1999 DODGE RAM Service Repair Manual

Fig. 2: Adjusting Transfer Case Shift Linkage (Ram Pickup)
Courtesy of Chrysler Corp.
TROUBLE SHOOTING
NOTE: For trouble shooting not covered in this article, see
appropriate table in TROUBLE SHOOTING article in GENERAL
INFORMATION.
Hydraulic system should not require addition of fluid under
normal circumstances. Reservoir fluid level will increase as normal
clutch wear occurs. Avoid overfilling or removing fluid from
reservoir. This will cause clutch release problems.
TESTING
CLUTCH PEDAL POSITION SWITCH
NOTE: The position switch is an integral part of clutch master
cylinder push rod and cannot be serviced separately.
Disconnect clutch pedal position switch electrical connector.
Depress switch. Using a DVOM, measure continuity between clutch pedal
position switch terminals No. 1 (Yellow/Red wire) and No. 2 (Dark
Blue/Yellow wire). If continuity exists, switch is okay. If continuity
does not exist, replace clutch master cylinder. See CLUTCH MASTER
CYLINDER under REMOVAL & INSTALLATION.

CLUTCH HOUSING (RAM PICKUP)
NOTE: Only NV4500 clutch housing can be checked using the following
bore and face runout procedures. The NV1500, NV3500 and
NV5600 clutch housings are an integral part of transmission
front case and can only be checked off vehicle.
Clutch Housing Bore Runout (NV4500)
1) Remove clutch housing. Remove clutch cover and disc. See
CLUTCH ASSEMBLY under REMOVAL & INSTALLATION. Replace one flywheel
bolt with a threaded rod. See Fig. 2. Remove release fork from clutch
housing. Reinstall clutch housing. Tighten housing bolts nearest
alignment dowels first. Mount dial indicator on threaded rod and
position indicator plunger on surface of clutch housing bore. See
Fig. 4 .
2) Rotate crankshaft until indicator plunger is at top center
of housing bore. Zero dial indicator. Rotate crankshaft and record
indicator readings at 8 points, 45 degrees apart, around bore. See
Fig. 5 .
3) Repeat measurement at least twice. Subtract each reading
from one 180 degrees opposite to determine magnitude and direction of
runout. For example: 0.000" minus (-0.007") = 0.007", 0.002" minus (-\
0.010") = 0.01", 0.004" minus (-0.005") = 0.009" or -0.001" minus (0\
.
001") = -0.002" which will be 0.002". In this example, largest
difference is 0.012" (total indicator reading). This means housing
bore is offset from crankshaft centerline by 0.006" (1/2 of 0.012").
4) On gas engines, acceptable total indicator reading is 0.
010". If measured total indicator reading is more than 0.010", bore
runout will have to be corrected using offset dowels. Offset dowels
are available in 0.007", 0.014" and 0.021". See DOWEL SELECTION table.
If total indicator reading is 0.053" or greater, replace clutch
housing. If dial indicator reads positive when plunger moves inward
(toward indicator) and negative when moves outward away from
indicator), lowest or most negative reading determines direction of
housing bore offset (runout).
5) On diesel engines, offset dowels are not available to
correct runout. If total indicator reading exceeds bore runout of 0.
015", replace either clutch housing, or transmission adapter plate. On
gas engines, if bore is offset, remove housing and original dowels,
install new offset dowels in direction need to center bore with
crankshaft centerline. Install new dowels with slotted side facing
out. Using a screwdriver, rotate dowels until total indicator reading
is less than 0.010". Ensure clutch housing face runout is within
specification.
DOWEL SELECTION









\









\









\









\









\









\









\







Application - In. (mm) Offset Dowel - In. (mm\
)
0.011-0.021 (0.2794-0.5334) ......................... 0.007 (0.1778\
)
0.022-0.035 (0.5588-0.8890) ......................... 0.014 (0.3556\
)
0.036-0.052 (0.9144-1.3208) ......................... 0.021 (0.5334\
)









\









\









\









\









\









\









\







Fig. 3: Manufactured Stud Or Threaded Rod
Courtesy of Chrysler Corp.

