig. 8: Vacuum Hose Diagram (Dakota - 5.9L - Calif.)
Courtesy of Chrysler Corp.
Fig. 9: Vacuum Hose Diagram (Dakota - 3.9L & 5.2L - Except Calif.)
Courtesy of Chrysler Corp.

Fig. 10: Vacuum Hose Diagram (Dakota - 5.9L - Except Calif.)
Courtesy of Chrysler Corp.
Fig. 11: Vacuum Hose Diagram (Durango - 3.9L & 5.2L - Calif.)
Courtesy of Chrysler Corp.

Fig. 12: Vacuum Hose Diagram (Durango - 5.9L - Calif.)
Courtesy of Chrysler Corp.
Fig. 13: Vacuum Hose Diagram (Durango - 3.9L & 5.2L - Except Calif.)
Courtesy of Chrysler Corp.

Fig. 14: Vacuum Hose Diagram (Durango - 5.9L - Except Calif.)
Courtesy of Chrysler Corp.
Fig. 15: Vacuum Hose Diagram (Ram Pickup - 3.9L & 5.2L - Light-Duty)
Courtesy of Chrysler Corp.

Fig. 16: Vacuum Hose Diagram (Ram Pickup - 5.9L - Light-Duty)
Courtesy of Chrysler Corp.
Fig. 17: Vacuum Hose Diagram (Ram Pickup - 3.9L & 5.2L - Medium-
Duty Calif.)
Courtesy of Chrysler Corp.
