as the malfunction is detected. A stored code indicates there was an
active code present at some time. However, the code currently may not
be present as an active code, although another active code could be.
When a trouble code occurs, the AIR BAG warning light
illuminates for 12 seconds minimum (even if problem existed for less
than 12 seconds). Code is stored, along with time in minutes it was
active, and number of times ignition has been cycled since problem was
detected.
When and if malfunction ceases to exist, an ignition cycle
count will be initiated for that code. If ignition cycle count reaches
100 without a reoccurrence of the same malfunction, DTC is erased and
that ignition cycle counter is reset to zero. If malfunction reoccurs
before count reaches 100, ignition cycle counter will be reset and DTC
will continue to be a stored code.
If a particular code is not active while performing
diagnostic test for that code, code diagnostic test may not locate the
source of the problem. In this case, stored code can only indicate an
area of system to inspect.
If no obvious problems are found, erase stored codes, and
with ignition on, wiggle wiring harness and connectors. Recheck for
codes periodically as you work through system. This procedure may
uncover a difficult problem to locate.
PRETEST INSPECTION & DIAGNOSTIC PROCEDURE
Following precautions and procedures must be followed:
* Always follow air bag service precautions to avoid air bag
deployment and possible personal injury. Refer to procedure
under See SERVICE PRECAUTIONS.
* After component replacement, ensure proper system operation.
See SYSTEM OPERATION CHECK .
* When testing voltage or continuity at ACM, use terminal side
(not wire end) of connector. DO NOT probe wire through
insulation.
* Always check if any TECH SERVICE BULLETINS (TSBs) apply to
vehicle.
* When using diagnostic charts, DO NOT skip any steps in chart
or incorrect diagnosis may result. Always perform
SYSTEM OPERATION CHECK after repairs are made.
* Always use most current DRB diagnostic program cartridge
available to prevent erroneous codes or test results.
* When using diagnostic charts, use DRB voltmeter unless
instructed to use an external voltmeter. Never use a test
light in place of a voltmeter.
* When performing electrical tests, prevent accidental
shorting of terminals. Such shorts can damage fuses or
components and may cause a second code (message) to be
set, making diagnosis of original problem more difficult.
* Vehicle must have a fully-charged battery and functional
charging system.
* Each time a connector is disconnected, inspect it to ensure
it is in good condition. Always focus on circuit being
tested. Dirt, water and corrosion, are most common problems
in connectors.
* Always disconnect DRB after use.
* Always disconnect DRB before charging battery.
USING DRB
1) Refer to DRB user guide for instructions and assistance
with reading trouble codes and other DRB functions. Under normal
operation DRB will display one of only 2 error messages: User-

Requested WARM boot or User-Requested COLD boot. If DRB should display
any other error message, record entire display and contact
manufacturer.
2) If DRB does not power-up, check for loose cable
connections or a bad cable. Check vehicle battery voltage (data link
connector terminal No. 16). A minimum of 11 volts is required to
adequately power DRB.
3) If all connections are proper between DRB and vehicle or
other devices, and vehicle battery is fully charged, an inoperative
DRB may be result of faulty cable or vehicle wiring.
ENTERING ON-BOARD DIAGNOSTICS
1) Before entering on-board diagnostics, refer to
PRETEST INSPECTION & DIAGNOSTIC PROCEDURE . Connect DRB to data link
connector. Data link connector (DLC) is located under left side of
instrument panel, left of steering column.
NOTE: Read active DTCs with PAD switch in both ON and OFF
positions. Always turn ignition off before changing PAD
switch positions,
2) Turn ignition switch to ON position. Exit vehicle with
DRB. Using DRB, read and record active Diagnostic Trouble Code (DTC)
data. Read and record stored DTC data. If any DTCs (fault messages)
exist, perform appropriate test.
3) If PAD switch OFF indicator fails to illuminate when in
the OFF position, go to PAD SWITCH INDICATOR PROBLEMS . If PAD switch
OFF indicator illuminates when switch is in ON position or key
cylinder does not operate, replace PAD switch.
4) Air Bag Control Module (ACM) may report any of the
following DTCs or fault messages. If the following active or stored
codes are reported by DRB, replace ACM. See
AIR BAG CONTROL MODULE (ACM) under REMOVAL & INSTALLATION.
* ACM OUTPUT DRIVER CIRCUIT OPEN
* ACM ACCELEROMETER
* ACM INTERNAL DIAGNOSTIC CODE #1
* WARNING LAMP DRIVER ERROR
* FIRING CAPACITOR LOW
* LOGIC CAPACITOR LOW
* SAFING SENSOR SHORTED
If the following active codes are reported by DRB, go to the
appropriate procedure under DIAGNOSTIC TESTS.
* CLUSTER MESSAGE MISMATCH
* DRIVER SQUIB CIRCUIT OPEN
* DRIVER SQUIB CIRCUIT SHORTED
* DRIVER SQUIB CIRCUIT SHORTED TO BATTERY
* DRIVER SQUIB CIRCUIT SHORTED TO GROUND
* LOSS OF IGNITION RUN ONLY
* LOSS OF IGNITION RUN/START
* NO CLUSTER CCD MESSAGE
* NO CCD COMMUNICATION
* MISSING OR INVALID VIN
* PASSENGER SQUIB CIRCUIT OPEN
* PASSENGER SQUIB CIRCUIT SHORTED
* PASSENGER SQUIB CIRCUIT SHORTED TO BATTERY
* PASSENGER SQUIB CIRCUIT SHORTED TO GROUND
* SCTM FAILURE
* SCTM MESSAGE MISMATCH
* VIN MESSAGE MISMATCH

* WARNING LAMP CIRCUIT OPEN/SHORTED
DIAGNOSTIC TESTS
* PLEASE READ THIS FIRST *
NOTE: Many of the diagnostic tests of the air bag restraint system
require voltage or resistance checks at various system
connector terminals. See Figs. 6-19.
Fig. 6: Identifying Powertrain Control Module (PCM) Connector
Terminals
Courtesy of DaimlerChrysler Corp.
Fig. 7: Identifying Instrument Cluster Connector Terminals
Courtesy of DaimlerChrysler Corp.

Fig. 8: Locating Seat Belt Control Timer Module & Main Seat Connector
Courtesy of DaimlerChrysler Corp.
Fig. 9: Identifying Seat Belt Control Timer Module (SCTM)
Connector Terminals
Courtesy of DaimlerChrysler Corp.

Fig. 10: Identifying Air Bag Control Module (ACM) Connector Terminals\
Courtesy of DaimlerChrysler Corp.
Fig. 11: Identifying Driver Squib Connector Terminals
Courtesy of DaimlerChrysler Corp.

Fig. 12: Locating Clockspring 2-Pin Connector
Courtesy of DaimlerChrysler Corp.
Fig. 13: Identifying Passenger Air Bag Disable (PAD) Switch
Connector Terminals (Switch Side)
Courtesy of DaimlerChrysler Corp.

Fig. 14: Identifying Passenger Air Bag Disable (PAD) Switch
Connector Terminals (Harness Side)
Courtesy of DaimlerChrysler Corp.
Fig. 15: Identifying Passenger Air Bag Disable (PAD) Switch 2-Pin
Connector Terminals
Courtesy of DaimlerChrysler Corp.

Fig. 16: Identifying Data Link Connector (DLC) Terminals
Courtesy of DaimlerChrysler Corp.