Fig. 4: Measuring Clutch Housing Bore
Courtesy of Chrysler Corp.
Fig. 5: Measurement Of Clutch Housing Bore (Example)
Courtesy of Chrysler Corp.
Clutch Housing Face Runout (NV4500)
1) After performing a clutch housing bore runout check,

reposition dial indicator plunger on housing face. Place indicator
plunger at rim of housing bore. See Fig. 6. Rotate crankshaft until
indicator plunger is at 10 o'clock position on bore. Zero dial
indicator. Measure and record face runout at 4 points 90 degrees apart
around housing face. See Fig. 7.
2) Perform measurement at least twice. Subtract lowest
reading from highest. For example: 0.009" minus (-0.004")=0.013".
Total allowable face runout is 0.010".
3) Correct housing face runout by installing shims between
clutch housing and transmission. Shims have to be made using shim
stock or similar materials. Use clutch housing face measurement
illustration as an example. See Fig. 7. Three shims will be needed.
Shim thicknesses should be 0.009" at 0.000 corner, 0.012" at -0.003
corner and 0.013" at -0.004 corner.
Fig. 6: Measuring Clutch Housing Face
Courtesy of Chrysler Corp.
Fig. 7: Measurement Of Clutch Housing Face (Example)
Courtesy of Chrysler Corp.

REMOVAL & INSTALLATION
TRANSFER CASE
CAUTION: When removing transfer case, DO NOT allow drive shafts to
hang free, as damage to "U" joints may result.
Removal (NV231HD, NV241HD & NV241LD - Ram Pickup)
1) Raise and support vehicle. Remove skid plate (if
equipped). Drain lubricant from transfer case if transfer case is
being repaired. Mark drive shafts and "U" joints for reassembly
reference. Disconnect speed sensor wires. Disconnect vent harness and
vent hose from transfer case switch.
2) Disconnect shift rod from grommet in transfer case shift
lever, or from floor arm, whichever provides easy access. Using slip
joint pliers, press rod out of lever grommet. See Fig. 8. Support
transmission with jackstand. Remove rear crossmember. Remove front and
rear drive shafts. Remove transfer case-to-transmission housing nuts.
Using transmission jack, support transfer case. Move transfer case
rearward until free of transmission. Remove transfer case from under
vehicle.
Removal (NV231 & NV242 - Dakota)
1) Shift transfer case into neutral. Raise vehicle. If
transfer case will be repaired, drain lubricant. Mark driveshafts and
"U" joints for reassembly reference. Support transmission with
jackstand. Remove rear crossmember and skid plate, if equipped.
2) Disconnect front and rear driveshafts at transfer case.
Disconnect transfer case linkage rod from shift lever. Disconnect
transfer case vent hose and electrical connectors. Support transfer
case with transmission jack. Remove nuts attaching transfer case to
transmission. Remove transfer case.
Installation (All Models)
To install, reverse removal procedure. If necessary fill
transfer case with MOPAR ATF Plus or Dexron-II. Tighten all nuts and
bolts to specification. See TORQUE SPECIFICATIONS table. Adjust shift
linkage, if necessary. See SHIFT LINKAGE ADJUSTMENT under ADJUSTMENTS.
Fig. 8: Removing Transfer Case Shift Mechanism (NV4500 & NV4500HD)
Courtesy of Chrysler Corp.
TRANSMISSION (DAKOTA)

Removal (AX15 & NV1500)
1) Shift gear selector into 1st or 3rd gear. Raise and
support vehicle. Disconnect necessary exhaust system components.
Remove "Y" pipe and position remaining pipes for working clearance.
Support transmission adjustable jackstand. Disconnect rear cushion and
mounting bracket from transmission or transfer case.
2) Remove rear crossmember. If transmission will be
disassembled for repair, drain transmission fluid. Disconnect
transmission shift linkage, speedometer cable, transfer case vacuum
lines and clutch hydraulic lines. Lower transmission/transfer case
assembly no more than 3" (76 mm). Reaching around transmission case,
unseat and lift shift lever dust boot. Press shift lever retainer
downward, turn retainer counterclockwise, and lift lever and retainer
out of shift tower.
3) Mark front and rear drive shaft and "U" joint for
reassembly reference. Disconnect and remove both drive shafts. Remove
crankshaft position sensor (AX15). Disconnect transmission/transfer
case assembly vent hoses. Remove slave cylinder from clutch housing.
Remove wire harness from clips on transmission case and transfer case.
4) Support transmission/transfer case assembly with
transmission jack. Secure assembly to jack with safety chains.
Reposition adjustable jackstand under engine. Remove clutch housing
brace rod. Remove clutch housing nuts and bolts. Remove
transmission/transfer case assembly.
Installation
To install, reverse removal procedure. Apply high-temperature
grease to release fork, lever, pivot ball stud and pilot bushing
located in end of crankshaft. Fill transmission with appropriate
fluid, if necessary. Tighten all nuts and bolts to specification. See
TORQUE SPECIFICATIONS table.
Removal (NV 3500)
1) Disconnect negative battery cable. Shift transmission to
Neutral. Open console lid and remove bolts attaching console to floor
pan. Lift cup holder bin and remove bolt attaching console to floor
pan. Lift rear of console and pull console rearward to separate from
shift bezel. Remove console from vehicle. Remove screws attaching
shift boot to floor pan and slide boot upward on lever extension.
2) Remove shift lever extension. Raise and support vehicle.
On 4WD models, remove skid plate, if equipped. Mark drive shaft and
axle yoke for alignment reference. Remove drive shaft. Remove exhaust
"Y" pipe. On 4WD models, disconnect and lower remaining exhaust pipes
for clearance as necessary. Disconnect speed sensor harness connector
and back-up light harness connector.
3) Support engine using adjustable jackstand. If transmission
is to be disassembled for repair, drain lubricant from transmission.
On 4WD models, disconnect transfer case shift linkage at transfer case
range lever and remove shift lever from transmission. Remove
bolts/nuts attaching transmission to rear mount.
4) Support transmission with a transmission jack. Secure
transmission with safety chains. Remove rear crossmember. On 4WD
models, support transfer case with transmission jack and secure
transfer case to jack with safety chains. Remove transfer case
attaching nuts and move transfer case rearward until input gear clears
transmission output shaft.
5) Lower transfer case assembly and remove it from under
vehicle. On 4WD models, remove clutch slave cylinder splash shield, if
equipped. Remove clutch slave cylinder and move aside for working
clearance. Remove starter. Remove transmission splash shield. Remove
transmission harness wires from clips on transmission shift cover.
6) Lower transmission slightly. Remove shift tower and lever
assembly. Remove transmission-to-engine attaching bolts. Slide

transmission and jack rearward until input shaft clears clutch disc.
Lower transmission jack and remove transmission from under vehicle.
Installation
1) To install, reverse removal procedure. Apply high-
temperature grease to pilot bushing located in end of crankshaft. Also
apply grease to release bearing bore, release fork, release fork ball
stud and drive shaft slip yoke. Apply sealer to threads of drain plug
before installing in case.
2) Align reference marks made on drive shaft(s) and "U"
joints during removal. After installing clutch assembly and housing,
tighten housing bolts nearest alignment dowels first. During final
transmission installation, install shims between clutch housing and
transmission at appropriate bolt location. Tighten all nuts and bolts
to specification. See TORQUE SPECIFICATIONS table.
TRANSMISSION (RAM PICKUP)
Removal (NV3500 & NV5600)
1) Disconnect negative battery cable. Shift transmission to
Neutral. Remove shift boot bezel screws and slide boot upward on lever
extension. Remove shift tower and lever assembly. Raise and support
vehicle.
2) On 4WD models, remove skid plate, if equipped. Remove
crankshaft position sensor. Mark drive shaft and axle yoke for
alignment reference. Remove drive shaft. Remove exhaust "Y" pipe. On
4WD models, disconnect and lower remaining exhaust pipes for
clearance, as necessary. Disconnect speed sensor harness connector.
3) Support engine using adjustable jackstand. If transmission
is to be disassembled for repair, drain lubricant from transmission.
On 4WD models, disconnect transfer case shift linkage at transfer case
range lever and remove shift lever from transmission. Remove
bolts/nuts attaching transmission to rear mount.
4) Support transmission with a transmission jack. Secure
transmission with safety chains. Remove rear crossmember. On 4WD
models, support transfer case with transmission jack and secure
transfer case to jack with safety chains. Remove transfer case
attaching nuts and move transfer case rearward until input gear clears
transmission output shaft.
5) Lower transfer case assembly and remove it from under
vehicle. On 4WD models, remove clutch slave cylinder splash shield, if
equipped. Remove clutch slave cylinder and move aside for working
clearance. Remove starter. Remove transmission splash shield. Remove
transmission harness wires from clips on transmission shift cover. On
some models, it may be necessary to remove front axle struts and oil
filter for access and removal clearance.
6) Lower transmission slightly. Remove shift tower and lever
assembly. Remove transmission-to-engine bolts. Slide transmission and
jack rearward until input shaft clears clutch disc. Lower transmission
jack and remove transmission from under vehicle.
Installation
1) To install, reverse removal procedure. Apply high-
temperature grease to pilot bushing located in end of crankshaft. Also
apply grease to release bearing bore, release fork, release fork ball
stud and drive shaft slip yoke.
2) Apply sealer to threads of drain plug before installing in
case. Align reference marks made on drive shaft(s) and axle yoke(s)
during removal. After installing clutch assembly and housing, tighten
housing bolts nearest alignment dowels first. Tighten all nuts and
bolts to specification. See TORQUE SPECIFICATIONS table.
Removal (NV4500 & NV4500HD)

1) Disconnect negative battery cable. Shift transmission to
Neutral. Remove shift boot bezel screws and slide boot upward on lever
extension. Scribe mark position of extension on shank of shift lever.
2) Raise and support vehicle. On 4WD models, remove skid
plate, if equipped. Mark drive shaft and axle yoke for alignment
reference. Remove drive shaft. Remove exhaust "Y" pipe. On 4WD models,
disconnect and lower remaining exhaust pipes for clearance as
necessary. Disconnect speed sensor harness connector and back-up light
harness connector.
3) Support engine using adjustable jackstand. If transmission
is to be disassembled for repair, drain lubricant from transmission.
See Fig. 9 . On 4WD models, disconnect transfer case shift linkage at
transfer case range lever and remove shift lever from transmission.
Remove bolts/nuts attaching transmission to rear mount.
4) Support transmission with a transmission jack. Secure
transmission with safety chains. Remove rear crossmember. On 4WD
models, support transfer case with transmission jack and secure
transfer case to jack with safety chains. Remove transfer case
attaching nuts and move transfer case rearward until input gear clears
transmission output shaft.
5) Lower transfer case assembly and move it from under
vehicle. On 4WD models, remove clutch slave cylinder splash shield, if
equipped. Remove clutch slave cylinder, and move aside. Remove
starter. Remove transmission splash shield. Remove transmission
harness wires from clips on transmission shift cover. On some models,
it may be necessary to remove front axle struts and oil filter for
access and removal clearance.
6) Lower transmission slightly. Remove shift tower and lever
assembly. Remove transmission-to-engine bolts. Slide transmission and
jack rearward until input shaft clears clutch disc. Lower transmission
jack and remove transmission from under vehicle.
Installation
1) To install, reverse removal procedure. Apply high-
temperature grease to pilot bushing located in end of crankshaft. Also
apply grease to release bearing bore, release fork, release fork ball
stud and propeller shift slip yoke.
2) Apply sealer to threads of drain plug before installing in
case. Align reference marks made on drive shaft(s) and axle yoke(s)
during removal. After installing clutch assembly and housing, tighten
housing bolts nearest alignment dowels first.
3) During final transmission installation, install shims
between clutch housing and transmission at appropriate bolt location.
See CLUTCH HOUSING BORE RUNOUT and CLUTCH HOUSING FACE RUNOUT under
CLUTCH HOUSING (RAM PICKUP) under TESTING. Press extension to scribe
mark made during removal. A 0.12-0.20" (3-5 mm) space should exist
between shift lever isolator, top edge of stub shaft and tool lower
jaw. Tighten all nuts and bolts to specification. See TORQUE
SPECIFICATIONS table.
Fig. 9: Identifying Transmission Drain Bolt (NV4500 & NV4500HD)
Courtesy of Chrysler Corp.
CLUTCH ASSEMBLY
